Side 1/40

Linea Focus

Electronically Steerable Line Source Systems

User Manual

LFI-120

LFI-220

LFI-350

LFI-450

Important information:

Linea Focus series models can only be configured using Fohhn Audio Soft. For software handling see

separate user instructions.

For connection to a PC, Fohhn-Net Adapter NA-11 is required.

Before using your Linea Focus system, please read this manual carefully and keep it for future

reference.

0. Important Safety Information

Please read the following safety information carefully before operating the loudspeaker system(s).

Keep this information for future reference.

A lightning flash with arrowhead symbol within an equilateral triangle alerts the user to the

presence of uninsulated, dangerous voltage within the system enclosure that may be of

sufficient magnitude to constitute risk of electric shock.

An exclamation mark within an equilateral triangle alerts the user to important information

regarding to safety, maintenance or service.

Compliance with safety provisions against fire hazard, risk of electronic shock and injury to

personnel.

WARNING! – While Linea Focus systems are in operation, the following safety requirements must

be strictly adhered to:

System Installation and Set-up

• To reduce risk of injury, extreme care should be taken when operating the systems near

children.

• Make sure that the systems are firmly secured, especially when used with tripod stands.

Avoid sloping or unstable surfaces at all times.

• Do not use the systems near water (e.g. sinks, swimming pools, or on wet ground).

• Keep the systems free from moisture, dust, lengthy or intensive exposure to sunlight and

vibration.

• The systems should not be used near ovens, heaters or other heat-producing equipment, nor

should they be exposed to extremely low temperatures.

• The systems should be installed in such a way that optimum ventilation is guaranteed and

power outlets are within easy reach.

• Make sure that the systems cannot be tampered with, or fall over, and that no liquids can get

into the ventilation slots thus damaging internal components.

• Containers with liquid (i.e. glasses) should never be placed on top of the systems

Operation

• Never go below the minimal load impedance of the connected amplifier.

• When used in conjunction with headphones or an external amplifier, these systems can

produce volume levels that may potentially damage your hearing. Do not listen at high

volume levels for long periods. If you notice any deterioration in your hearing, or whistling in

your ears, please consult your doctor.

Produkt Specifikationer

Mærke:	Atlas
Kategori:	Højttaler
Model:	ALS-LFI220
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50/60 Hz
Bredde:	130 mm
Dybde:	120 mm
Højde:	2250 mm
Vægt:	15000 g
Produktfarve:	Sort
Bluetooth:	Ingen
Udgangseffekt (RMS):	1600 W
Strømforbrug (standby):	5 W
Husmateriale:	Aluminium
Anbefalet brug:	Universel
Frekvensområde:	60 - 17000 Hz
Forbindelsesteknologi:	Ledningsført
Lyd-output kanaler:	- kanaler
Højttaler, placering:	Stand-mountable, Wall-mountable
Strømkilde type:	Vekselstrøm
Antal drivere:	16
Driver diameter:	101 mm
Sensitivitet:	112 dB
Signal/støjforhold:	130 dB
Forstærker:	Indbygget
Forstærker klasse:	D
Forstærker, udgående strøm:	100 W
Højttalere RMS-effekt:	1600 W
Strålebredde:	90 - 110 °
Antal forstærkere:	16
