Side 1/16
®
®making good sound better®
Line Driver / Volume Control
You have just purchased a high-performance autosound product, the
AudioControl OVERDRIVE PLUS Line Driver. The OVERDRIVE PLUS
will allow you to utilize every last bit of performance and sound quality
that you’ve always strived for from your vehicle’s sound system. In addi-
tion, your new OVERDRIVE PLUS provides you with an input to accept
an dash mounted remote level control. The OVERDRIVE PLUS optional
can now be both a line driver and a remote volume/bass control. Find a
nice dry spot well away from the rainforest drizzle, and take in the clean
air along with this Enjoyment Manual for the OVERDRIVE PLUS Line
Driver.
Key Features of the OVERDRIVE PLUS:
• High signal voltage capability: 9.5 volts RMS output
• 24 dB of gain
• Input for optional Dash Control for remote level
• Ultra-low distortion, ultra-quiet operation
• Low noise, high current output circuitry
• High-headroom PWM switching power supply
• Selectable ground isolation
• Voltage indicator LEDs
- 2 -
High-Voltage Line Driver
The OVERDRIVE PLUS is a line driver that takes the input voltage
of a high performance source unit and increases it (up to 13 volts peak).
It then delivers this punched up signal to the amplier for more lifelike
sound with less noise, less distortion and more dynamic range. In short: it
makes music played on your system sound more like live music.
Input for Optional Dash Control
An optional dash control (sold separately) can be plugged into the
OVERDRIVE PLUS to allow you to adjust the output gain remotely. You
can use this to have a remote system volume control or to have a remote
amp volume control.
Low Noise / High Current Output Circuitry
Driving long lengths of cable can present a nasty capacitive load to the
source that has to drive them. The OVERDRIVE PLUS’s low-impedance,
high-current output circuitry can easily handle long cable runs without
their associated problems.
Output Voltage Indicators
Setting voltage levels for best signal-to-noise performance can be a real
pain — especially when you have to get out the old digital voltmeter and
nd a way to make those probes stay put while you try to read the dancing
LCD display. With the OVERDRIVE PLUS’s voltage indicator LEDs,
we remove some of the pain. The rst LED indicates that you are in the
OVERDRIVE PLUS’s comfortable working range. The second LED lets
you know you are over 8 Volts and better make sure your amp can take
that much input.
