Side 1/53

GT SYSTEM

Standard & Expanded System

SETTING MANUAL

Thank you for selecting Aiphone for your communication needs. Please read this manual carefully before installation, and keep this in a safe

place for future reference.

Please note that images and illustrations depicted in this manual may differ from the actual product.

- 2 -

READ THIS BEFORE SETTING UP THE

SYSTEM

1 Notes about using this manual ................................. 3

2 Outline of link setting .................................................. 4

3 DIP switch settings (conﬁ rm in advance) .............. 7

3-1 Entrance station, guard station,

expanded bus control unit .......................................... 7

3-2 Residential/tenant station ......................................... 10

SYSTEM SETUP USING GT SETUP

TOOL

4 Outline of settings ...................................................... 11

5 Initial setup ................................................................... 12

5-1 Installing the GT Setup Tool .................................... 12

5-2 Creating a new site ................................................... 13

5-3 Changing the setting contents for an existing site ... 14

6 System settings .......................................................... 15

6-1 Registering resident information .............................. 15

6-2 Guard and entrance station settings ......................... 16

7 Functions in the menu bar ....................................... 19

7-1 Function list ............................................................. 19

7-2 Changing site conﬁ guration ..................................... 20

7-3 Comparing and merging setting contents between

stations or ﬁ les ......................................................... 21

7-4 Uploading setting data conﬁ gured by the GT Setup

Tool to an entrance station, guard station or

expanded bus control unit ........................................ 23

7-5 Downloading setting data conﬁ gured on

an entrance station, guard station or expanded

bus control unit to the GT Setup Tool ...................... 24

SYSTEM SETUP USING ENTRANCE/

GUARD STATION

8 Setting up a link among stations ........................... 25

8-1 Setting up a link using a modular type entrance

station (GT-DB(-V, -VN)/GT-NSB/GT-SW) ........... 25

8-2 Setting up a link using an all-in-one type

entrance station (GT-DMB-N/GT-DMB-LVN) ....... 28

8-3 Setting up a link using a guard station

(GT-MKB-N) ........................................................... 31

9 Station settings ........................................................... 35

9-1 Setting item list ........................................................ 35

9-2 Basic setting operation ............................................. 38

Using a modular type entrance station

(name scrolling module (GT-NSB)/10 key module

(GT-10K)) ............................................................... 38

Using an all-in-one type entrance station

(GT-DMB-N/GT-DMB-LVN) ................................ 39

Using a guard station (GT-MKB-N) ...................... 40

9-3 Setting item description ........................................... 42

SELECT LANGUAGE .......................................... 42

CHANGE PASSCODE .......................................... 42

PROGRAMMING.................................................. 42

SYSTEM SETTINGS ............................................ 42

STATION SETTINGS ............................................ 43

OTHER SETTINGS ............................................... 47

SETTINGS ON RESIDENTIAL/TENANT

STATION

10 Changing settings on GT-2C-L/GT-2C only .......... 48

10-1 How to use the MENU ........................................... 48

10-2 Guard station settings ............................................. 48

10-3 Emergency input settings ....................................... 49

10-4 External input setting ............................................. 49

10-5 Doctor call setting .................................................. 51

10-6 Press-to-talk setting ................................................ 51

10-7 Call ID display setting ........................................... 51

10-8 Initializing .............................................................. 52

Table of Contents

Notices

• We will under no condition be liable for any damages or losses resulting from this product's contents or speciﬁ cations.

Aiphone Co., Ltd. is strictly prohibited.

• This manual may be revised or changed without prior notice.

• Product speciﬁ cations may be changed for the sake of improvement without prior notice.
