Side 1/6

GERA

THE LEIBNIZ BINARY SUBSYSTEM

binary

product

commander

Model of 1989

operator’s manual rev. 1989/X5/1.1

SALUT

Thank you for purchasing this Xaoc Devices

product. Gera  is a component of the

Leibniz Binary Subsystem. It works by process-

ing data in the Leibniz bus and requires a con-

nection to other Leibniz modules. It features

eight individual gate inputs that affect the cor-

responding individual bits of the Leibniz data.

Eight illuminated tact switches allow for man-

ual inverting of each gate input. The primary

function of Gera is masking individual bits of

the digital data through the AND operation.

For example, when connected to Drezno, which

is processing a waveform or voltage, masking

individual bits yields various forms of quanti-

zation. However, Gera does not need Drezno

to work. The AND operation is also a basic

building block for sequence automation, chaos

and rhythm generation, and various cybernetic

modular patches. Bit processing logic in Gera

is hardware-based; hence there is virtually no

latency, and the binary signals may change at

extreme rates.To better understand the device

and avoid common pitfalls, we strongly advise

the user to read through the entire manual

before use.

INSTALLATION

The module requires 6hp worth of free space

in the Eurorack cabinet. Always turn the pow-

er off before plugging the module into the

bus board using the supplied 10-pin ribbon

cable, paying close attention to the power

cable pinout and orientation. The red stripe

indicates the negative rail and should match

the dot or mark on the bus board as well 12V

as the unit. Gera is internally secured against

     

pin header may cause serious damage to

other components of your system because it

will short-circuit the +12V and +5V power

lines. Always pay close attention to the proper

orientation of your ribbon cable on both sides!

note: do not plug a power cable into

the leibniz headers as this will damage

your unit and may also jeopardize other

Leibniz modules connected to it!

Besides power, you need to connect Gera to

other components of your Leibniz subsystem.

Gera ships with one 10-pin ribbon data cable.

To complete the connection, use the 10-pin

cables included with your other Leibniz mod-

ules. Using the cable, connect the 10-pin un-

shrouded header labeled out to the headin -

er of your next Leibniz-compatible module

(e.g., Drezno, Jena, Erfurt, Odessa, etc.). Then

connect the incoming data from the module

preceding Gera (e.g., Ostankino, Drezno, or

Erfurt) to the 10-pin unshrouded header la-

beled . Please observe the marks of pin #1 in

(red stripe) on all connected modules. We

advise you to plan ahead as to how you wish

to incorporate Gera into your modular setup.

The module should be fastened by mounting

the supplied screws before powering up.

MODULE OVERVIEW



with other modules in the Leibniz series, Gera

features a bank of eight binary gate inputs

expecting gate signals, where an active 5V

gate signal represents a logic 1, and an inac-

module

explained
