AXDIS-TY1
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 11/22/24 INSTAXDIS-TY1
INTERFACE FEATURES
INTERFACE COMPONENTS
• Wire cutter
• Crimp tool
• Solder gun
• Tape
• Small flat-blade screwdriver
• Connectors (example: butt-
connectors, bell caps, etc.)
TABLE OF CONTENTS
Applications ...........................................................2
Connections:
Non-Amplified Models:
LD-TYNOAMP .................3
Amplified Models: LD-BX-TY2
.............................4
3.5mm Jack Steering Wheel Control Retention
....5
Installing the AXDIS-TY1 ........................................5
Programming the AXDIS-TY1 ................................6
Audio Level Adjustment .......................................6
Steering Wheel Control Settings .....................7-10
LED Feedback .......................................................7
Changing Radio Type ..........................................8
Remapping the SWC Buttons .........................8-9
Dual Assignment Instructions
........................... 10
Troubleshooting.................................................... 11
Fits Lexus/Toyota Interface with SWC 2001-2015
• AXDIS-TY1 interface
• AXDIS-TY1 harnesses (LD-TYNOAMP, LD-BX-TY2 AND LD-2NAVAMP)
• Female 3.5mm connector with stripped leads
Visit AxxessInterfaces.com for more detailed information
about the product and up-to-date vehicle specific applications.
• Designed for both amplified and non-amplified models
• Provides accessory power (12-volt 10-amp)
• Retains audio controls on the steering wheel
• Provides NAV outputs (parking brake, reverse)
• Retains the factory AUX-IN jack
• Retains balance on amplified models
(non-amplifed models will retain balance and fade)
• Micro-B USB updatable
APPLICATIONS (See Page 2)
TOOLS REQUIRED
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
MetraOnline.com may be used
to assist with dash assembly
instructions. Simply enter your
Year, Make, Model vehicle into
the vehicle fit guide and look
for the Dash Kit Installation
Instructions.
Product Info
www.MetraOnline.com
2
APPLICATIONS
APPLICATIONS
LEXUS
ES Series .............................................................2007-2012
ES Series (Multi-Disc) .........................................2002-2006
GS Series ............................................................. 2001-2005
IS Series ..............................................................2002-2005
LS Series ..............................................................2001-2008
LX Series .............................................................2001-2007
RX Series ............................................................. 2001-2009
TOYOTA
4Runner .............................................................. 2003-2013
Avalon (Non-NAV) .............................................2013-2014
Camry..................................................................2007-2014
Corolla .................................................................2009-2015
FJ Cruiser.............................................................2011-2014
Highlander ..........................................................2012-2013
Prius .................................................................... 2010-2014
RAV4 ...................................................................2004-2014
TOYOTA (CONT)
Sequoia ............................................................... 2005-2013
Sienna ................................................................. 2004-2014
Solara .................................................................. 2004-2008
Tacoma ...............................................................2005-2013
Tundra .................................................................2006-2013
Tundra (4 -Door ) ...............................................2004-2005
Venza ..................................................................2009-2013
