AIMB-708 Startup Manual 1

AIMB-708 LGA1700 Intel

Core™ i9/i7/i5/i3 ATX

Motherboard with HDMI/VGA, DDR4, USB 3.2, M.2

Startup Manual

Specications (Cont.) Packing List

For more information on this and other Advantech prod-

ucts, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our sup-

port website for AIMB-708 at:

http://advt.ch/aimb708spt

extra warranty for free at:

http://www.register.advantech.com

This manual is for the AIMB-708 series Rev. A1, and all

specications are subject to the data-sheet on the o󰀩cial

website. The information in this manual is subject to

change without notice.

Part No. 2041070801

Printed in China

2nd Edition

March 2023

• M.2 socket: One M.2 socket supports up to PCIe p1-x2 Gen

3 M-Key 2280 type storage devices (G2 SKU only).

• SATA interface: Four on-board Serial ATA 3.0 connectors

support data transmission rates up to 600 MB/s. All four

SATA 3.0 ports support Advanced Host Controller Inter-

face (AHCI) technology.

• PCIe and PCI slots: 1 PCIe p1-x16 Gen 4 expansion slot, 2

PCIe p1-x4 expansion slots (x2 Gen 3 link), 4 PCI slots 32-

bit/33 MHz PCI 2.2 compliant.

• USB 3.2/2.0:

- G2 SKU: 4 USB 3.2 Gen 1 ports on the rear with up to

5 Gb/s data rate, 6 USB 2.0 ports (2 rear, 2 via header, 2

internal Type-A)

- VG SKU: 2 USB 3.2 Gen 1 ports on the rear with up to

5 Gb/s data rate, 5 USB 2.0 ports (2 rear, 2 via header, 1

internal Type-A)

• Serial port: Up to 6 serial ports: COMD1 and COM4 ~ 6

are RS-232; COM3 is RS-232/422/485 with jumper and

BIOS menu options.

• SPI interface: Advantech-designed SPI connector sup-

ports optional dTPM 2.0 module.

• Watchdog timer: 255 timer level intervals.

Graphics Interface

• Chipset: CPU integrated graphics controller.

• Display memory: 1 GB maximum shared memory with 2

GB and above system memory installed.

• HDMI (G2 SKU only): Resolution up to 3840 x 2160 @

30 Hz refresh rate.

• VGA: Resolution up to 1920 x 1200 @ 60 Hz refresh rate.

Ethernet Interface

• Interface:

- LAN1: 10/100/1000 Mbps

- LAN2: 10/100/1000/2500 Mbps (G2 SKU only)

• Controller:

- LAN1: Intel

I219-V

- LAN2: Intel

I226-V (G2 SKU only)

Mechanical and Environmental

• Dimensions (L x W): 304.8 x 244 mm (12" x 9.6")

• Power consumption: Intel® Core™ i 65W; DDR4 32 GB x 2

Maximum: +3.3V at 3.06A, +5V at 8.17A, +12V at 0.84A,

+5V

at 0.05A, -12V at 0.03A, -5V at 0.01A

• Operating temperature: 0 ~ 60 °C (depending on CPU load

ing and thermal solution)

• Weight of board: 0.7 kg (1.54 lb)

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 x AIMB-708 motherboard

• 1 x AIMB-708 Startup Manual

• 2 x Serial ATA HDD data cables

• 1 x I/O port bracket

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Standard Functions

• CPU: LGA1700 socket supporting 12th/13th Gen Intel

Core™ i9/i7/i5/i3/Pentium

/Celeron

processors.

• BIOS: AMI 256 Mbit SPI BIOS

• Chipset: Intel

H610E PCH

Note: Legacy platforms are not supported.

• System memory: Up to 64 GB in two 288-pin DIMM

sockets, supporting dual-channel DDR4 3200 SDRAM.

AIMB-708 supports non-ECC unbu󰀨ered DIMMs and

does not support any memory conguration that mixes

non-ECC with ECC unbu󰀨ered DIMMs.

