Side 1/36
1
Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343
Thank you for choosing this WyreStorm product.
Please read these instructions carefully before installing to avoid complications later.
WyreStorm Pro Plus PoH HDBaseT Solutions
MX-0808-PP-POH MX-0808-PP-POH-Custom
Fixed Pro Plus chassis featuring PoH
HDBaseT out, mirrored HDMI out, HDMI in, IR
input transmission card.
Modular Pro Plus chassis with selection
of customisable analogue and digital PoH
transmission cards.
Instruction Manual
2
Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343
Contents
1. Introduction
CONTENTS AND INTRODUCTION
The WyreStorm MX-PP-POH matrix range oers the
ultimate in exible and aordable Class B HDBaseT™
integration; for projects that demand the benets
of HDBaseT transmission, such as signal stability,
distribution of full 1080p HD video, HD audio, Power-over-
HDBaseT (PoH) and control via IR and routable serial
control over a single Cat5e/6 cable up to 70m/230ft, yet
may not require the transmission distance or feature set
of full Class A HDBaseT.
Models in the MX-PP-POH range offer an HDBaseT Pro Plus
matrix solution with PoH support for power passed along a
single Cat5e/6/7 cable along with transmissions and control
commands to enable receivers to operate without the need for
local mains power at display zones.
This not only offers more exibility and convenience during
installation but also greater energy efciency and an easier
installation than a permanent mains connection as less power
supplies are required for devices.
MX-PP-POH matrices also feature routable serial commands
via RS232 for individual screen control in display zones using
a WyreStorm Enado or third party control system – all of which
adds up to a powerful package for applications of any size or
budget.
MX-PP-POH matrices are available either in factory standard
conguration, featuring HDMI input to HDBaseT and mirrored
HDMI Output, or a modular customisable conguration featuring
a matrix chassis and selection from a range of multi-format
digital and analogue transmission cards that enable distribution
and control to be tailored to the specics of the project like
never before.
Using our Virtual Rack system-planner available at
www.wyrestom.com, combinations of matrices and
transmission cards can be selected and customised to personal
specication, with orders submitted online, custom-built and
shipped directly within 10 days from initial spec to nal delivery.*
MX-PP-POH matrix solutions from WyreStorm offer incredible
exibility and versatility of custom transmission selection
combined with the power and features of HDBaseT for solutions
where stable HD transmission and control over distance is
required, whether in a residential or commercial setting.
For further information on this product and other WyreStorm
ranges, visit our website or download our latest product guide.
www.wyrestom.com
*Subject to stock availability
Introduction
Features
Safety Precautions
Package Contents
Front Panel Description
i. Rear Panel Description - MX-0808-PP-POH
ii. Rear Panel Description -MX-0808-PP-POH-CUSTOM
Card Options
i. Typical Application - TX-POH-010 Transmission Card
ii. Typical Application - All Cards
Connection
Basic Operation
Basic Remote Control
Advanced Remote Control
Advanced Operation
RS232 Application Scenarios - Understanding
RS232 Connection & Signals
Routable RS232 with MX-PP-POH
Routing Serial Commands from the MX-PP-POH
QuickSync Setting
EDID Management - About EDID
Before EDID Adjustments
EDID Presets
COM CTL
Troubleshooting
FAQ
Maintenance
Provided Service
Mail In Service
i. Warranty
ii. Warranty Limits and Exclusions
i. Installation Reference Log - Input Reference Log
ii. Installation Reference Log - Output Reference Log
Specication
1
2
3
4
5
6
7
8
9
10
11
13
14
15
16
17
19
20
21
18
12
22
23
24
25
26
27
28
