AXVI-1788
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
AXVI-1788
AXVI-1788 AXVI-1788
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
FEATURES
Provides accessory power (12-volt 10-amp)
Retains R.A.P. (retained accessory power)
Provides NAV outputs (parking brake, reverse, and speed sense)
Prewired AXSWC harness (AXSWC sold separately)
Retains balance and fade
USB updatable
FEATURES
Provides accessory power (12-volt 10-amp)
Retains R.A.P. (retained accessory power)
Provides NAV outputs (parking brake, reverse, and speed sense)
Prewired AXSWC harness (AXSWC sold separately)
Retains balance and fade
USB updatable
AXVI-1788
Dodge Sprinter 2008-2009 /
Freightliner Sprinter 2008-up
Accessory and NAV Output CAN Interface
AXVI-1788
Dodge Sprinter 2008-2009 /
Freightliner Sprinter 2008-up
Accessory and NAV Output CAN Interface
Connections to be made
Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
Connect the Black wire to the radio’s ground wire.
Connect the Red wire to the ignition wire of the aftermarket radio.
Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
Connect the White wire to the left front positive speaker output of the aftermarket radio
.
Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
Connect the Gray wire to the right front positive speaker output of the aftermarket radio.
Connections to be made
Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
Connect the Black wire to the radio’s ground wire.
Connect the Red wire to the ignition wire of the aftermarket radio.
Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
Connect the White wire to the left front positive speaker output of the aftermarket radio
.
Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
Connect the Gray wire to the right front positive speaker output of the aftermarket radio.
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator
lights must be connected before cycling the ignition. Also, do not remove the factory radio with
the key in the on position, or while the vehicle is running.
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator
lights must be connected before cycling the ignition. Also, do not remove the factory radio with
the key in the on position, or while the vehicle is running.
CARACTERÍSTICAS
Provee corriente de accesorios (12 voltios 10 amperes)
Retiene R.A.P. (corriente de accesorio retenida)
Proporciona salidas de NAV (freno de mano, reversa y sensor de velocidad
)
Arnés AXSWC pre cableado (el AXSWC se vende por separado)
Retiene el balance y la intensidad
Actualizable mediante USB
CARACTERÍSTICAS
Provee corriente de accesorios (12 voltios 10 amperes)
Retiene R.A.P. (corriente de accesorio retenida)
Proporciona salidas de NAV (freno de mano, reversa y sensor de velocidad
)
Arnés AXSWC pre cableado (el AXSWC se vende por separado)
Retiene el balance y la intensidad
Actualizable mediante USB
Conexiones que se deben hacer
Conecte el cable amarillo con la batería de 12 voltios o el cable de memoria del radio.
Conecte el cable negro con el cable de puesta a tierra del radio.
Conecte el cable rojo con el cable de ignición del radio de mercado secundario.
Conecte el cable anaranjado con el cable de iluminación del radio de mercado secundario. Si el
radio de mercado secundario no tiene cable de iluminación, cubra con cinta el cable anaranjado.
Conecte el cable azul con el cable de encendido de la antena del radio de mercado secundario
.
Conecte el cable blanco con la salida de la bocina positiva frontal izquierda del radio
de mercado secundario.
Conecte el cable blanco/negro con la salida negativa de la bocina frontal izquierda del
radio de mercado secundario.
Conecte el cable gris con la salida positiva de la bocina frontal derecha del radio de
mercado secundario.
Conecte el cable gris/negro con la salida negativa de la bocina frontal derecha del
radio de mercado secundario.
Conexiones que se deben hacer
Conecte el cable amarillo con la batería de 12 voltios o el cable de memoria del radio.
Conecte el cable negro con el cable de puesta a tierra del radio.
Conecte el cable rojo con el cable de ignición del radio de mercado secundario.
Conecte el cable anaranjado con el cable de iluminación del radio de mercado secundario. Si el
radio de mercado secundario no tiene cable de iluminación, cubra con cinta el cable anaranjado.
Conecte el cable azul con el cable de encendido de la antena del radio de mercado secundario
.
