iMPuLSE inTEGraTOr
SYnTH uTiLiTY MODuLE
MODEL OF 1981
PrODuCT fEaTurES
TECHniCaL DETaiLS
• 3independenttrigger/gate
4:1combinersections(ORgate)
• eachcombinersectioncanbe
• basicCVsumming
• backwardpowerprotection
• eurorackstandardsynthesizer
module,fullyDoepfercompatible
• 6hpwide
• +12/-12Vpowered
• currentdraw:10mA
THE MODuLE EXPLainED
ViSiT fOr uPDaTES, ManuaLS, TuTOriaLS anD ParaPHrEnaLiaXAOCDEVICES.COM
SaLuT
Thankyouforpurchasing
thisXAOCDevicesproduct.
Bytomisasimpleyetex-
tremelyusefulutilitymodule
thathelpsyoutoworkwith
controlvoltagesinyour
system,combiningvarious
trigger/gatesignalsources
inordertoobtaininterest-
ingrhythmiceventsuseful
forsequencing,modulation
andpatch“automation”
purposes.
inSTaLLaTiOn
Unplugyourmodularsystem
fromthepowersourcerst.
Cleara6hpspaceinyour
eurorackcabinet,andplug
thepowerconnectorintothe
busboardsotheredband
pointsrighttowardsthe
–12Vrail(usuallythelower
one).Althoughthemoduleis
protectedagainstbackwards
powerconnections,itis
alwaysagoodhabittopay
attentiontothis.Tightenthe
suppliedmountingscrews
andyou’rereadytogo.
COnTrOLS & OPEraTiOn
Bytomisatriplegateand
triggersignalcombiner(OR
gate)thatconsistsofthreein-
dependentsections.Eachone
canprocessuptofoursignals
fedtoinputsockets
1
.
ThecorrespondingLED
3
willlightupeverytimethe
statusofthegate/triggeron
theoutput
2
ishigh.
Allthreesectionscanbe
normalizedintoone12-signal
combinationviathemanual
switches
4
,alsotheupperor
lowersectionscanbecom-
binedwiththemiddlesection
toforman8-signalcombina-
tion.Summedsignalsoftwo
orthreesectionswillappear
onthemiddlesection’soutput
socket
5
.
Theindividualouts
2

onupperandlowerunits
remainactiveevenwhen
combinedwiththemiddle
section.
Lastbutnotleast,Bytomcan
bealsousedforsumming
positivecontrolvoltages.
On OFF
On OFF
1
1
1
4
4
TRIGGER/GATE COMBINER C TRIGGER/GATE COMBINER B TRIGGER/GATE COMBINER A
3
2
3
2
3
5
WARRANTY INFORMATION•XaOC DEViCES WarranTS THiS PrODuCT TO BE frEE frOM anY COnSTruCTiOn DEfECTS fOr OnE
YEar frOM THE DaTE Of PurCHaSE. DurinG THaT PEriOD anY MaLfunCTiOninG uniTS WiLL BE rEPairED, SErViCED anD CaLiBraTED WiTH
CuSTOMEr COVErinG uP THE aPPrOPriaTE TranSiT fEES•WarranTY DOES nOT COVEr anY PrOBLEMS rESuLTinG frOM THE inCOrrECT
inSTaLLaTiOn Or VOLTaGE SuPPLiED, aBuSiVE TrEaTMEnT Or anY OTHEr OBViOuS uSEr-infLiCTED fauLT•WE arE STiLL HaPPY TO HELP
afTEr THE WarranTY PEriOD, HOWEVEr WE rESErVE THE riGHT TO CHarGE fOr LaBOr, rEPLaCEMEnT ParTS anD TranSiT•in CaSE
Of anY PrOBLEM PLEaSE COnTaCT uS iMMEDiaTELY: infO@XaOCDEViCES.COM• •THE MiGHTY Muff WiGGLErS, uLf XAOC SALUTES
LunDBLaD, CLarKE rOBinSOn, HEnriK n. BjOrKK, PauL SCHuLZ, CODY GarrETT-TaiT, MODuLarnE.infO & COMraDES WOrLDWiDE•aLL
riGHTS rESErVED © 2012 XaOC DEViCES•ManufaCTurEr rESErVES THE riGHT TO CHanGE SPECifiCaTiOnS aT anY TiME•MaDE in EurOPE
