binary phase

akkumulator

Model of 1989

operator’s manual rev. 1989/X2/1.1

ERFURT

THE LEIBNIZ BINARY SUBSYSTEM

SALUT

Thank you for purchasing this Xaoc Devices

product. Erfurt [ˈɛrfurt] is a bi-directional

digital counter, frequency divider, and a com-

ponent of our 8-bit Leibniz Binary Subsystem.

It has multiple applications: the output of the

counter may be used as a phase source driving

a digital wavetable, connected to other Leib-

niz modules it may scan waveshapes in Jena,

produce stepped voltages useful for making

interesting glissandi with Drezno and any

VCO, generate gate patterns animating the

spectrum of Odessa harmonic banks, spawn

pseudo-chaotic sequences when fed back to

Lipsk, etc.

It can also operate standalone (without other

Leibniz components), and act as an 8-output

clock and audio frequency divider.

Since Erfurt is based on CMOS logic (no CPU!),

it can be clocked at very high frequencies

(exceeding audio rate) without any aliasing

or frequency interference. It also features its

own internal HF clock source that may be

used with clockless data sources.

INSTALLATION

The module requires 6hp worth of free space

in the eurorack cabinet. Always turn the pow-

er off before plugging the module into the bus

board using the supplied ribbon cable. Pay

close attention to power cable pinout and

orientation. The red stripe indicates the neg-

ative rail and should match the dot or –12V

mark on the bus board as well as the unit.

Erfurt is internally secured against reversed

power connection, however, rotating the 16-

pin header may cause serious damage to

other components of your system, because

it will short circuit the +12V and +5V power

lines. Always pay particularly close attention

to the proper orientation of your ribbon cable

on both sides!

Besides power, you may want to connect Erfurt

to other components of your Leibniz Subsystem

(unless you intend to use it standalone). Erfurt

comes with one 10-pin ribbon data cable to

connect with other Leibniz modules alongside

any additional cables included with other mod-

ules in the subsystem. The 10-pin unshrouded

header labeled out is where you need to plug

the cable that goes to the in header of your next

Leibniz module (e.g. Drezno, Jena, or Odessa).

The incoming data from a module preceding Er-

furt (e.g. Ostankino, Drezno, Lipsk, etc.) should

be plugged into the 10-pin unshrouded header

labeled in. Please observe the marks of pin #1

(red stripe) on all connected modules. Depend-

ing on the intended use of Erfurt, these connec-

tions may not be necessary. We advise you to

plan ahead as to how you wish to incorporate

Erfurt into your modular setup.

A jumper labeled selects whether Erclk src -

furt runs with its own internal clock generator

or uses the clock signal delivered with the Leib-

niz data. Put the jumper in the int position

when there is only a static data source (e.g. Lipsk

or Ostankino), or when you don't feed Erfurt any

data via the Leibniz interface. Set the jumper to

ext when the preceding module delivers clock

alongside its data (usually changing over time),

like Drezno or Jena.

module

explained
