Side 1/2

AXVI-1785 AXVI-1785

1-800-221-0932 metraonline.com

AXVI-1785 AXVI-1785

1-800-221-0932 metraonline.com

AXVI-1785

Mercedes accessory and NAV output CAN Interface 2001-2004

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Used in non-amplified systems, or when replacing amplified system

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

APPLICATIONS

WIRING THE AXVI-1785

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio.

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the Orange wire.

• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.

• Connect the White wire to the left front positive speaker output of the

aftermarket radio.

• Connect the White/Black wire to the left front negative speaker output of the

aftermarket radio.

WIRING THE AXVI-1785

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio.

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the Orange wire.

• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.

• Connect the White wire to the left front positive speaker output of the

aftermarket radio.

• Connect the White/Black wire to the left front negative speaker output of the

aftermarket radio.

WIRING THE AXVI-1785

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio.

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the Orange wire.

• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.

• Connect the White wire to the left front positive speaker output of the

aftermarket radio.

• Connect the White/Black wire to the left front negative speaker output of the

aftermarket radio.

WIRING THE AXVI-1785

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio.

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the Orange wire.

• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.

• Connect the White wire to the left front positive speaker output of the

aftermarket radio.

• Connect the White/Black wire to the left front negative speaker output of the

aftermarket radio.

AXVI-1785

Mercedes accessory and NAV output CAN Interface 2001-2004

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Used in non-amplified systems, or when replacing amplified system

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

APPLICATIONS

AXVI-1785

Mercedes accessory and NAV output CAN Interface 2001-2004

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Used in non-amplified systems, or when replacing amplified system

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

MERCEDES

C Class 2001-2004

CLK Class 2004

CLK500 2003

CLK55AMG 2003

APPLICATIONS

AXVI-1785

Mercedes accessory and NAV output CAN Interface 2001-2004

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Used in non-amplified systems, or when replacing amplified system

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

APPLICATIONS

MERCEDES

C Class 2001-2004

CLK Class 2004

CLK500 2003

CLK55AMG 2003

MERCEDES

C Class 2001-2004

CLK Class 2004

CLK500 2003

CLK55AMG 2003

MERCEDES

C Class 2001-2004

CLK Class 2004

CLK500 2003

CLK55AMG 2003

AXVI-1785 AXVI-1785

1-800-221-0932 metraonline.com

AXVI-1785 AXVI-1785

1-800-221-0932 metraonline.com

• Connect the Gray wire to the right front positive speaker output of the

aftermarket radio.

• Connect the Gray/Black wire to the right front negative speaker output of the

aftermarket radio.

• Connect the Green wire to the radio’s left rear positive speaker output.

• Connect the Green/Black wire to the radio’s left rear negative speaker output.

• Connect the Purple wire to the radio’s right rear positive speaker output.

• Connect the Purple/Black wire to the radio’s right rear negative speaker output.

The following wires are for the aftermarket radios that have navigation built in.

• Connect the Light Green wire to the parking brake wire of the aftermarket

navigation radio (if applicable).

• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket

navigation radio (if applicable).

• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation

radio (if applicable).

• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to

test the radio.

AXSWC (if installing)

After the interface is initialized, plug in the AXSWC into the 12-pin harness of the

AXVI-1785 and refer to the AXSWC instructions.

Caution: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

Note: Refer to the instructions included with the

aftermarket radio.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certified technicians

Caution: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

Note: Refer to the instructions included with the

aftermarket radio.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certified technicians

Caution: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

Note: Refer to the instructions included with the

aftermarket radio.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certified technicians

Caution: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

Note: Refer to the instructions included with the

aftermarket radio.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certified technicians

• Connect the Gray wire to the right front positive speaker output of the

aftermarket radio.

• Connect the Gray/Black wire to the right front negative speaker output of the

aftermarket radio.

• Connect the Green wire to the radio’s left rear positive speaker output.

• Connect the Green/Black wire to the radio’s left rear negative speaker output.

