operator’s manual rev. 1989/X3/1.1

POCZDAM

THE LEIBNIZ BINARY SUBSYSTEM

leibniz device

komutator

Model of 1989

SALUT

Thank you for purchasing this Xaoc Devices

product. Poczdam is a binary data

routing solution for the Xaoc Leibniz Subsys-

tem. It facilitates manual and remote switch-

ing between two Leibniz data sources, mod-

ifying individual bits of the data stream, and

re-clocking the data with its onboard volt-

age–controlled wideband oscillator or any

external clock signal. Poczdam is particularly

useful within complex Leibniz setups where

-

tween multiple modules. However, it can also

be employed in small creative patches, e.g., for

waveform splicing, disrupting rhythmic loops,

or generating digital chaos.

To better understand the device and avoid

common pitfalls, we strongly advise you to

read through the entire manual before use.

INSTALLATION

The module requires 10hp worth of free space

in the Eurorack cabinet. Always turn the pow-

er off before plugging the module into the bus

board using the supplied 16-pin to 16-pin rib-

bon cable, paying close attention to power cable

pinout and orientation. The red stripe indicates

the negative rail and should match the dot or

–12V mark on the bus board as well as the unit.

Poczdam is internally secured against reversed

power connection; however, rotating the whole

16-pin header may cause serious damage

to other components of your system because it

will short circuit the +12V and +5V power lines.

Always pay close attention to the proper orien-

tation of your ribbon cable on both sides!

Besides power, you need to connect Poczdam

to other components of your Leibniz subsys-

tem. Poczdam comes with three ribbon data

cables with 10-pin plugs on both ends. Before

installing the data cables, we advise you to

read the entire manual and carefully plan

your Leibniz setup. Pay attention to the prop-

er orientation of the red stripe with pin #1

indicated by a dot or an arrow on each mod-

ule. Remember that proper data transmission

requires connecting inputs to outputs, just like

the analog signals in your modular system.

warning: make sure not to plug the eu-

rorack power into any data headers.

Doing so will destroy your Poczdam immedi-

ately and may jeopardize other Leibniz mod-

ules connected to it!

The module should be fastened by mounting

the supplied screws before powering up.

MODULE OVERVIEW

The main feature of Poczdam is switching be-

tween two data sources plugged into its two

Leibniz in ports at the back. Switching may

be done manually by pressing the illuminat-

ed button labeled source

in the upper

        

trigger/gate signal plugged into the source

select input

. The source data is selected

together with its associated clock and deliv-

ered to the Leibniz header at the back.out1

Besides , the data from the selected out1

source is also available in the bank of eight

binary incoming data outputs jacks

on the front panel. Furthermore, apart from

module

explained
