AXBUCH-TYCAM16V
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 2/11/25 INSTAXBUCH-TYCAM16V
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Cutting tool
• Tape
• Crimping tool
TABLE OF CONTENTS
Connections: LD-TYCAM1 ................................ 2
Back Up Camera Retention Harness
Fits Toyota Select Models 2012-2015
• Retains the factory backup camera to an aftermarket radio
• Includes the AXCSD-6V 12-volt to 6-volt converter
• AXBUCH-TYCAM1V harness
• AXCSD-6V 12-volt to 6-volt converter
For Dash Disassembly Instructions, refer to
metraonline.com. Enter the year, make, and
model of the vehicle in the Vehicle Fit Guide for
Radio Install kits.
APPLICATIONS
Scion
FRS ......................................................2013-2015
iQ .........................................................2014-2015
tC .........................................................2014-2015
xB ........................................................2014-2015
xD .................................................................2014
Toyota
4-Runner
(w/o factory amp) .............2012-2013
Avalon ...............................................2013-2014
Camry ................................................2012-2013
Highlander .................................................2013
Prius ..................................................2012-2015
Prius PHV ..........................................2012-2015
Prius V ...............................................2012-2014
Rav-4 (built before Nov. 2013) .................2014
Rav-4 .........................................................2013
Sequoia ...................................................... 2013
Venza ................................................2013-2014
Visit AxxessInterfaces.com for more detailed
information about the product and up-to-date
vehicle specific applications.
