ASMB-977S Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• 1 x ASMB-977S startup manual

• 1 x Serial ATA HDD data cables

• 1 x Serial ATA HDD power cables

• 2 x CPU power cables (8P)

• 2 x CPU carrier - E1A (XCC)

• 2 x CPU carrier - E1B (MCC)

• 1 x I/O port bracket

• 2 x M.2 screw

If any of these items are missing or damaged, please

contact your distributor or sales representative immediately.

Note 1: Acrobat Reader is required to view any PDF ﬁ le.

Acrobat Reader can be downloaded at:

https://www.adobe.com/downloads.html

(Acrobat is a trademark of Adobe)

ASMB-977S Dual LGA4677 5th/4th Gen Intel® Xeon®

Scalable Proprietary Server Board with 16 x DDR5, 6 x

PCIe x16, 2 x MCIO, 5 x SATA3.0, 4 x USB 3.2 (Gen 1),

Dual 10GbE, and IPMI

Startup Manual

Standard M/B Functions

• CPU: Dual LGA4677 5th/4th Gen Intel® Xeon® Scalable

processors, TDP up to 350W

• BIOS: AMI 512 Mbit SPI BIOS

• Chipset: Intel® C741 PCH

• System Memory: 16x DDR5 4400/4800/5200/5600 MT/s

registered ECC DIMM, Max. capacity 4TB

Note 2: Due to the inherent limitations of the PC architec-

ture, the system may not fully detect 4TB RAM

when 4TB RAM is installed.

• SATA Interface:

- 4 x SATA 3.0 (6 Gb/s) via Slim-SAS HD, supports

software RAID 0,1,5,10

- 1 x SATA 3.0 (6 Gb/s) for internal HDD or ODD

• Serial Ports: Two RS-232 ( one on rear I/O, and another

one via pin header)

• Keyboard/Mouse Header (KBMS1): Supports the stan-

dard PS/2 keyboard and mouse via PS/2 cable

• Watchdog Timer: 255 /sec or min level timer intervals

• USB Port: Supports up to 4 x USB 3.2 gen1 (2 rear and

2 onboard) and 1 x USB 2.0 ports (1*Type-A connector

onboard)

VGA Interface

• Chipset: ASPEED AST2600

• Resolution: Supports VGA up to resolution 1920 x 1200

@60Hz refresh rate

Ethernet Interface

• Interface: 10/100/1000 Mbps & 10Gb (only for LAN3 &

LAN4)

• Controller: LAN1/2: Intel I210; LAN3/4: Intel

X710-AT2

Mechanical and Environment

• Dimensions (L x W): 380 x 349.5 mm (14.96” x 13.76”)

• Power Supply Voltage: +3.3 V, +5 V, ±12 V, +5 Vsb

• Power Consumption (mainboard only, excluding

IO device): Max. load: +3.3V@2.8A, +5V@2.23A,

+12V@0.15A, +5V_SB@0.12A, -12V@0.01A,

+12V_8P_1@17.11A, +12V_8P_2@16.65A,

+12V_8P_3@17.89A, +12V_8P_4@17.74A

• Operating Temperature: 0 ~ 40° C (depending on CPU)

• Weight: 1.8 kg (weight of board)

Speciﬁ cations Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://support.advantech.com

months extra warranty for free at:

http://www.register.advantech.com

This manual is for the ASMB-977S series Rev. A1.

Part No. 2042977S00

Printed in China

1st Edition

May 2025

2 ASMB-977S Startup Manual

The board has a number of jumpers that allow you to con-

ﬁ gure your system to suit your application. The table below

lists the function of each of the jumpers and connectors.

Connectors

Label Function

ATXPWR1

ATX 24-pin main power connector

ATX12V1, ATX12V3

Processor power connector

(mandatory)

ATX12V2, ATX12V4

Processor power connector

(reserved)

BH2 For optional battery kit

BIOS_SKT1 BIOS SPI ROM

BMC_SPI1 BMC SPI ROM

BMC_LAN IPMI dedicated LAN connector

COM1 RS-232 connector

COM2 RS-232 header

CPUFAN0, CPUFAN1 CPU FAN connector

DIMMA1, DIMMB1,

DIMMC1, DIMMD1,

DIMME1, DIMMF1,

DIMMG1, DIMMH1

DDR5 from CPU0

DIMMI1, DIMMJ1,

DIMMK1, DIMML1,

DIMMM1, DIMMN1,

DIMMO1, DIMMP1

DDR5 from CPU1

DIMMA1, DIMMC1,

DIMME1, DIMMG1,

DIMMI1, DIMMK1,

DIMMM1, DIMMO1

DCPMM slot

ESPI1 eSPI connector

EX_THR1 Connector for external thermistor

GPIO1 GPIO connector

HDAUD1 Audio header

JFP1, JFP2, JFP3 Front panel header

KBMS1

External keyboard and mouse

connector

LAN1, LAN2 1 Gbps LAN connector

LAN3, LAN4 10 Gbps LAN connector

LANLED1 LAN LED extension connector

M2_2280_1

M.2 connector (SATA and PCIe

gen3 x4)

M2_2280_2

M.2 connector (SATA and PCIe

gen3 x4)

MCIO1, MCIO2 MCIO PCIe Gen5 p2-x8 connector

PCIEX16_SLOT1 PCIE x16 slot (CPU0)

Jumpers and Connectors (Cont.)

PCIEX16_SLOT2 PCIE x16 slot (CPU0)

PCIEX16_SLOT4 PCIE x16 slot (CPU0)

PCIEX16_SLOT6 PCIE x16 slot (CPU0)

PCIEX16_SLOT8 PCIE x16 slot (CPU1)

PCIEX16_SLOT9 PCIE x16 slot (CPU1)

PMBUS1

PMBUS connector to communi-

cate with the power supply

SATA_CON1 4 x SATA3.0 via Slim-SAS HD

SLOT12V1 For PCIe slot 12V input only

SLOT12V2 For PCIe slot 12V input only

SMBUS1 SMBus header

SATA0 SATA connector

SYSFAN0~SYSFAN6 System FAN connector

SYS_LED1 System LED connector

USB2A1 USB 2.0 port (Type-A)

USB3H1 USB 3.0 port (20-pin header)

VGA1 VGA connector

PEHP1 NVMe RAID LED control

VROC1

Enables NVMe RAID, hot-plug,

and LED control via direct PCIe

CPU link.

Jumper List

Label Function

JCMOS1

CMOS clear

JME1 ME update

JWDT1 Watch Dog Reset

JTHR_SEL1

Internal (default pins 2-3) and external

(pins 1-2) thermistor selection

JCASE1 Chassis case open alarm

PSON1

AT(1-2)/ATX(2-3)

JCMOS1/JME1: CMOS Clear/ME Update Function

Closed Pins Result

1-2

Keep CMOS data/Disable ME update*

2-3 Clear CMOS data/Enable ME update

*: Default

Keep CMOS data/Disable ME update Clear CMOS data/Enable ME update

123

Jumpers and Connectors
