Side 1/4

ASMB-586 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 Startup manual

• 2 Serial ATA HDD data cables

• 2 Serial ATA HDD power cables

• 1 COM cable (for connection to real panel)

• 1 I/O port bracket

• 1 Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF

le.AcrobatReadercanbedownloadedat:

http://www.adobe.com/downloads/ (Acrobat is a

trademark of Adobe)

ASMB-586 LGA 1151 Intel® Xeon® E and 8th/9th Core™

MicroATX Server Board with 4 x DDR4, 4 x PCIe,

6 x USB 3.1, 8 x SATA3, Quad/Dual LANs, IPMI

Startup Manual

Standard Functions

• CPU: Intel LGA1151 Xeon E-21xx/22xx and 8th/9th Gen

Core i3/i5/i7 series processors

• BIOS: AMI 256 Mb SPI BIOS

• Chipset: Intel C246

• System Memory: Dual channel DDR4 ECC/Non-ECC

2666/2400/2133MHzunbu󰀨eredDIMM,Max.128GB

Note: Due to the inherent limitations of the PC archi-

tecture, the system may not fully detect 128 GB

RAM when 128 GB RAM is installed.

• SATA3 Interface: 8 x SATA3 6Gb/s ports to support Intel

Rapid Storage Technology Enterprise with software RAID

0, 1, 10 & 5. (for Windows only)

• Serial ports: Two serial ports onboard, only supports RS-

232 (one can be in rear IO via COM cable connection)

• Keyboard/Mouse connector: Supports standard PS/2

keyboard and mouse via KMBS1 pin header.

• Watchdog timer: 255 level timer intervals (sec/min)

• USB 3.1: Supports up to six USB 3.1 ports, four Gen2

ports in rear I/O and two Gen1 ports from on-board pin

header

• USB 2.0: Supports up to seven USB 2.0 ports (1* Type-A)

Display Interface

• Chipset: CPU integrated Intel HD graphics controller

• Display Memory: 1 GB maximum shared memory with

2 GB and above system memory installed (BIOS default

is 256MB)

• Resolution:

- Supports VGA up to 1920 x 1200 resolution @ 60 Hz

refresh rate

- Supports DVI up to 1920 x 1200 resolution@ 60 Hz

refresh rate

- Supports HDMI 2.0 up to 2K/4K resolution @ 60Hz

Ethernet Interface

• Interface: 10/100/1000 Mbps

• Controller: LAN1:Intel

I219LM; LAN2 ~ LAN4: Intel®

I210AT (LAN2 is BMC shared NIC; LAN3/4 is for G4 SKU

only)

Mechanical and Environmental

• Dimensions (L x W): 244 x 244 mm (9.6” x 9.6”)

• Power supply voltage: +3.3 V, +5 V, ±12 V, 5 Vsb

• Power consumption: Max. load: +3.3 V @ 3.87 A, +5 V

@ 4.11 A, +12 V @ 0.63 A, +12 V (8P) @ 6.28 A, +5 Vsb

@ 0.09 A

• Operating temperature: 0 ~ 60° C (Depends on CPU

speed and cooler solution)

Specications

Packing List

For more information on this and other Advantech prod-

ucts, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our sup-

port website for ASMB-586 at:

https://advt.ch/searc8f16d

extra warranty for FREE at:

http://www.register.advantech.com

This manual is for the ASMB-586 series Rev. A1..

Part No. 2001058611

Printed in China

2nd Edition

January 2020

2 ASMB-586 Startup Manual

Connector list

PMBUS1

PMBUS connector to communi-

cate with power supply

SATA0~7 SATA III (6Gb/s)

SPDIF_OUT1 SPDIF Audio output pin header

SYS_LED1

System Information LED Con-

nector

SPI4 BIOS SPI ROM

SYSFAN0,SYSFAN1,

SYSFAN2,SYSFAN3

System FAN connector

SPI_CN1 SPIashcardpinheader

SMBUS1 SMBus From PCH

SGPIO1, SGPIO2 Serial General Purpose I/O

USB7_8, USB9_10,

USB11_12

USB 2.0 Port (Header)

USB13 USB 2.0 Port (USB Type A)

USB5_6 USB 3.1 Gen1 Port (Header)

VOLT1 Voltage Display

*COM1 is directed to the PCB silk screen as COM1 or

COM3 but in BIOS it shows as COM1.

Jumper list

Label Function

CPUFAN_SEL1,

SYSFAN_SEL1

FAN PWM (1-2) / DC mode

(2-3)

HDMI_I2C1 For RD debugging

JCMOS1 CMOS clear

JME1

Intel ME Disable Jumper for

ME/BIOS update

JWDT1 Watch Dog Reset

JUSB1

Rear window USB 3.1 Gen2

port power source switch

between +5 VSB and +5 V

JUSB2

On board USB2.0/3.1 Gen1 port

power source switch between

+5 VSB and +5 V

JCASE1 Case Open

JPEG1, JPEG2 x16 or x8x8 or x8x4x4 for slot-6

JTHR_SEL1

Selects on board or external

thermistor

JPEG3

Default (1-2)/reserve for RD

debug (2-3)

JSMB1 For RD debug purpose

PSON1 AT(1-2) / ATX(2-3)

• Weight: 0.5 kg (weight of board)

The board has a number of jumpers that allow you to con-

gureyoursystemtosuityourapplication.Thetablebelow

lists the function of each jumper and connector.

Connector list

Label Function

ATXPWR1

ATX 24-pin main power connec-

tor (for System)

ATX12V1

8-pin power connector

(for CPU)

BAT2 For optional battery kit

BMC1

BMC connector to support

IPMI-1000 module (P/N: IPMI-

1000-00A2E)

COM1*, COM2 Serial port: RS-232

CPUFAN0 CPU FAN connector

DVI1 DVI connector

DIMMA0,DIMMA1,

DIMMB0,DIMMB1

DDR4 288-pin slot

EX_THR1

For External Thermistor Cable

Kit

FPAUD1 Front Panel Audio Header

GPIO1 8-bit GPIO header

HDMI1_VGA1 HDMI + VGA connector

JFP1 Power Switch / Reset connector

JFP2

External speaker / HDD LED

connector/ SMBus connector

JFP3

Keyboard Lock and Power LED

Suspend:Fastash(ATX/AT)

System On: ON (ATX/ AT)

SystemO󰀨:OFF(ATX/AT)

KBMS1

External keyboard and mouse

connector (6-pin)

LAN1_USB1_2,

LAN2_USB3_4

LAN1 / USB 3.1 Gen2 port 1, 2

stack connector

LAN2 / USB 3.1 Gen2 port 3, 4

stack connector

LAN3_4 LAN3 & LAN4 connector

LANLED1 LAN LED extension connector

LPC1

Low pin count connec-

tor for Advantech TPM and

RS232/422/485 module

PCIEX4_SLOT4 PCIe p2-x4 slot (Gen3 p2-x4 link)

PCIEX1_SLOT5 PCIe p2-x1 slot (Gen3 p2-x1 link)

PCIEX16_SLOT6 PCIe x16 slot (Gen3 x16 link)

PCIEX4_SLOT7 PCIe p2-x4 slot (Gen3 p2-x4 link)

Jumpers and Connectors Jumpers and Connectors (Cont.)