Conecte el cable blanco con la salida de la bocina positiva frontal izquierda del radio
de mercado secundario.
Conecte el cable blanco/negro con la salida negativa de la bocina frontal izquierda del
radio de mercado secundario.
Conecte el cable gris con la salida positiva de la bocina frontal derecha del radio de
mercado secundario.
Conecte el cable gris/negro con la salida negativa de la bocina frontal derecha del
radio de mercado secundario.
AXVI-1788
Dodge Sprinter 2008-2009 /
Freightliner Sprinter 2008 y mas
Interfase CAN para accesorios y salida NAV
AXVI-1788
Dodge Sprinter 2008-2009 /
Freightliner Sprinter 2008 y mas
Interfase CAN para accesorios y salida NAV
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de clima y especialmente
las luces del indicador de las bolsas de aire deben estar conectados antes ciclar la ignición. Además,
no quite el radio de fábrica con la llave en la posición o de encendido ni con el vehículo funcionando.
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de clima y especialmente
las luces del indicador de las bolsas de aire deben estar conectados antes ciclar la ignición. Además,
no quite el radio de fábrica con la llave en la posición o de encendido ni con el vehículo funcionando.
AXVI-1788
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
AXVI-1788
AXVI-1788 AXVI-1788
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
Conecte el cable verde con la salida de la bocina positiva izquierda de atrás
del radio.
Conecte el cable verde/negro con la salida negativa de la bocina izquierda de
atrás del radio.
Conecte el cable púrpura con la salida positiva de la bocina derecha de atrás del radio.
Conecte el cable púrpura/negro con la salida negativa de la bocina derecha de
atrás del radio.
Los siguientes (3) cables son para radios de mercado secundario que tienen navegación integrada.
Conecte el cable verde claro con el cable del freno de mano del radio de navegación
de mercado secundario (si aplica).
Conecte el cable azul/rosa con el cable V.S.S. o de detección de velocidad del radio
de navegación de mercado secundario (si aplica).
Conecte el cable verde/púrpura al cable de reversa del radio con navegación de
mercado secundario (si aplica).
INICIALIZACIÓN DEL AXVI-1788
Atención! Si la interfase pierde energía por cualquier razón, tendrán que volverse a
ejecutar los siguientes pasos. Si va a utilizar el AXSWC, conéctelo después de inicializar
y probar el interfase/radio con la llave en la posición de apagado.
Gire la llave (o pulsar para botón de inicio) a la posición de encendido and y esperar
hasta que la radio se enciende.
Nota: Si la radio no se enciende dentro de 60 segundos, gire la llave a la posición
de apagado, desconecte la interfase, compruebe todas las conexiones, vuelva a
conectar la interfase, y vuelva a intentarlo.
Gire la llave a la posición de apagado, y luego a la posición de accesorios. Pruebe
todas las funciones de la instalación para su correcto funcionamiento, antes de
volver a montar el tablero.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
®
Metra recomienda técnicos
con certificación del Programa
de Certificación en Electrónica
Móvil (Mobile Electronics
Certification Program, MECP).
EL CONOCIMIENTO ES PODER
Mejore sus habilidades de instalación y
fabricación inscribiéndose en la escuela de
dispositivos electrónicos móviles más reconocida
y respetada de nuestra industria. Regístrese en
www.installerinstitute.com o llame al
800-354-6782 para obtener más información y
avance hacia un futuro mejor.
Conecte el cable verde con la salida de la bocina positiva izquierda de atrás
del radio.
Conecte el cable verde/negro con la salida negativa de la bocina izquierda de
atrás del radio.
Conecte el cable púrpura con la salida positiva de la bocina derecha de atrás del radio.
Conecte el cable púrpura/negro con la salida negativa de la bocina derecha de
atrás del radio.
Los siguientes (3) cables son para radios de mercado secundario que tienen navegación integrada.
Conecte el cable verde claro con el cable del freno de mano del radio de navegación
de mercado secundario (si aplica).
Conecte el cable azul/rosa con el cable V.S.S. o de detección de velocidad del radio
de navegación de mercado secundario (si aplica).
Conecte el cable verde/púrpura al cable de reversa del radio con navegación de
mercado secundario (si aplica).
INICIALIZACIÓN DEL AXVI-1788
Atención! Si la interfase pierde energía por cualquier razón, tendrán que volverse a
