Installation instructions for part AXGMLN-01
REV. 8/6/2020 INSTAXGMLN-01
axxessinterfaces.com
•
metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Axxess Integrate
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake,
reverse, speed sense)
• Pre-wired AXSWC harness (AXSWC sold
separately)
• Retains chimes to the factory speaker
• Adjustable chime level
• Retains OnStar / OE Bluetooth
• Adjustable OnStar level
• Retains the factory backup camera
• Designed for non-amplified models, or
when bypassing a factory amp
• Retains balance and fade
• Includes an antenna adapter
• AXUSB-CBL updatable (sold separately)
INTERFACE FEATURES
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
• Small flat-blade screwdriver
TOOLS REQUIRED
AXGMLN-01
GM Data Interface
2006-Up
• AXGMLN-01 interface • AXGMLN-01 harness
• 16-pin harness with stripped leads • Backup camera harness • Antenna adapter
INTERFACE COMPONENTS
Connections to be made ................................................ 2-3
Installing the AXGMLN-01 ................................................ 3
Initializing the AXGMLN-01 .............................................. 3
Adjusting the AXGMLN-01 ................................................ 4
Table of Contents
APPLICATIONS
See inside front cover
AXGMLN-01
2
Applications
From the 16-pin harness with stripped leads to the aftermarket radio:
• Connect the Red wire to the accessory wire.
Note: If installing an AXSWC (sold separately), there will be an accessory wire
there to connect as well.
• If the aftermarket radio has an illumination wire, connect the Orange/White
wire to it.
• If the aftermarket radio has a mute wire, connect the Brown wire to it. If the
mute wire is not connected, the radio will turn off when OnStar is activated.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
The following (3) wires are only for multimedia/navigation radios that require these wires
.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
Connections to be made
† These vehicles are standard for a factory amplifier. Either use the AXGMLN-02 interface,
or bypass the amplifier.
‡ Only for models without NAV in 2011-2015. For models with NAV, use the AXGMLN-08.
∆ Only for models without NAV in 2012-up. For models with NAV, use the AXGMLN-08.
BUICK
Enclave 2008-up
Lucerne 2006-2011
CADILLAC
DTS † 2006-2011
Escalade † 2007-2014
SRX † 2007-2009
CHEVROLET
Avalanche ∆ 2007-2013
Captiva Sport 2012-2015
Equinox 2007-2009
Express ‡ 2008-up
Impala 2006-2013
Impala Limited 2014-2016
Monte Carlo 2006-2007
Silverado (new body) ∆ 2007-2013
Silverado 2500/3500 ∆ 2014
Suburban ∆ 2007-2014
Tahoe ∆ 2007-2014
Traverse 2009-up
GMC
Acadia 2007-2016
Acadia Limited 2017
Savana ‡ 2008-up
Sierra 2500/3500 ∆ 2014
Sierra (new body) ∆ 2007-2013
Yukon / Yukon XL ∆ 2007-2014
HUMMER
H2 † 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
Vue 2008-2010
SUZUKI
XL-7 2007-2009
