CUTOFF FREQUENCY CONTROL

Use this control to change the cuto frequency of the lter. The spectral content of the input

signal is reduced as this control travels from maximum to minimum in a counter-clockwise

direction.

RESONANCE CONTROL

Use this control to the input signal with respect to the cuto frequency. When set resonate

to the maximum position, the lter will begin to self oscillate sine wave and can be used as a

Voltage Controlled Oscillator (VCO).

POLE-ZERO is a 4-pole (24dB/octave) low pass Voltage Controlled Filter (VCF) utilizing MOSFET

transistors. MOSFETs are known for their soft, vacuum tube like distortion when overdriven.

POLE-ZERO is designed to exploit these characteristics with the addition of a MOSFET saturation

control and provide a much wider palette of sounds when compared to a standard VCF. A

Voltage Controlled Amplier (VCA) is a relatively novel addition and also provides a simple way

to amplitude modulate the lter without the need of an external VCA.

FM CV INPUT

This input is for frequency modulating the CUTOFF of the lter with bipolar or unipolar

control voltage. Signals applied to this input are processed through the FM LEVEL

polarizing attenuator. The signal applied here will also sum together with a signal

patched into the 1V/OCT scaled (SFM) input.

FM LEVEL LED

Indicates the cuto level position as aected by the CUTOFF control and FM input.

AMPLIFIER STATUS LED

Indicates the amplitude level of the input signal as aected by the AMP CV input.

OUT

PANEL CONTROL

LED INDICATOR

INPUT

OUTPUT

COLOR KEY LEGEND

SFM

SIGNAL INPUT

This is the input to the lter. The signal passes through the amplier and saturater,

then through the lter section and to the output (OUT).

AMPLIFIER CV INPUT

Use this input to voltage control the amplitude of the signal. For normal

operation, a signal is not required to be present at this input. Patching a

positive polarity control voltage into AMP CV will cause the amplitude to

follow the level of the control voltage (CV). Use 8 to 10 volt control

voltages for nominal signal output level.

OUT

LOW PASS OUTPUT

Output of the saturater and lter.

AMP

SATURATION CONTROL

Use this control to add warm, fat MOSFET saturation to the input signal, which

increases the harmonic content and boosts the bottom end for . maximum bass

FM POLARIZING ATTENUATOR

This control aects the level of control voltage (CV) applied to the FM input. This

control is capable of attenuating inverting the CV level as well as the polarity.

Center position (0) turns the CV level o.

Maximum position (+) results in the full, normal signal.

Minimum position (-) results in the full, inverted signal.

SFM

1V/OCT SCALED FM CV INPUT

This input is for frequency modulating the CUTOFF of the lter with bipolar or unipolar

control voltage. This FM input is used for precisely tracking the lter when a keyboard

or other controller is used and/or when the lter is used as a sine wave VCO. The signal

applied here will also sum together with a signal patched into the FM CV input.

AMP

OUT

SFM

+ +

LOW PASS

AMP

LEVEL

SIGNAL PATH DIAGRAM

= SUM
