Side 1/8

stereo vc

frequency

shiftor

Model of 1964

operator’s manual rev. 1964/1.1ę

KOSZALIN

SALUT

Thank you for purchasing this Xaoc Devices

product. Koszalin is a stereo fre-

      

quasi-exponential and linear frequency mod-

ulation as well as full stereo feedback under

voltage control. Frequency shifting results in

a linear translation of the signal spectrum,

which produces a variety of atonal sounds. It

should not be confused with frequency scal-

ing, also known as pitch shifting. Complex

phase cancellation patterns occurring with

frequency shifting and deep feedback pro-

duce spectacular barber-pole effects.

Koszalin offers direct controls over feedback

amount, feedback routing, and feedback re-

sponse. It also facilitates frequency modula-

tion of any stereo audio signal, thanks to the

linear TZFM input. Koszalin is a digital mod-



INSTALLATION

The module requires 10hp worth of free space

in the Eurorack cabinet. Always turn the

power off before plugging the module into

the bus board using the supplied 16-pin/16-

pin ribbon cable, paying close attention to

power cable pinout and orientation. The red

stripe indicates the negative rail and should

match the –12v mark on the bus board and

the unit. Koszalin is internally secured against

    -

ping the 16-pin header may cause serious

damage to other components of your system

because it will short circuit the +12V and +5V

power lines. Always pay particularly close at-

tention to the proper orientation of your rib-

bon cable on both sides!

The module should be fastened by mounting

the supplied screws before powering up. To

better understand the device and avoid com-

mon pitfalls, we strongly advise the user to

read through the entire manual before use.

MODULE OVERVIEW



shift knob

used for setting the amount

of frequency shifting applied to the input

        

bent exponentially in both directions from



In other words, the scale is stretched propor-

tionally around zero, which facilitates great-

er precision in setting a low shift amount.

Three ranges are set with the switch range

       

      -

reo input signals should be patched into the

pair of jacks input

. The input indica-

tor

shows the volume of the input using

light intensity and color, gradually changing

from green to yellow and red when the sum

exceeds 16Vpp.

Two pairs of stereo outputs are available for

independent access to the signal being shifted



shifted down

(towards lower frequencies,

including and beyond 0Hz; more on that be-

module

explained
