Side 1/64

JOS-1A

JO-DVF

JO-1MD

JOS-1V

JOS-1F

JO-DV

JO-DA

VIDEO DOOR STATION

MASTER MONITOR STATION

VIDEO DOOR STATION

Thank you for selecting Aiphone for your communication and security needs. Please read this manual carefully for proper system

operation. For future reference, keep manual in a safe place.

INSTALLATION & OPERATION MANUAL

MANUEL D’INSTALLATION ET D’UTILISATION

MANUAL DE INSTALACIÓN Y OPERACIÓN

INSTALLATIE- EN BEDIENINGSHANDLEIDING

MANUALE D'INSTALLAZIONE E USO

INSTALLATIONS- UND BEDIENUNGSANLEITUNGHANDBUCH

FK1899 A P0713KD 55060

HANDS-FREE COLOR VIDEO INTERCOM

INTERPHONE VIDEO COULEUR MAINS LIBRES

INTERCOMUNICACIÓN CON VÍDEO A COLOR MANOS LIBRES

HANDENVRIJE KLEURENVIDEOFONIE

VIDEOCITOFONO A COLORI A VIVAVOCE

FREISPRECH-FARBVIDEO-SPRECHANLAGEN-HAUPTSTELLE

JOS-1A, JOS-1V, JOS-1F

EnglishFrançaisEspañolNederlandsItalianoDeutsch

PRECAUTIONS

Prohibited Do not dismantle unit Keep unit away from water General precautions

WARNING

Negligence could result in death or serious injury.

Do not dismantle or alter the unit. Fire or electric shock could result.

2. Keep the unit away from water or any other liquid.

Fire or electric shock could result.

3. High voltage is present internally. Do not open the case.

Electric shock could result.

4. Do not connect any non-specied power source to the +, - terminals.

Also, do not install two power supplies in parallel to a single input.

Fire or damage to the unit could result.

5. Do not use power supply with a voltage other than specied.

Fire or electric shock could result.

6. Do not put any metal or ammable material into the unit through the openings.

Fire, electric shock, or unit trouble could result.

The unit must be installed and wired by a qualied technician.

CAUTION

Negligence could result in injury or damage to property.

1. Do not install or make any wire terminations while power supply is plugged in. It

can cause electrical shock or damage to the unit.

2. When mounting the unit on a wall, install the unit in a convenient location, but not

where it could be jarred or bumped. Injury could result.

3. Before turning on power, make sure wires are not crossed or shorted. Fire or

electric shock could result.

4. Do not install the unit in locations subject to frequent vibration or impact. It may

fall or tip over, resulting in damage to the unit or personal injury.

5. For power supply, use Aiphone power supply model specied for use with system.

If non-specied product is used, re or malfunction could result.

6. Do not put anything on the unit or cover the unit with cloth, etc.

Fire or unit trouble could result.

7. Do not install the unit in any of the following locations.

Fire, electric shock, or unit trouble could result.

* Places under direct sunlight or near heating equipment that varies in temperature.

* Places subject to dust, oil, chemicals, hydrogen sulde (hot spring).

* Places subject to moisture and humidity extremes, such as bathrooms, cellars,

greenhouses, etc.

* Places where the temperature is quite low, such as inside a refrigerated area or

in front of an air conditioner.

* Places subject to steam or smoke (near heating or cooking surfaces).

* Where noise generating devices such as dimmer switches or inverter electrical

appliances are closeby.

* Locations subject to frequent vibration or impact.

Do not apply high pressure on the screen. If fractured, injury could result.

9. If the LCD is punctured, do not allow skin contact with the liquid crystal inside.

Inammation could result.

* If liquid crystal is ingested, immediately gargle with water and seek medical

attention.

* If contact with the eyes or skin occurs, clean with pure water and seek medical

attention.

GENERAL PRECAUTIONS

Keep the unit more than 1m (3.3

') away from radio or TV set.

Keep the intercom wires more than 30cm (12

'') away from AC 100-240V wiring. AC

induced noise and/or unit malfunction could result.

