Atlona 6 Input Switcher and

Scaler with HDBaseT and

Mirrored HDMI Output

Please check http://www.atlona.

com/AT-UHD-CLSO-612

for the most recent firmware

update or manual.

User Manual

AT-UHD-CLSO-612

atlona.com

Toll free: 1-877-536-3976

Local: 1-408-962-0515

Revision B - Firmware 1.0.60 and OSD 1.1.0

Auto Switching Pg. 3, 15, 20, 27

VGA Preferred Timing Pg. 18, 27

HDVS Transmitters Pg. 20

Resolutions Pg. 10, 26

Video Adjustment Pg. 26

1. Introduction .......................................................................................... 3

2. Package Contents .......................................................................................... 3

3. Features .......................................................................................... 3

4. Panel Descriptions

a. Front Panel .......................................................................................... 4

b. Rear Panel .......................................................................................... 4

5. Wall/Rack mounts .......................................................................................... 5

6. Category cable .......................................................................................... 5

7. Analog Multi-Format Inputs .......................................................................................... 6

8. Audio Connections .......................................................................................... 7

9. Microphone .......................................................................................... 8

10. On Screen Display .......................................................................................... 9-11

11. TCP/IP and GUI .......................................................................................... 12-20

12. IR .......................................................................................... 21-23

13. RS-232

a. Connection .......................................................................................... 24

b. Set Up .......................................................................................... 24

c. Commands .......................................................................................... 25-27

d. IP Commands .......................................................................................... 28

e. Baud Rate .......................................................................................... 28-29

f. Control Diagram .......................................................................................... 29

14. Connection & Installation .......................................................................................... 30-31

15. Control Drivers .......................................................................................... 31

16. CLSO-612 Updating .......................................................................................... 31

17. Specifications .......................................................................................... 32-33

18. Safety .......................................................................................... 33

19. Warranty .......................................................................................... 34-35

20. Registration .......................................................................................... 35

Table of Contents
