Wyrestorm NetworkHD™ 200-Series HD Over IP
Encoder and Decoders for video wall
NHD-200 Series
WyreStorm® NetworkHD 200 is our agship H.264 HD over IP distribution platform. With its simple system conguration and
powerful video wall functionality it is the best all round solution for commercial AV installs. Enabling the distribution of multiple
video formats over a dedicated IP network switch for commercial AV applications.
NetworkHD 200 series facilitates the transmission of an HDMI, DVI, Component & VGA signals (including Full HD 1080p video with
2.1 audio) to any number of HDMI displays over standard Ethernet (Cat5e/6) infrastructure. The NHD-200-RX enables the display
of a single image on a display whilst the NHD-210-RX decoder adds video wall playback to the system.
WYRESTORM PRODUCT SPECIFICATION SHEET
Highly scalable, visually lossless HD over IP solution using the most ecient compression
technology to allow for very large commercial AV deployments
Powerful video wall functionality (NHD-210-RX only) up to 4 x 4 displays.
Multi-format DVI-I input selectable to HDMI, DVI, Component, VGA & Composite input
Plug and Play setup with automatic networking conguration and auto discovery of components
Quick SyncTM technology for virtually instantaneous, seamless switching
CEC One-Touch Play & Standby or RS232 control of connected displays
Key Features:
Additional Features & Benefits:
Supports video previewing on a PC or third party device.
NetworkHD 100 outputs simultaneous IP streams. One full
resolution for the NHD-100-RX. The other small one supports
resolutions of 352 x 288 @ 5Hz to easily preview a video from
the encoder on a PC or Mac
Use with the new NHD-000-CTL controller for simple
conguration and control via the LAN, as well as for allowing
control from third party control system such as AMX, Crestron,
Control4, RTI & WyreStormTM Enado.
Supports PoE to enable remote powering from POE network
switches, eliminating the need for a nearby power outlet
Full PC control suite available free of charge at wyrestorm.com
Supports HDCP
Audio Breakout on both Encoder & Decoder
Congurable encoding bit rate up to 40 Mbps
NHD-000-CTL
1 x NHD-000-CTL Main Unit
1 x Power Adapter (12V 1A DC)
1 x Phoenix Conn.
(Male, 3.5 mm, 3 pins)
2 x Mounting Brackets
5 x IP labels
NHD-200-TX
1 x NHD-200-TX Main Unit
1 x Power Adapter (12V 1A DC)
1 x Detachable Plug
1 x HDMI to DVI Converter
2 x Phoenix Conn.
(Male, 3.5 mm, 3 pins)
2 x Mounting Brackets
NHD-200-RX
1 x NHD-200-RX Main Unit
1 x Power Adapter (12V 1A DC)
1 x Detachable Plug
3 x Phoenix Conn.
(Male, 3.5 mm, 3 pins)
2 x Mounting Brackets
NHD-210-RX
1 x NHD-210-RX Main Unit
1 x Power Adapter (12V 1A DC)
1 x Detachable Plug
3 x Phoenix Conn.
(Male, 3.5 mm, 3 pins)
2 x Mounting Brackets
in the box
US OFFICE:
TEL: +1 518-289-1293
EMEA OFFICE:
TEL: + 44 (0) 1793 230 343
WYRESTORM PRODUCT SPECIFICATION SHEET
Specifications NHD-200-TX
Input Video Ports 1 × DVI IN
Input Video Type HDMI 1.3, DVI 1.0, VGA, YPbPr
Input Video Resolutions HDMI: 640 x 480 @ 60Hz, 480p @ 60Hz, 576p @ 50Hz,
800 x 600 @ 60Hz, 1024 x 768 @ 60Hz, 720p @ 50Hz, 720p @ 60Hz,
1280 x 800 @ 60Hz, 1280 x 1024 @ 60Hz, 1360 x 768 @ 60Hz,
1366 x 768 @ 60Hz, 1400 x 1050 @ 60Hz, 1440 x 900 @60Hz,
1680 x 1050 @ 60Hz, 1080p @ 24Hz, 1080p @ 25Hz, 1080p @ 30Hz,
1080p @ 50Hz, 1080p @ 60Hz, 1920 x 1200 @ 60Hz
DVI: 640 x 480 @ 60Hz, 480p @ 60Hz, 576P @ 50Hz, 800 x 600 @ 60Hz,
1024 x 768 @ 60Hz, 720p @ 50Hz, 720p @ 60Hz, 1280 x 800 @ 60Hz,
1280 x 1024 @ 60Hz, 1360 x 768 @ 60Hz, 1366 x 768 @ 60Hz,
1400 x 1050 @ 60Hz, 1440 x 900 @ 60Hz, 1680 x 1050 @ 60Hz,
1080p @ 24Hz, 1080p @ 25Hz, 1080p @ 30Hz, 1080p @ 50Hz, 1080p @ 60Hz,
1920 x 1200 @ 60Hz
VGA: 640 x 480 @ 60Hz, 800 x 600 @ 60Hz, 1024 x 768 @ 60Hz, 1280 x 1024 @ 60Hz,
1280 x 720 @ 60Hz, 1280 x 768 @ 60Hz, 1280 x 800 @ 60Hz, 1360 x 768 @ 60Hz,
1366 x 768 @ 60Hz, 1440 x 900 @ 60Hz, 1400 x 1050 @ 60Hz,
1680 x 1050 @ 60Hz, 1920 x 1080 @ 60Hz, 1920 x 1200 @ 60Hz
Component: 720 x 480p @ 60Hz, 720 x 576p @ 50Hz, 1280 x 720p @ 50Hz,
1280 x 720p @ 60Hz
Input Video Signal 0.5 ~ 1.2 V p-p
Encoding Data Rate Up to 40 Mbps, congurable
Output Video Ports 1 x LAN
Output Video Type H.264/MPEG-4 AVC
Output Video Resolutions Large IP stream: 480p @ 60Hz ~ 1920 x 1200 @ 60Hz, Small IP stream: 352 x 288 @ 5Hz
Video Impedance 100
Input DDC Signal 5 V p-p (TTL)
End-to-End Time Latency About 60 ms-90 ms (Low latency mode), About 250 ms-300 ms (High quality mode)
Input Audio Ports 1 x Audio Jack
Input Audio Format Stereo
Output Audio Ports 1 x Phoenix Connector
Output Audio Format Stereo
Control Method Rear panel source switch, PC congurator and RS232
Operating Temperature +32°F ~ +113°F (0°C ~ +45°C) 10% ~ 90%, non-condensing
Storage Temperature -4°F ~ 140°F (-20°C ~ +70°C) 10% ~ 90%, non-condensing
Power 12V 1A DC
Power Consumption 6W (Max.)
ESD Protection Human body model: ±8kV (air-gap discharge) ±4kV (contact discharge)
Surge Protection Voltage ±1 kV
Product Dimensions (WxHxD) 200mm x 25 mm x 94mm / 7.9’’ x 1.0’’ x 3.7’
Weight 0.48 Kg
Certication CE, FCC, RoHS compliant
For additional product information visit wyrestorm.com
For technical support contact: North America: 1 844-280-WYRE (9973) EMEA/ROW: +44 (0) 1793 230 343 +
