IMPORTANT INSTRUCTIONS -

OPERATING MANUAL

SAVE THESE INSTRUCTIONS

www.airkinglimited.com

210575917 Rev. H 11-18 1 of 8

Bulb Heat Lamp with Fan

Models: AK917, AK927

READ AND SAVE THESE INSTRUCTIONS

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN

THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY

INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL

INJURY AND/OR PROPERTY DAMAGE!

RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.

GENERAL SAFETY INFORMATION

When using electrical appliances, basic precautions should

always be followed to reduce the risk of ﬁre, electric shock and

injury to person, including the following:

WARNING: TO REDUCE THE RISK

OF FIRE, ELECTRIC SHOCK AND INJURY TO

PERSON, OBSERVE THE FOLLOWING:

a) Use this unit only in the manner intended by the manufacturer.If you have

questions, contact the manufacturer.

b) Before servicing or cleaning the unit, switch power off at service

panel and lock the service disconnecting means to prevent power

from being switched on accidentally. When the service disconnecting

means cannot be locked, securely fasten a prominent warning

device, such as a tag, to the service panel.

WARNING: TO REDUCE THE RISK

OF FIRE, ELECTRIC SHOCK AND INJURY TO

PERSON, OBSERVE THE FOLLOWING:

a) Installation work and electrical wiring must be done by qualiﬁed

person(s) in accordance with all applicable codes and standards,

including ﬁre-related construction.

b) Sufﬁcient air is needed for proper combustion and exhausting of

gases through the ﬂue (chimney) of fuel burning equipment to prevent

back drafting. Follow the heating equipment manufacturer’s guideline

and safety standards such as those published by the National Fire

Protection Association (NFPA) and the American Society for Heating,

Refrigeration, and Air Conditioning Engineers (ASHRAE), and the local

code authorities.

c) When cutting or drilling into wall or ceiling, do not damage electrical

wiring and other hidden utilities.

CAUTION: FOR GENERAL VENTILATING USE ONLY.

DO NOT USE TO EXHAUST HAZARDOUS OR EXPLOSIVE

MATERIALS AND VAPORS.

d) Ducted fans must always be vented to the outdoors.

e) This unit must be grounded.

f) To avoid motor bearing damage and noisy and/or unbalanced impellers,

keep drywall spray, construction dust, etc. off power unit.

g) Read all instructions before installing or using exhaust fan.

WARNING: TO REDUCE THE RISK OF FIRE,

ELECTRIC SHOCK, DO NOT USE THIS FAN WITH

ANY SOLID-STATE SPEED CONTROL DEVICE.

WARNING: DO NOT INSTALL OVER A TUB OR

MOUNT IN A SHOWER STALL ENCLOSURE.

a) Do not install into a ceiling thermally insulated to a value greater

than R-40.

b) NEVER place a switch where it can be reached from a tub or shower.

WARNING: DO NOT USE IN KITCHENS.

WARNING: THIS UNIT IS DESIGNED AND

TESTED TO BE A SUPPLEMENTAL HEATER FOR USE

WITH A TIMER OR A SWITCH. IT IS NOT INTENDED TO BE USED AS THE

PRIMARY SOURCE OF HEAT AND CONTROLLED BY A THERMOSTAT.

INSTALLATION INSTRUCTIONS

CAUTION: MAKE SURE POWER IS SWITCHED OFF AT

SERVICE PANEL BEFORE STARTING INSTALLATION.

WARNING: TO REDUCE THE RISK OF FIRE, DO NOT STORE

OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN

THE VICINITY OF THE HEATER.

SECTION 1

Preparing the Exhaust Fan

1. Unpack fan from the carton and conﬁrm that all pieces are present. In addition to the

exhaust fan you should have:

1 - Grill

1 - Damper Assembly (attached)

4 - Mounting Rails

1 - Instruction/Safety Sheet

2. Remove the wire compartment cover by loosening the two screws holding the cover in

place (Figure 1).

3. Choose the location for your fan. To ensure the best air and sound performance, it is

recommended that the length of ducting and the number of elbows be kept to a

minimum, and that insulated hard ducting be used.

Larger duct sizes will reduce noise and airﬂow

restrictions. This fan will require at least 8 of "

clearance in the ceiling or wall, and will mount

through drywall up to 3/4 thick. The fan mounts "

between 16” on center joists using the provided

mounting rails.

3. Select the most convenient electrical knockout and

remove using a straight-blade screw driver (Figure 2).

SECTION 2

New Construction

1. Install the rails on the housing and position the housing next to the joist. Line up housing

so that it will be ﬂush with the ﬁnished ceiling. Secure the ends of the rails with screws

or nails (not included) to the joists and slide the housing into the ﬁnal position (Figure 3).

SECTION 3

Existing Construction

1. Set housing in position between the joist and trace an outline onto the ceiling material

(Figure 4). Set housing aside and cut opening, being careful not to cut or damage any

electrical or other hidden utilities. Install the rails on the housing and position the housing

in the previously cut hole so that it is ﬂush with the ﬁnished ceiling. Secure the ends of

the rails to the joists (Figure 3).

www.airkinglimited.com

210575917 Rev. H 11-18 2 of 8

SECTION 4

Ducting

CAUTION: ALL DUCTING MUST COMPLY WITH LOCAL AND NATIONAL

BUILDING CODES.

1. Remove any tape that might be holding the damper in place during shipping and connect

the ducting to the fan’s duct collar Secure in place using tape or screw (Figure 5).

clamp. Always duct the fan to the outside through a wall or roof cap.

SECTION 5

Wiring

CAUTION: MAKE SURE POWER IS SWITCHED OFF AT

SERVICE PANEL BEFORE STARTING INSTALLATION.

CAUTION: ALL ELECTRICAL CONNECTIONS MUST BE

MADE IN ACCORDANCE WITH LOCAL CODES, ORDINANCES, OR

NATIONAL ELECTRICAL CODE. IF YOU ARE UNFAMILIAR WITH METHODS OF INSTALLING

ELECTRICAL WIRING, SECURE THE SERVICES OF A QUALIFIED ELECTRICIAN.

NOTE: This unit includes a side access panel for wiring that does not require the removal of the

fan’s blower assembly. If you choose to wire the unit from the inside, you will need to remove the

blower assembly and internal wiring compartment. Both methods are equally effective.

1a. Run wiring from an approved wall switch Wiring Fan/Heat Bulb(s) Independently:

carrying the appropriate rating. One neutral (white), one ground (green or bare copper),

and two hot (black and blue). Secure the electrical wires to the housing with an approved

electrical connector. Make sure you leave enough wiring in the box to make the

connection to the fan’s receptacle.

1b. From where you have access to inside the fan’s junction box, connect the white wire

from the house to the white wire from the fan. Connect one hot (black) wire from the

house to the black wire from the fan (this is the fan control). Connect the second hot

(blue) wire from the house to the blue wire from the fan (this is the heat bulb control).

Connect the ground wire from the house to the green wire from the fan Use (Figure 6).

approved methods for all connections.

NOTE: On model AK927 connect the Hot (Blue) wire from the house to the two Blue wires from

the unit.

Housing

Joist Mounting Rails

Figure 3

Figure 2

Figure 1

Screws

Wire

Compartment

Cover

Figure 4

Figure 5

Figure 6

Supply from house

Black

Neutral (White)

Ground (Green or Bare)

Fan

Neutral (White)

Green

Black

By others

Blue Blue
