Side 1/2
Wimberley, Inc. ©2017, All Rights Reserved
Recess
p cylindrical
ch as small
and branches.
Foam Jaw Inserts
Grip delicate objects without damage.
Thumbscrew Turn the thumbscrew to open or close the jaws of the clip.
Compared to typical spring activated clips, thumbscrew activated clip jaws allow -
for more finesse when holding delicate objects, as well as much higher maximum
clamping force when desired.
The Plamp Clip
Clip Body
The clip is custom designed to hold
anything from the most delicate plant stems
to heavy reflectors and diffusers. It is made of
nearly unbreakable ST Nylon
Jaw opening band
This elastomer band puts tension on the clamp s moving ’
jaw so that it opens when you loosen the thumbscrew. It
is made of weather/UV resistant EPDM (the same mate-
rial that industrial rubber roofs are made of)
Special notches in the clip s jaws grab the steel rim on reflectors and ’
diffusers, providing a secure, slip free attachment (applies to typical cloth-
reflectors/diffusers with steel perimeter hoop). This new feature is a drastic
improvement over other clips currently on the market.
The firm grip allows you to make precise adjustments to the angle of a reflector.
You can even hold diffusers cantilevered straight out above your subject
Important Feature
Reflector/Diffuser Notches
5 Year Warranty – See www.tripodhead.com/warranty.cfm for complete details
PP-400 The Ground Plamp
Dimensions (coiled-up): (L x W x H): 12” 6” x x 1.5” in Weight: 10.2 oz (290g)
Maximum extended length: 27 inches
Package Contents:
The Plamp Ground Support (Qty 1)
Ground Spike (Qty 1)
Wimberley, Inc. Phone: 1- - - 434 529 8385
1750 Broadway St Toll Free: 1---888 665 2746 (USA & Canada)
Charlottesville, VA
22902 USA www.tripodhead.com info@tripodhead.com
Wimberley, Inc. ©2016, All Rights Reserved
PP- 210
Plamp Rod Extension ($19.00)
Fine control using the Plamp Rod Extension
For extra dexterity try using the Plamp Rod Extension in con-
junction with the Ground Plamp or a Plamp II connected to a
tripod leg or Plamp Stake.
Tips and Tricks
Extending the reach of your Ground Plamp
If you need more reach one option is to move the Ground Plamp closer to your subject. Another
option is to extend the length of your Plamp by adding extra links to its arm. We sell a long 12”
extension (part # PP 222). The trade off to adding extra length to your Plamp is that it becomes - -
less rigid. If you have a Plamp II, you can attach it in series to gain extra reach (see below). PP- 222
12” Plamp II Extension ($8.00)
Reconnecting the ball and socket joints of your Plamp- -
If the articulating arm is bent forcefully beyond its normal range of motion, it is
possible for the segments to pop out of joint. Fixing this is simply a matter of
popping the segments back together. If you have a hard time reconnecting the
joints (we realize it takes quite a bit of force), you can warm the socket (female)
end in hot water (boiling or near boiling). This will cause the socket to expand -
and make it easier to pop the ball portion into place.
Adjusting the Ground Spike fit inside the Sheath
Time and various conditions may affect the fit between the Ground Spike and Sheath. Therefore
the spike has been designed with an adjustment screw so that a snug but not excessively tight fit can be
achieved. This adjustment can be made with a standard slotted head screwdriver. If you have multiple
Ground Spikes you can use the tip of another spike to adjust the screw.
Extending the Sheath
The Sheath can be extended by about 10 inches with the
Extension Tube. Multiple extensions may be used.
You can also use standard Schedule 40 PVC 3/4”
pipe with a standard belled end or coupling fitting.
PP- 320
Extension Tube ($9.00)
Replacing a lost Ground Spike
If you lose your Ground Spike or need another
you may purchase one individually.
PP- 310
Ground Spike ($10.00)
Hold Additional Items with a Plamp II
A Plamp II with spring clamp can easily be attached
to the Ground Plamp, Tripod leg or Plamp Stake for
holding additional items
PP- 200
Plamp II ($43.00)
Rod Extension
Plamp II
Ground Plamp
Move desirable background or
foreground elements
into the picture.
Move distracting back-
ground or foreground
elements out of the way
PP-400 Ground Plamp
Made in USA
Made in USA
About the Ground Plamp
The Ground Plamp is an articulating arm used to hold macro subjects and other useful objects. The stake is inserted into a
variety of ground types and held by the pipe sheath connected to the arm. The other end (with the small black clip) grasps the
object you wish to hold.
How to use your Ground Plamp
To use the ground plamp, first remove the stake from the sheath then rotate and insert into the sheath with the
blade facing out. Then grasp the sheath and insert the blade into the ground.
Using Reflectors and Diffusers
The Ground Plamp will hold reflectors and diffusers in any position without problems. 12”
20” reflectors, which are generally held in a relatively vertical position and not fully
cantilevered out, can be held and positioned confidently with a single Ground Plamp.
20” Diffusers can be cantilevered above your subject using one Plamp, however
it is pushing The limits of the Plamp s holding capacity. It might take some ’
Experimentation to find a position that will hold. Aggressively bending
the joints of the Plamp back and forth until they start making a louder
squeaking noise will temporarily increase the holding power of the Plamp.
For diffusers larger than in diameter we suggest using Two Plamps. 20”
(Two Ground Plamps or a Ground Plamp and a Plamp II
clamped to the Ground Plamp)
Please visit our site for more in depth information -
about the Ground Plamp including a video tutorial.
www.tripodhead.com/products/ground plamp.cfm-
Video Available
30” Reflector
Plamp II
12” Reflector
Plamp II
24” Reflector
Extension Tube
Ground Plamp
Steady wind blown -
plants for ambient light
photography
Move your subject into the
desired position for lighting
Hold reflectors, diffusers, small
lighting units or shades to prevent
lens flares
Change the orientation of your
subject to make an impossible
camera angle into an easy one
Move your subject to isolate it
from distracting background or
foreground elements
Move distracting background
or foreground elements out
of the way
