Side 1/8

Installing Company: Service Rep. Name: _______________ __________________________________

Address: Phone #: _____________________________________________ __________________

Rev. 050613

More than just power.

Z1409

VertiLine563

Rack Mount

Power Supply/Charger

Installation Guide

- 2 - VertiLine563 Installation Guide

Overview:

Altronix VertiLine563 is a EIA 19” 1U rack mountable dual independent power supply with optional battery backup

that provides 56VDC. It is intended primarily to be used in conjunction with respective Altronix current and future

products that require 56VDC input such as: eBridge4PCRX, eBridge16PCRX & eBridge1PCRX multi-port and

single port IP/PoE over coax adapters. However, it can also be employed wherever 56VDC level power sources

are needed.

There are applications, which may require delivering power in a range of 48VDC to 57VDC over CAT5 cable for

distances up to 100m. For these applications, transmission at the higher voltage is more efficient, as it reduces

cable losses when compared to the lower voltage.

Specifica tions:

Agency Listings:

• UL/cUL: UL 60950-1

Information Technology Equipment.

• European Conformity.CE

• C-Tick C-Tick Compliant.

Input:

• Input 115VAC, 60Hz, 4.9A.

Output:

• 56VDC @ 3A each output.

(When using battery backup, output rating is

56V/2.7A for respective outputs).

Battery Backup:

• Built-in charger for sealed lead acid or

gel type batteries.*

*External batteries are optional.

• Automatic switch over to stand-by battery

when AC fails.

• Maximum charge current 0.3A.

Additional Features:

• Two (2) AC LED indicators.

• IEC 320 - 3-wire grounded line cord (detachable).

• Unit can be rack or shelf mounted.

Rack Dimensions (H x W x D approx.):

• 1U rack mount chassis for use in standard

EIA 19” rack.

1.625” x 19.125” x 8.5”

(41.3mm x 486mm x 216mm)

Accessories:

RE2 - Rack Mount Battery Enclosure:

• Fits up to four (4) 12VDC/7AH batteries.

• 2U rack mount chassis for use in standard

EIA 19” rack.

Installation Instructions:

1. Suitable for rack, wall or shelf mounting (refer to page 7).

a. If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack

environment may be greater than room ambient. Therefore, consideration should be given to installing

the equipment in an environment compatible with the maximum ambient temperature (Tma) specified by

the manufacturer.

b. Installation of the equipment in a rack should be such that the amount of airflow required for safe

operation of the equipment is not compromised.

c. Mounting of the equipment in the rack should be such that a hazardous condition is not achieved due to

uneven mechanical loading.

d. Consideration should be given to the connection of the equipment to the supply circuit and the effect that

overloading of the circuits might have on overcurrent protection and supply wiring.

Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

e. Reliable earthing of rack-mounted equipment should be maintained.

Particular attention should be given to supply connections other than direct connections to the branch

circuit (e.g. use of power strips).

2. Insert terminal blocks included with unit in sockets in the rear of unit (Fig. 2, pg. 4).

3. Plug power cord into grounded 115VAC, 60Hz receptacle to energize unit (Fig. 2a, pg. 4).

4. Measure output voltage on both output terminal blocks marked [– OUT1] + and [– OUT2 +] before connecting

devices. Output voltage should be nominally 56VDC.

5. Unplug power cord from grounded 115VAC, 60Hz receptacle to de-energize unit (Fig. 2a, pg. 4).