Specications

2 AIMB-708 Startup Manual

The board has a number of jumpers that allow you to con-

gure your system to suit your application. The table below

lists the function of each jumper and connector.

Connector/Jumper List

Label Function

ATX12V1+ATX12V2

ATX 12 V auxiliary power connec-

tor (for CPU)

AUDIO1+AUDIO2 Audio connector (Line Out, Mic In)

COM4 ~ COM6

Serial port: RS-232 (9-pin header,

G2 SKU only)

COM3

Serial port: RS-232/422/485 (9-

pin header, G2 SKU only)

COMD1

Serial port: RS-232 (DB-9 con-

nector) *2

CPUFAN1 CPU fan connector (4-pin)

DIMMA1 Channel A DIMM1

DIMMB1 Channel B DIMM1

EATXPWR1

ATX 24-pin main power connector

(for system)

FPAUD1 Front panel audio connector

GPIO1 8-bit GPIO from super I/O

HDMI1 HDMI connector (G2 SKU only)

JCASE1 Case open connector

JCMOS1 CMOS clear data

JFP1 Power switch/reset connector

JFP2

External speaker/HDD LED con-

nector/SMBus connector

JFP3

Power LED

Suspend: fast ash (ATX/AT)

System on: on (ATX/AT)

System o󰀨: o󰀨 (ATX/AT)

JFV1 VGA dummy load setting

JME1 Intel® ME update

JPCICLK1 PCI clock selection

JR1+JT1

COM3 RS-422/485 termination

resistor

JSETCOM3

COM3 RS-232/422/485 jumper

setting

JUSB1

External USB power source

switch

JUSB2 Internal USB power source switch

JWDT1+JOBS1

Watchdog timer output and OBS

alarm

LAN1 GbE LAN

LAN2 GbE LAN (G2 SKU only)

LANLED1

Front panel LAN indicator con-

nector

NVME1

M.2 2280 M-Key socket (G2 KU

only)

PCI1 ~ PCI4 PCI slot

PCIE1 PCIe x16 slot (x16 Gen 4 link)

PCIE2 ~ PCIE3 PCIe p2-x4 slot (x2 Gen 3 link)

PSON1 ATX/AT mode selection

SATA4 ~ SATA7 Serial ATA 3.0 port

SMB1 ~ SMB2

PCIe SMBus connection setting

for PCIE2 ~ PCIE3 slot

SMB3 ~ SMB4

PCIe SMBus connection setting

for PCIE1 slot

SMBUS1 SMBus connector from PCH

SPDIF_OUT1 SPDIF audio out pin header

SPI_TPM1

SPI (Serial Peripheral Interface)

connector for Advantech dTPM

2.0 module.

SYSFAN1 ~ SYS-

FAN3

System fan connector (4-pin)

USB2A1 USB 2.0 port (internal Type-A)

USB2A2

USB 2.0 port (internal Type-A, G2

SKU only)

USB2C1 USB 2.0 port *2

USB2H1 2 x USB 2.0 port (10-pin header)

USB3C1

USB 3.2 Gen 1 port *2 (G2 SKU

only)

USB3C2 USB 3.2 Gen 1 port *2

VGA1 VGA connector

VOLT1 Alarm board power connector

Note The PCIE1 slot can only support graphics cards

and storage cards according to the specication

recommended by Intel. Other types of add-on

cards might not work properly. For the compat-

ible device list validated on the PCIe x16 slot,

please refer to the user manual.

JCMOS1: CMOS clear data

JME1: Intel® ME update

Closed Pins Result

1-2 *Keep CMOS data

*Enable ME update

2-3

Clear CMOS data

Disable ME update

* Default

*Keep CMOS data Clear CMOS data

*Enable ME update Disable ME update

123

Jumpers and Connectors

Jumpers and Connectors (Cont.)
