Installation instructions for part AXDI-GLMLN29

REV. 1/20/2020 INSTAXDI-GLMLN29

axxessinterfaces.com

•

metraonline.com

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, and speed sense)

• Retains chimes through an onboard speaker

• Pre-wired AXSWC harness (AXSWC sold separately)

• Designed for non-amplified models, analog amplified models,

or when bypassing a factory amp

• Retains balance and fade

• Micro-B USB updatable

INTERFACE FEATURES

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (i.e. butt-connectors, bell caps, etc.)

TOOLS REQUIRED

AXDI-GLMLN29

GM Data Interface

2006-Up

Connections to be made ................................................ 2-3

Installing the AXDI-GLMLN29 ........................................... 3

Initializing the AXDI-GLMLN29 ......................................... 3

TABLE OF CONTENTS

INTERFACE COMPONENTS

• AXDI-GLMLN29 interface • AXDI-GLMLN29 harness

APPLICATIONS

See application list inside cover

AXDI-GLMLN29

Connections to be madeApplication

From the AXDI-GLMLN29 harness to the aftermarket radio:

• Connect the Black wire to the ground wire.

• Connect the Yellow wire to the battery wire.

• Connect the Red wire to the accessory wire.

• Connect the Blue wire to the amp turn on wire.

• If the aftermarket radio has an illumination wire, connect the Orange wire to it.

• Connect the Gray wire to the right front positive speaker output.

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the White wire to the left front positive speaker output.

• Connect the White/Black wire to the left front negative speaker output.

• Connect the Green wire to the left rear positive speaker output.

• Connect the Green/Black wire to the left rear negative speaker output.

• Connect the Purple wire to the right rear positive speaker output.

• Connect the Purple/Black wire to the right rear negative speaker output.

The following (3) wires are only for multimedia/navigation radios that require these wires.

• Connect the Blue/Pink wire to the VSS/speed sense wire.

• Connect the Green/Purple wire to the reverse wire.

• Connect the Light Green wire to the parking brake wire.

BUICK

Enclave 2008-up

Lucerne 2006-2011

CADILLAC

DTS 2006-2011 †

Escalade, Escalade ESV

& EXT 2007-2011 †

SRX 2007-2009 †

CHEVROLET

Avalanche

(without RPO code STZ

or Y91) ∆ * 2007-2013

Captiva Sport 2012-2015

Equinox 2007-2009

Express 2008-up ‡

Impala 2006-2013

Impala Limited 2014-2016

Monte Carlo 2006-2007

Silverado (new body)

(without RPO code Y91) ∆*

2007-2013

Silverado 2500/3500

(without RPO code Y91)

∆*

2014

Suburban (without RPO

code STZ or Y91) ∆ *

2007-2014

Tahoe (without RPO code

STZ or Y91) ∆* 2007-2014

Traverse 2009-up

GMC

Acadia 2007-2016

Acadia Limited 2017

Savana 2008-up ‡

Sierra 2500/3500

(without RPO code Y91) ∆*

2014

Sierra (new body)

(without RPO code Y91) ∆*

2007-2013

Yukon (without RPO code

STZ or Y91) ∆* 2007-2014

Yukon XL (without RPO

code STZ or Y91) ∆*

2007-2014

HUMMER

H2 2008-2009 †

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

Vue 2008-2010

SUZUKI

XL-7 2007-2009

* These vehicles have a digital amp option. Please reference the “Service Parts

Identification” sticker located in the glove box for the RPO code listed. If the RPO code

listed is present, the vehicle is equipped with a digital amplifier. Either use the

AXDIS-GMLN29 interface, or bypass the amp.

† These vehicles are standard for a digital amplifier. Either use the AXDIS-GMLN29 interface,

or bypass the amp.

‡ Only for models without NAV in 2011-2015 ∆ Only for models without NAV in 2012-Up.

Continued on the next page