3. Comply with all third party manufacturing specications that will be used with this

system (sensors, door releases, etc.).

4. If the unit is down or does not operate properly, unplug the power supply.

5. When wall-mounted, the top of the unit may darken. This does not indicate a

malfunction.

6. The unit case may become warm with use, but this is not a unit malfunction.

7. If the unit is used near a cellular phone, the unit may malfunction.

8. The unit can be damaged if dropped. Handle with care.

9. The unit will not work during power failure.

10. In areas where broadcasting station antennas are close by, the intercom system may be

affected by radio frequency interference.

11. All the units, except for door stations, are designed for indoor use only.

Do not use at outdoor locations.

12. This product, providing door release, should not be used as a crime prevention device.

13. Please note the LCD panel, though manufactured with very high precision techniques,

inevitably will have a very small portion of its image elements always lit or not lit at

all. This is not considered a unit malfunction.

14. Environmental sound around the unit may hinder smooth communication, but this is

not a malfunction.

15. At night, due to reduced lighting on the object, the screen sees more noise and faces

become more difcult to see, but this is not a malfunction.

16. For hands-free communication:

If you stand too far away, it may be difcult for the other person to hear the

communication.

17. If there are loud noises around the unit (such as music playing or children crying), the

sound may break up and be difcult to hear.

18. During communication, if you speak before the other person has nished talking, your

voice may not come through clearly.

Communication will proceed smoothly if you wait until the other person has nished

before speaking.

19. At a gate or porch illuminated by a uorescent lamp, the image may vary, but this is

not a malfunction.

20. The outline of video images displayed by the video door station may differ from that

of the actual person(s) or background, but this is not a malfunction.

21. If the surface of a video door station freezes during wintertime, the image may

become difcult to see or the call button may not move, but this is not a malfunction.

22. Warm-color lighting shining on the video door station may change the tint of the

image on the screen.

23. When outside temperature lowers sharply after rainfall, etc., the inside of the camera

may fog up slightly, causing a blurry images, but this is not a malfunction. Normal

operation will be restored when moisture evaporates.

24. When the unit’s screen is illuminated with strong light, the image looks white or

silhouetted, but this is not a malfunction.

NOTICES

* We will under no conditions be liable for damage occurring due to the inability to

communicate due to malfunctions, problems, or operational errors in this product.

* We will under no conditions be liable for any damages or losses resulting from this

product’s contents or specications.

or in whole, this manual without prior permission from Aiphone Co., Ltd. is strictly

forbidden.

* Please note that images and illustrations depicted in this manual may differ from the

actual ones.

* Please note that this manual may be revised or changed without prior notice.

* Please note that product specications may be changed for the sake of improvement

without prior notice.

* This system is not intended for life support or crime prevention. It is a supplementary

means of conveying information. Aiphone will under no conditions be liable for loss of

life or property which occurs while the system is being operated.

* Lighting adjustments are made automatically by the door station. Adjustment results

may vary depending on installation environment.

Produkt Specifikationer

Mærke:	Aiphone
Kategori:	Intercomsystem
Model:	JOS-1F
Kode for international beskyttelse (IP):	IP54
Bredde:	230 mm
Dybde:	21 mm
Højde:	130 mm
Vægt:	470 g
Produktfarve:	Hvid
Skærm diagonal:	7 "
Skærmteknologi:	LCD
Forbindelsesteknologi:	Ledningsført
Højttalertelefon:	Ja
Kan monteres på væggen:	Ja
Sensortype:	CMOS
Farve:	Ja
IK kode:	IK07
Minimumsbelysning:	5 Lux
Optisk sensorstørrelse:	1/4 "
Indendørsenhed boligmateriale:	Plastic, Resin
Indendørsenhed inkluderet:	Ja
Udendørsenhed inkluderet:	Ja
Primær overvågningsstation driftstemperatur (T-T):	0 - 40 °C
Dørstation driftstemperatur (T-T):	-20 - 60 °C
Dørstation dimensioner (BxDxH):	135 x 3.5 x 209 mm