ejecutar los siguientes pasos. Si va a utilizar el AXSWC, conéctelo después de inicializar
y probar el interfase/radio con la llave en la posición de apagado.
Gire la llave (o pulsar para botón de inicio) a la posición de encendido and y esperar
hasta que la radio se enciende.
Nota: Si la radio no se enciende dentro de 60 segundos, gire la llave a la posición
de apagado, desconecte la interfase, compruebe todas las conexiones, vuelva a
conectar la interfase, y vuelva a intentarlo.
Gire la llave a la posición de apagado, y luego a la posición de accesorios. Pruebe
todas las funciones de la instalación para su correcto funcionamiento, antes de
volver a montar el tablero.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
®
Metra recomienda técnicos
con certificación del Programa
de Certificación en Electrónica
Móvil (Mobile Electronics
Certification Program, MECP).
EL CONOCIMIENTO ES PODER
Mejore sus habilidades de instalación y
fabricación inscribiéndose en la escuela de
dispositivos electrónicos móviles más reconocida
y respetada de nuestra industria. Regístrese en
www.installerinstitute.com o llame al
800-354-6782 para obtener más información y
avance hacia un futuro mejor.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Connect the Gray/Black wire to the right front negative speaker output of
the aftermarket radio.
Connect the Green wire to the radio’s left rear positive speaker output.
Connect the Green/Black wire to the radio’s left rear negative speaker output.
Connect the Purple wire to the radio’s right rear positive speaker output.
Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following (3) wires are for the aftermarket radios that have navigation built in.
Connect the Light Green wire to the parking brake wire of the aftermarket
navigation radio (if applicable).
Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
Connect the Green/Purple wire to the reverse wire of the aftermarket navigation
radio (if applicable).
INITIALIZING THE AXVI-1788
Attention! If the interface loses power for any reason, the following steps will need to
be performed again. Also, if installing an AXSWC connect it after you initialize and test
the interface/radio, with the key in the off position.
Turn the key (or push-to-start button) to the ignition position and wait until the radio
comes on.
Note: If the radio does not come on within 60 seconds, turn the key to the off
position, disconnect the interface, check all connections, reconnect the interface,
and then try again.
Turn the key to the off position, and then to the accessory position. Test all functions
of the installation for proper operation, before reassembling the dash.
Connect the Gray/Black wire to the right front negative speaker output of
the aftermarket radio.
Connect the Green wire to the radio’s left rear positive speaker output.
Connect the Green/Black wire to the radio’s left rear negative speaker output.
Connect the Purple wire to the radio’s right rear positive speaker output.
Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following (3) wires are for the aftermarket radios that have navigation built in.
Connect the Light Green wire to the parking brake wire of the aftermarket
navigation radio (if applicable).
Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
Connect the Green/Purple wire to the reverse wire of the aftermarket navigation
radio (if applicable).
INITIALIZING THE AXVI-1788
Attention! If the interface loses power for any reason, the following steps will need to
be performed again. Also, if installing an AXSWC connect it after you initialize and test
the interface/radio, with the key in the off position.
Turn the key (or push-to-start button) to the ignition position and wait until the radio
comes on.
Note: If the radio does not come on within 60 seconds, turn the key to the off
position, disconnect the interface, check all connections, reconnect the interface,
and then try again.
Turn the key to the off position, and then to the accessory position. Test all functions
of the installation for proper operation, before reassembling the dash.


Produkt Specifikationer

Mærke: Axxess
Kategori: Ikke kategoriseret
Model: AXVI-1788

Har du brug for hjælp?

Hvis du har brug for hjælp til Axxess AXVI-1788 stil et spørgsmål nedenfor, og andre brugere vil svare dig




Ikke kategoriseret Axxess Manualer

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer
