Atlona 6 Input Switcher and

Scaler with HDBaseT and

Mirrored HDMI Output

Please check http://www.atlona.

com/product/AT-UHD-CLSO-

612ED for the most recent

firmware update or manual.

User Manual

AT-UHD-CLSO-612ED

atlona.com

Toll free: 1-877-536-3976

Local: 1-408-962-0515

1. Introduction .......................................................................................... 3

2. Package Contents .......................................................................................... 3

3. Features .......................................................................................... 3

4. Panel Descriptions

a. Front Panel .......................................................................................... 4

b. Rear Panel .......................................................................................... 4

5. Wall/Rack Mounts .......................................................................................... 5

6. Category Cable .......................................................................................... 5

7. Analog Multi-Format Inputs .......................................................................................... 6

8. Audio Connections .......................................................................................... 7

9. Microphone .......................................................................................... 8

10. On Screen Display .......................................................................................... 9-11

11. TCP/IP and GUI .......................................................................................... 12-20

12. IR .......................................................................................... 21-23

13. RS-232

a. Connection .......................................................................................... 24

b. Set Up .......................................................................................... 24

c. Commands .......................................................................................... 25-27

d. IP Commands .......................................................................................... 28

e. Baud Rate .......................................................................................... 28-29

f. Control Diagram .......................................................................................... 29

14. Connection & Installation .......................................................................................... 30-31

15. Control Drivers .......................................................................................... 31

16. CLSO-612 Updating .......................................................................................... 31

17. Specifications .......................................................................................... 32-33

18. Safety .......................................................................................... 33

19. Warranty .......................................................................................... 34-35

20. Registration .......................................................................................... 35

Table of Contents

Produkt Specifikationer

Mærke:	Atlona
Kategori:	Ikke kategoriseret
Model:	AT-UHD-CLSO-612ED
Bredde:	438 mm
Dybde:	254 mm
Højde:	44 mm
Vægt:	3220 g
Produktfarve:	Sort
Understøttede videotilstande:	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	20 - 90 %
HDCP:	Ja
Strømforbrug (typisk):	43 W
Driftstemperatur (T-T):	0 - 50 °C
Indgangsspænding for vekselstrømsadapter:	100-240 V
Frekvens for vekselstrømsadapter:	50/60 Hz
Udgangsspænding for vekselstrømsadapter:	48 V
Bæredygtighedscertifikater:	RoHS
Farvedybde:	12 Bit
Maksimal opdateringshastighed:	60 Hz
Antal VGA-porte (D-sub):	2
Maksimal driftstilstand:	100 m
Vekselstrømsadapterens udgangsstrøm:	2.08 A
HSMI-indgang:	2
RJ-45 indgangs-porte:	2
RS-232-porte:	6
Video porttype:	HDMI
Båndbredde:	10.2 Gbit/sek.
RJ-45 udgangs-porte:	2