• Connect the Purple wire to the radio’s right rear positive speaker output.

• Connect the Purple/Black wire to the radio’s right rear negative speaker output.

The following wires are for the aftermarket radios that have navigation built in.

• Connect the Light Green wire to the parking brake wire of the aftermarket

navigation radio (if applicable).

• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket

navigation radio (if applicable).

• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation

radio (if applicable).

• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to

test the radio.

AXSWC (if installing)

After the interface is initialized, plug in the AXSWC into the 12-pin harness of the

AXVI-1785 and refer to the AXSWC instructions.

• Connect the Gray wire to the right front positive speaker output of the

aftermarket radio.

• Connect the Gray/Black wire to the right front negative speaker output of the

aftermarket radio.

• Connect the Green wire to the radio’s left rear positive speaker output.

• Connect the Green/Black wire to the radio’s left rear negative speaker output.

• Connect the Purple wire to the radio’s right rear positive speaker output.

• Connect the Purple/Black wire to the radio’s right rear negative speaker output.

The following wires are for the aftermarket radios that have navigation built in.

• Connect the Light Green wire to the parking brake wire of the aftermarket

navigation radio (if applicable).

• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket

navigation radio (if applicable).

• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation

radio (if applicable).

• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to

test the radio.

AXSWC (if installing)

After the interface is initialized, plug in the AXSWC into the 12-pin harness of the

AXVI-1785 and refer to the AXSWC instructions.

• Connect the Gray wire to the right front positive speaker output of the

aftermarket radio.

• Connect the Gray/Black wire to the right front negative speaker output of the

aftermarket radio.

• Connect the Green wire to the radio’s left rear positive speaker output.

• Connect the Green/Black wire to the radio’s left rear negative speaker output.

• Connect the Purple wire to the radio’s right rear positive speaker output.

• Connect the Purple/Black wire to the radio’s right rear negative speaker output.

The following wires are for the aftermarket radios that have navigation built in.

• Connect the Light Green wire to the parking brake wire of the aftermarket

navigation radio (if applicable).

• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket

navigation radio (if applicable).

• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation

radio (if applicable).

• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to

test the radio.

AXSWC (if installing)

After the interface is initialized, plug in the AXSWC into the 12-pin harness of the

AXVI-1785 and refer to the AXSWC instructions.

Produkt Specifikationer

Mærke:	Axxess
Kategori:	Ikke kategoriseret
Model:	AXVI-1785

Har du brug for hjælp?

Hvis du har brug for hjælp til Axxess AXVI-1785 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Ikke kategoriseret Axxess Manualer

Axxess AXVI-1785 Manual

8 Oktober 2025

Axxess AXGMLN-09 Manual

7 Oktober 2025

Axxess AXBUCH-TYCAM16V Manual

7 Oktober 2025

Axxess AX-LOC4.4-PRO Manual

7 Oktober 2025

Axxess AXVI-1788 Manual

7 Oktober 2025

Axxess AXDSPH-GL44 Manual

7 Oktober 2025

Axxess AXAC-CH5 Manual

7 Oktober 2025

Axxess LOC-CHH3 Manual

7 Oktober 2025

Axxess AXDSPX-HK4 Manual

7 Oktober 2025

Axxess AX-NISUSB-1 Manual

7 Oktober 2025

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Panduit CEG-23X1 Manual

8 Oktober 2025

Vestil EHLTT-H-3648-2-47 Manual

8 Oktober 2025

Teesa Aroma 300 TSA4002 Manual

8 Oktober 2025

Lofrans Remote Control Manual

8 Oktober 2025

LG SH-T4TA77 Manual

8 Oktober 2025

Martin Audio Wavefront WS2A Manual

8 Oktober 2025

Vollrath Cayenne 7277148 Manual

8 Oktober 2025

Panduit PR2HF4 Manual

8 Oktober 2025

Vestil EHLT-N-1648-2-32 Manual

8 Oktober 2025

Panduit CEG-15X1 Manual

8 Oktober 2025
