ASMB-977 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 x ASMB-977 startup manual

• 1 x Serial ATA HDD data cables

• 1 x Serial ATA HDD power cables

• 2 x CPU power cables (8P)

• 2 x CPU carriers

• 1 x I/O port bracket

• 1 x M.2 screw

If any of these items are missing or damaged, please

contact your distributor or sales representative immediately.

Note 1:  AcrobatReaderisrequiredtoviewanyPDFle.

Acrobat Reader can be downloaded at:

https://www.adobe.com/downloads.html

(Acrobat is a trademark of Adobe)

ASMB-977 Dual LGA4677 4th Gen Intel

Xeon

Scalable

Proprietary Server Board with 16x DDR5, 5 x PCIe x16,

9 x SATA3.0, 4 x USB 3.2 (Gen 1), Dual 10GbE, and IPMI

Startup Manual

Standard M/B Functions

• CPU: Dual LGA4677 4th Gen Intel

Xeon

Scalable

processors

• BIOS: AMI 256 Mbit SPI BIOS

• Chipset: Intel

C741 PCH

• System Memory: 16x DDR5 3200/3600/4000/4400/4800

MT/s registered ECC DIMM, Max. capacity 2TB

Note 2: Due to the inherent limitations of the PC architec-

ture, the system may not fully detect 2TB RAM

when 2TB RAM is installed.

• SATA Interface:

- 8 x SATA 3.0 (6 Gb/s) via Mini SAS HD (SFF-8643),

supports software RAID 0,1,5,10

- 1 x SATA 3.0 (6 Gb/s) for internal HDD or ODD

• Serial Ports: Two RS-232 ( one on rear I/O, and another

one via pin header)

• Keyboard/Mouse Header (KBMS1): Supports the stan-

dard PS/2 keyboard and mouse via PS/2 cable

• Watchdog Timer: 255 /sec or min level timer intervals

• USB Port: Supports up to 4 x USB 3.2 gen1 (2 rear and 2

onboard) and 1 x USB 2.0 ports (1*Type-A from onboard

10-pin header)

VGA Interface

• Chipset: ASPEED AST2600

• Resolution: Supports VGA up to resolution 1920 x 1200

@ 60 Hz refresh rate

Ethernet Interface

• Interface: 10/100/1000 Mbps & 10Gb (only for LAN3 &

LAN4)

• Controller: LAN1/2: Intel I210; LAN3/4: Intel

X710-AT2

Mechanical and Environment

• Dimensions (L x W): 380 x 349.5 mm (14.96” x 13.76”)

• Power Supply Voltage: +3.3 V, +5 V, ±12 V, +5 Vsb

• Power Consumption (mainboard only, excluding

IO device): Max. load: +3.3V@2.43A, +5V@1.76A,

+12V@18.12A, +5V_SB@1.54A, -12V@0.01A,

+12V_8P_0@16.29A, +12V_8P_1@13.91A

• Operating Temperature: 0 ~ 40° C (depending on CPU)

• Weight: 1.8 kg (weight of board)

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

https://advt.ch/asmb977

months extra warranty for free at:

http://www.register.advantech.com

This manual is for the ASMB-977 series Rev. A1.

Part No. 2042097700

Printed in China

1st Edition

January 2023

2 ASMB-977 Startup Manual

The board has a number of jumpers that allow you to con-

gureyoursystemtosuityourapplication.Thetablebelow

lists the function of each of the jumpers and connectors.

Connectors

Label Function

ATXPWR1

ATX 24 Pin main power connector

ATX12V1, ATX12V3

Processor power connector

(mandatory)

ATX12V2, ATX12V4

Processor power connector

(reserved)

BH2 For optional battery kit

BIOS_SKT1 BIOS SPI ROM

BMC_SPI1 BMC SPI ROM

BMC_LAN IPMI dedicated LAN connector

COM1 RS-232 connector

COM2 RS-232 header

CPUFAN0, CPUFAN1 CPU FAN connector

DIMMA1, DIMMB1,

DIMMC1, DIMMD1,

DIMME1, DIMMF1,

DIMMG1, DIMMH1

DDR5 from CPU0

DIMMI1, DIMMJ1,

DIMMK1, DIMML1,

DIMMM1, DIMMN1,

DIMMO1, DIMMP1

DDR5 from CPU1

DIMMA1, DIMMC1,

DIMME1, DIMMG1,

DIMMI1, DIMMK1,

DIMMM1, DIMMO1

DCPMM slot

ESPI1 eSPI connector

EX_THR1 Connector for external thermistor

GPIO1 GPIO connector

HDAUD1 Audio header

JFP1, JFP2, JFP3 Front panel header

KBMS1

External keyboard and mouse

connector

LAN1, LAN2 1 Gbps LAN connector

LAN3, LAN4 10 Gbps LAN connector

LANLED1 LAN LED extension connector

M2_2280_1 M.2 connector (PCIe gen4 x4)

M2_2280_2

M.2 connector (SATA and PCIe

gen3 x4)

PCIEX8_SLOT1 PCIE p2-x8 slot (CPU0)

Jumpers and Connectors (Cont.)

PCIEX16_SLOT2 PCIE x16 slot (CPU0)

PCIEX16_SLOT4 PCIE x16 slot (CPU0)

PCIEX 8_SLOT5 PCIE p2-x8 slot (CPU1)

PCIEX16_SLOT6 PCIE x16 slot (CPU0)

PCIEX8_SLOT7 PCIE p2-x8 slot (CPU1)

PCIEX16_SLOT8 PCIE x16 slot (CPU1)

PCIEX16_SLOT9 PCIE x16 slot (CPU1)

PCIEX8_SLOT10 PCIE p2-x8 slot (CPU1)

PCIEX8_SLOT11 PCIE p2-x8 slot (CPU1)

PMBUS1

PMBUS connector to communi-

cate with the power supply

SATA0~SATA3,

SATA4~7

SATA via SFF-8643

SGPIO1 SATA0~3 SGPIO header

SGPIO2 SATA4~7 SGPIO header

SLOT12V1 For PCIe slot 12V input only

SLOT12V2 For PCIe slot 12V input only

SMBUS1 SMBus header

SATA0 SATA connector

SYSFAN0~SYSFAN6 System FAN connector

SYS_LED1 System LED connector

USB2A1 USB 2.0 port (Type-A)

USB3H1 USB 3.0 port (20-pin header)

VGA1 VGA connector

Jumper list

Label Function

JCMOS1

CMOS clear

JME1 ME update

JWDT1 Watch Dog Reset

JTHR_SEL1

Internal (default pins 1-2) and

external

(pins 2-3) thermistor selection

JCASE1 Chassis case open alarm

PSON1

AT(1-2)/ATX(2-3)

Jumpers and Connectors
