Side 1/20

SIGNALING

Rev. 101817

Combine Altronix Power and Accessories with

Access Controllers from the Industry’s Leading Manufacturers

Installation Guide

All registered trademarks are property of their respective owners. More than just power.™

Installing Company: _____________________ Service Rep. Name: __________________________________________

Address: ________________________________________________________ Phone #: _________________________

Access & Power Integration

- 2 - Trove

Overview:

Trove accommodates various combinations of access controllers and accessories from the industry’s leading manufacturers with or without

Altronix power supplies and accessories for access systems. A variety of backplanes offer a wide range of scalable access and power conﬁg-

urations. Trove simplifies board layout and wire management, while reducing installation and labor costs.

Trove Model Identification:

Series

Trove

Enclosure Size

Backplane Model

(Access Controller Manufacturer)

Backplane Size

Trove

18” x 14.5” x 4.625”

(457mm x 368mm x 118mm)

C = CDVI

16.625” x 12.5” x 0.06”

(422.3mm x 317.5mm x 1.5mm)

BV = Brivo

16.625” x 12.5” x 0.3125”

(422.3mm x 317.5mm x 7.9mm)

DM = DMP

JC = Johnson Controls

M = Mercury

PD = ProdataKey

SA = Salto

V = HID/VertX

27.25” x 21.75” x 6.5”

(692.2mm x 552.5mm x 165.1mm)

AM = AMAG

25.375” x 19.375” x 0.3125”

(644.5mm x 492.1mm x 7.9mm)

AG = AMAG

BH = Bosch

BL = Universal Blank Backplane

BV = Brivo

CV = CDVI

DM = DMP*

HN = Honeywell NetAXS

HW = Honeywell ProWatch/WinPak

JC = Johnson Controls

KA = Keyscan

KH = Kantech

M = Mercury

PX = Paxton*

SA = Salto*

SH = Software House

SL = Sielox*

V = HID/VertX

Z = ZKTeco

36.12” x 30.125” x 7.06”

(917.5mm x 768.1mm x 179.3mm)

BL = Universal Blank Backplane

34.0” x 28.0” x 0.3125”

(863.6mm x 711.2mm x 7.9mm)

BV = Brivo

CV = CDVI

HW = Honeywell ProWatch/WinPak

JC = Johnson Controls

M = Mercury

SH = Software House

V = HID/VertX

Door Backplanes for System Expansion:

TMV2 - Trove2 and Trove3 door backplane compatible with Mercury or HID/VertX boards and Altronix sub-assemblies (Fig. 11, pg. 13).

THWD2 - Trove2 and Trove3 door backplane compatible with Honeywell ProWatch/WinPak boards.

Specifications:

Agency Listings:

• UL 294 - 6th edition. Trove1 and Trove2 Power Controllers: Line Security I, Destructive Attack I, Endurance IV, Stand-by Power II.

• This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada.

• CE European Conformity.

Environmental:

• Humidity and Temperature conditions as tested by UL (85%, +/-5% @ 30ºC +/-2ºC), ULC (93%, +/-2% @ 32ºC +/-2ºC).
