Side 1/4

ASMB-786 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 Startup manual

• 2 Serial ATA HDD data cables

• 2 Serial ATA HDD power cables

• 1 COM cable

• 1 I/O port bracket

• 1 Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note: Acrobat Reader is required to view any PDF

le.AcrobatReadercanbedownloadedat:

http://www.adobe.com/downloads/ (Acrobat is a

trademark of Adobe)

ASMB-786 LGA 1151 Intel® Xeon® E and 8th/9th Gen

Core™ ATX Server Board with 4 x DDR4, 7 x PCIe,

6 x USB 3.1, 8 x SATA3, Quad/Dual LANs, IPMI

Startup Manual

Standard Functions

• CPU: Intel LGA1151 Xeon E-21xx/22xx and 8th/9th Gen

Core i3/i5/i7 series processors

• BIOS: AMI 256 Mb SPI BIOS

• Chipset: Intel C246

• System Memory: Dual Channel DDR4 ECC/Non-ECC

2666/2400/2133MHzunbu󰀨eredDIMM,Max.128GB

Note: Due to the inherent limitations of PC architecture,

the system may not fully detect 128 GB RAM

when 128 GB RAM is installed.

• SATA3 Interface: 8 SATA3 6Gb/s ports to support Intel

Rapid Storage Technology Enterprise with software RAID

0, 1, 10 & 5. (for Windows only)

• Serial Ports: Two serial ports onboard, only support RS-

232 (one can be in rear IO via COM cable connection)

• Keyboard/Mouse Connector: Supports standard PS/2

keyboard and mouse via KMBS1 pin header

• Watchdog Timer: 255 level timer intervals (sec/min)

• USB 3.1: Supports up to six USB 3.1 ports, four Gen2

ports in rear I/O and two Gen1 ports from on-board pin

header

• USB 2.0: Supports up to seven USB 2.0 ports (1* Type-A)

Display Interface

• Chipset: CPU integrated Intel HD graphics controller

• Display Memory: 1 GB maximum shared memory with

2 GB and above system memory installed (BIOS default

is 256 MB)

• Resolution:

- Supports VGA up to 1920 x 1200 resolution @ 60 Hz

refresh rate

- Supports DVI up to 1920 x 1200 resolution@ 60 Hz

refresh rate

- Supports HDMI 2.0 up to 2K/4K resolution @ 60Hz

Ethernet Interface

• Interface: 10/100/1000 Mbps

• Controller: LAN1:Intel

I219LM; LAN2 ~ LAN4: Intel®

I210AT (LAN2 is BMC shared NIC; LAN3/4 is for G4 SKU

only)

Mechanical and Environmental

• Dimensions (L x W): 244 x 304 mm (9.6” x 12”)

• Power Supply Voltage: +3.3 V, +5 V, ±12 V, 5 Vsb

• Power Consumption: Max. load: +3.3 V @ 3.44 A, +5 V

@ 2.61 A, +12 V @ 1.04 A, +12 V (8P) @ 6.3 A, +5 Vsb

@ 0.09 A

• Operating Temperature: 0 ~ 60° C (depends on CPU

speed and cooler solution)

Specications

Packing List

For more information on this and other Advantech prod-

ucts, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our sup-

port website for ASMB-786 at:

https://advt.ch/searca78a8

extra warranty for FREE at:

http://www.register.advantech.com

This manual is for the ASMB-786 series Rev. A1..

Part No. 2001S78611

Printed in China

2nd Edition

January 2020

2 ASMB-786 Startup Manual

Connector list

PCIEX4_SLOT2,

PCIEX4_SLOT7

PCIe p2-x4 slot (Gen3 p2-x4 link)

PCIEX16_SLOT4,

PCIEX16_SLOT6

PCIE x16 slots (one Gen3 x16

link for slot 6 or two Gen3 x8

link for slot 4 and 6)

PMBUS1

PMBUS connector to communi-

cate with power supply

SATA0~7 SATA III (6Gb/s)

SYSFAN0,SYSFAN1,

SYSFAN2,SYSFAN3

System FAN connector

SPI_CN1 SPIashcardpinheader

SPI1 BIOS SPI ROM

SMBUS1 SMBus from PCH

SGPIO1, SGPIO2 Serial general purpose I/O

SPDIF_OUT1 SPDIF audio output pin header

SYS_LED1

System information LED con-

nector

USB5_6 USB 3.1 Gen1 port header

USB7_8, USB9_10,

USB11_12

USB 2.0 port header

USB13 USB 2.0 port (USB Type A)

VOLT1 Voltage display

*COM1 is directed to the PCB silk screen as COM1 or

COM3 but in BIOS it shows as COM1.

Jumper list

Label Function

CPUFAN_SEL1,

SYSFAN_SEL1

FAN PWM (1-2) / DC mode

(2-3)

HDMI_I2C1 For RD debugging

JCMOS1 CMOS clear

JME1

Intel ME Disable jumper for ME/

BIOS update

JWDT1 Watchdog reset

JUSB1

Rear window USB 3.1 Gen2

port power source switch

between +5 VSB and +5 V

JUSB2

On board USB2.0/3.1 Gen1 port

power source switch between

+5 VSB and +5 V

JCASE1 Case open

JPEG1, JPEG2

PCIEX16_SLOT6 PCIe Link

swtich between one x16 or two

x8 or x8, two x4

• Weight: 0.75 kg (weight of board)

The board has a number of jumpers that allow you to con-

gureyoursystemtosuityourapplication.Thetablebelow

lists the function of each jumper and connector.

Connector list

Label Function

ATXPWR1

ATX 24-pin main power connec-

tor (for System)

ATX12V1

8-pin power connector

(for CPU)

AUDIO1 Audio connector

BAT2 For optional battery kit

BMC_VGA1 BMC VGA connector

BMC_SPI1 BMC image ROM

CPUFAN0 CPU FAN connector

COM1*, COM2 Serial port: RS-232

DIMMA0,DIMMA1,

DIMMB0,DIMMB1

DDR4 288-pin slot

DVI1 DVI connector

EX_THR1 For external thermistor cable kit

FPAUD1 Front panel audio header

GPIO1 8-bit GPIO header

HDMI1_VGA1 HDMI + VGA connector

JFP1 Power Switch / Reset connector

JFP2

External speaker / HDD LED

connector/ SMBus connector

JFP3

Keyboard Lock and Power LED

Suspend:Fastash(ATX/AT)

System On: ON (ATX/ AT)

SystemO󰀨:OFF(ATX/AT)

KBMS1

External keyboard and mouse

connector (6 pin)

LAN1_USB1_2,

LAN2_USB3_4

LAN1 / USB 3.1 Gen2 port 1, 2

stack connector

LAN2 / USB 3.1 Gen2 port 3, 4

stack connector

LAN3_4 LAN3 & LAN4 connector

LANLED1 LAN LED extension connector

LPC1

Low pin count connec-

tor for Advantech TPM and

RS232/422/485 module

LPT1 Parallel port

PCIEX1_SLOT1,

PCIEX1_SLOT3,

PCIEX1_SLOT5

PCIe p2-x1 slot (Gen3 p2-x1 link)

Jumpers and Connectors Jumpers and Connectors (Cont.)
