Side 1/2

Wimberley, Inc. - - - Phone: 1 434 529 8385

1750 Broadway St Toll Free: 1 2746 -888-665-(USA & Canada)

Charlottesville, VA

22902 USA www.tripodhead.com info@tripodhead.com

Dimensions (coiled-up): (L x W x H): in 9” x x 8” 1.5”

Maximum extended length: 23 inches

Weight: 7.9 oz (224g)

Extending the reach of your Plamp II

If you need more reach one option is to attach the Plamp II to an object other than your own

tripod. Another option is to extend the length of your Plamp by adding extra links to its arm.

We sell a long extension (part # PP 222). The trade off to adding extra length to your Plamp 12” - -

is that it becomes less rigid.

Package Contents: The Plamp II (Qty 1)

Tips and Tricks

PP- 222

12” Plamp II Extension ($8.00)

5 Year Warranty – See www.tripodhead.com/warranty.cfm for complete details

Reconnecting the ball and socket joints of your Plamp- -

If the articulating arm is bent forcefully beyond its normal range of motion, it is

possible for the segments to pop out of joint. Fixing this is simply a matter of

popping the segments back together. If you have a hard time reconnecting the

joints (we realize it takes quite a bit of force), you can warm the socket (female)

end in hot water (boiling or near boiling). This will cause the socket to expand -

and make it easier to pop the ball portion into place.

Camera Generated Vibrations

If your Plamp is secured to your cameras tripod, it is

possible for vibrations from mirror slap to travel through

the Plamp to your subject, negatively affecting image

sharpness. This issue is magnified when you add the

12” extension to the plamp.

We strongly advise using mirror lock-up

(if your camera has this feature)

Alternately, you can attach the Plamp II to an object not

connected to your camera such as our plamp stake

(part# PP 300) or a second tripod.-

These vibrations are not a concern when

Holding objects that are not in the picture

(e.g. reflectors & diffusers).

Recess

p cylindrical

ch as small

and branches.

Foam Jaw Inserts

Grip delicate objects without damage.

Thumbscrew Turn the thumbscrew to open or close the jaws of the clip.

Compared to typical spring activated clips, thumbscrew activated clip jaws allow -

for more finesse when holding delicate objects, as well as much higher maximum

clamping force when desired.

The Plamp Clip

Clip Body

The clip is custom designed to hold

anything from the most delicate plant stems

to heavy reflectors and diffusers. It is made of

nearly unbreakable ST Nylon

Jaw opening band

This elastomer band puts tension on the clamp s moving ’

jaw so that it opens when you loosen the thumbscrew. It

is made of weather/UV resistant EPDM

Special notches in the clip s jaws grab the steel rim on reflectors and ’

diffusers, providing a secure, slip free attachment (applies to typical cloth-

reflectors/diffusers with steel perimeter hoop). This new feature is a drastic

improvement over other clips currently on the market.

The firm grip allows you to make precise adjustments to the angle of a reflector.

You can even hold diffusers cantilevered straight out above your subject

Important Feature

Reflector/Diffuser Notches

PP- 210

Plamp Rod Extension ($19.00)

Fine control using the Plamp Rod Extension

For extra dexterity try using the Plamp Rod Extension in con-

junction with the Ground Plamp or a Plamp II connected to a

tripod leg or Plamp Stake.

Rod Extension

Plamp II

Ground Plamp

Move desirable background or

foreground elements

into the picture.

Move distracting back-

ground or foreground

elements out of the way

Made in USA

The Plamp II PP-200

Using Reflectors and Diffusers

The Plamp II will hold reflectors and diffusers in any position without problems. 12”

20” reflectors, which are generally held in a relatively vertical position and not fully

cantilevered out, can be held and positioned confidently with a single Plamp.

20” Diffusers can be cantilevered above your subject using one Plamp, however

it is pushing The limits of the Plamp s holding capacity. It might take some ’

Experimentation to find a position that will hold. Aggressively bending

the joints of the Plamp back and forth until they start making a louder

squeaking noise will temporarily increase the holding power of the Plamp.

For diffusers larger than in diameter we suggest using Two Plamps. 20”

(Two Ground Plamps or a Ground Plamp and a Plamp II

clamped to the Ground Plamp)

Please visit our site for more in depth information -

about the Plamp II including a video tutorial.

www.tripodhead.com/products/plamp main.cfm-

Video Available

30” Reflector

Ground Plamp

About the Plamp II

The Plamp II is an articulating arm used to hold macro subjects and other useful objects. The large black clamp on one

end attaches to your tripod leg, Plamp Stake, or any other suitable solid object. While the other end (with the small clip)

grasps the object you wish to hold.

12” Reflector

24” Reflector

Extension Tube

Ground Plamp

Steady wind blown -

plants for ambient light

photography

Move your subject into the

desired position for lighting

Hold reflectors, diffusers, small

lighting units or shades to prevent

lens flares

Change the orientation of your

subject to make an impossible

camera angle into an easy one

Move your subject to isolate it

from distracting background or

foreground elements

Move distracting background

or foreground elements out

of the way

Plamp Stake

Ground Plamp
