SIZE: Adjusts the “size” of the

cymbal engine. Increasing this pa-

rameter will increase decay time

while also affecting the frequency

response of the decay.

DECAY: Crucible’s cymbal mod-

el contains no envelopes or

VCA’s! The DECAY paramter is

acheived by applying a frequency

independent damping constant

to the engine. Turn clockwise to

decrease the amount of damping

applied resulting in longer more

natural decay times.

TONE: Applies frequency de-

pendent damping to the engine.

Turning clockwise will result in a

“brighter” sound.

INPUT: Skip the exciter and inject

audio directly into the EDGE of the

engine. INPUT is parallel to the ex-

citer, so feel free to use them side

by side.

PITCH: Adjusts the “pitch” and

overall spectrum of the engine.

MODEL: ( ) models a curved

plate with a hole in the center,

approximating a cymbal.

( ) is similar to the last

model with amplitude dependent

“ghost transients.”

( ) removes the center hole

from the model and extends pa-

rameter ranges, giving an entirely

new response and feel.

DEFORM: Adjusts the “thickness”

of the modeled cymbal. Increasing

deform will “thin” the model mak-

ing it more “crashy.”

VELOCITY: Modify the velocity of the

exciter.

CRUCIBLE

CURVED PLATE AND CY

The status of these two jacks deter-

mines where the exciter will strike the

engine. A trigger on EDGE or MID will

apply the exciter to the respective posi-

tion. A simultaneous trigger on both, or

a gate on one and a trigger on the other

will excite the “BELL” of the engine.

EXCITE: Adjust the material and

strike angle of the stick. The stick

sound is brightest at the full CCW

position, approximating a ny-

lon tipped drum stick. Increasing

this parameter moves toward a

wood tip. Approaching the full

CW position ﬂattens the attack

angle causing an larger impact

area between the stick and the

engine. This excites more of the

engine expanding the output fre-

quency spectrum, and increasing

amplitude.

CHOKE: Gate input that applies

strong damping to the engine,

causing it to decay immediately.

A minimum damp time is applied

when a trigger is received. Longer

gates will continue to damp the

engine.

Size: 8hp

Depth: 30mm (with cables)

Power: +61mA, -17mA

Audio Input:

100k ohm impedance

20Vpp range

All CV Inputs:

100k ohm impedance

CV inputs sum with knobs. Full sweep is 5V

Gate Inputs:

100k ohm impedance

2V threshold Schmitt Trigger

Audio Output:

220 ohm impedance

20Vpp range

4.0ms latency max

SPECSINTRODUCTION

Can a realistic cymbal sound be synthesized? Can a model be

developed that actually sounds and behaves like a real cymbal?

These are the questions we had to ask ourselves when we set out

to make our next drum module. After many prototypes and a little

serendipity we present Crucible. A true synthesizer that behaves

and sounds like a real cymbal, while offering the otherworldly

ﬂexibility that can only be acheived with a synthesis model.

Crucible doesn’t contain any samples. Every sound it produces

is fully synthesized in real time. Behind the scenes, common digital

synthesis functions like delay lines and digital ﬁlters are arranged

to form an engine that provides the user with separate “Exciter”

and “Model” synthesis blocks. This means Crucible’s settings

approximate the parameters of an actual stick and cymbal making

both classic and experimental programming intuitive and rewarding.

Recreate the sizzle and swell of your favorite kit cymbal then run

your whole mix into the audio input and head into unexplored

territories.
