Side 1/1

- INSTRUCTIONS -

The SBX-DV30 is an 18-Gauge stainless steel surface mount 30° box designed for angle mounting the

JF-DV, JK-DV, JO-DV, and JP-DV video door stations. This is applicable for wide or double door entrances

where the door station needs to be mounted off to the side of the door, and provides a better viewing angle

for the camera.

Stainless Steel 30° Angle Box for the

JF-DV, JK-DV, JO-DV, & JP-DV

SPECIFICATIONS:

Mounting: 1-gang box, or surface mount directly to wall surface

Material: 18-Gauge Stainless Steel

Color: Polished Stainless Steel

Dimensions (HxWxD): 6-13/16” x 3-5/8” x 2-3/4" (high side); 3/4” (low side)

SBX-DV30 Instr.

0415JD

Aiphone Communication Systems

1700 130th Ave. N.E.

Bellevue, WA 98005

(425) 455-0510

FAX (425) 455-0071

Toll Free Technical Support:

1-800-692-0200

E-mail tech@aiphone.com

CONTENTS:

- SBX-DV30 Surface mount 30° angle box

- 4 machine screws

JF-DV

SBX-DV30

MOUNTING INSTRUCTIONS:

1. The SBX-DV30 is designed to mount to a 1-gang box or

ring, or to any flat surface.

2. Pass cable through the knockout hole.

3. Secure mounting box to wall.

4. Connect cable to JF-DV/JK-DV/JO-DV/JP-DV.

(Refer to system’s installation instructions.)

5. Attach video door station to mounting box using

supplied machine screws.

6. Attached camera case to camera unit using supplied

security screw and tool. (Security screw and tool are

supplied with the door station.)

3-5/8"

2-¾”

6-13/16"

4-1/8"

¾”
