Side 1/8

voltage

controlled

dsp effektor

Model of 1970

operator’s manual rev. 1970/1.2

TIMISZOARA

SALUT

Thank you for purchasing this Xaoc Devices

product. Timiszoara is a stereo-

phonic, Eurorack compatible, voltage-con-

trolled multi-effect signal processor based

on the popular Spin Semiconductor FV-1

DSP chip. It features a full stereo signal path

with two adjustable audio inputs, two out-

puts, and a stereo voltage-controlled wet/

dry mixer. In addition, there is a microSD

memory card slot on the front panel that al-

lows for loading factory and custom effects

without any restrictions or copyright protec-

tion, which means you can use many effects

available on the Internet and even create

your own.

Effect programs are organized in of banks

8 and can be selected using a rotary encoder,

as well as CV and trigger signals. Timiszoara

features a crisp OLED screen that displays the

program parameters and its name. It also

facilitates navigating the list of banks. Up to

three parameters per effect can be controlled

from the front panel with illuminated slider po-

tentiometers and dedicated CV inputs.

INSTALLATION

The module requires 10hp worth of free space

in the Eurorack cabinet. Always turn the pow-

er off before plugging the module to the bus



paying close attention to power cable pinout

and orientation. The red stripe indicates the

negative rail and should match the –12v

mark on the bus board and the unit. Timiszo-

ara is internally secured against reversed

    

pin header may cause serious damage to

other components of your system because

it will short circuit the +12V and +5V power

lines. Always pay particularly close attention

to the proper orientation of your ribbon cable

on both sides! note: There is a second, 10-pin

header at the back of the module for connect-

ing an expander. do not plug power into

this header, as it will destroy your

module!

The module should be fastened by mounting

the supplied screws before powering up. To

better understand the device, we strongly ad-

vise the user to read through the entire man-

ual before use.

MODULE OVERVIEW



1. The OLED screen

and the single rotary

encoder

allow easy navigation between

the effect programs organized into banks

of 8. The banks are loaded from the microSD

memory card inserted into the slot

. During

normal operation, the screen displays the

name of the current effect and the names of

its three parameters.

Two inputs below the rotary encoder allow

for remote changing of the programs within

the bank: using continuous CV plugged to the

scan input

and using trigger impulses via

the next input

The left

and right

signal inputs

are associated with individual attenuators

and

used for adjusting the input level.

module

explained
