INSTAXVI-9003
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
INSTAXVI-9003
INSTAXVI-9003 INSTAXVI-9003
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following wires are for the aftermarket radios that have navigation built in.
• Connect the Light Green wire to the parking brake wire of the aftermarket navigation
radio (if applicable).
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio
(if applicable).
• Cycle the key by turning the ignition on for 30 seconds, then “off” and “on” again to
test the radio.
AXSWC (if installing)
After the interface is initialized, plug in the AXSWC into the 12 pin harness of the
AXVI-9003 and refer to the AXSWC instructions.
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following wires are for the aftermarket radios that have navigation built in.
• Connect the Light Green wire to the parking brake wire of the aftermarket navigation
radio (if applicable).
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio
(if applicable).
• Cycle the key by turning the ignition on for 30 seconds, then “off” and “on” again to
test the radio.
AXSWC (if installing)
After the interface is initialized, plug in the AXSWC into the 12 pin harness of the
AXVI-9003 and refer to the AXSWC instructions.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following wires are for the aftermarket radios that have navigation built in.
• Connect the Light Green wire to the parking brake wire of the aftermarket navigation
radio (if applicable).
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio
(if applicable).
• Cycle the key by turning the ignition on for 30 seconds, then “off” and “on” again to
test the radio.
AXSWC (if installing)
After the interface is initialized, plug in the AXSWC into the 12 pin harness of the
AXVI-9003 and refer to the AXSWC instructions.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following wires are for the aftermarket radios that have navigation built in.
• Connect the Light Green wire to the parking brake wire of the aftermarket navigation
radio (if applicable).
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio
(if applicable).
• Cycle the key by turning the ignition on for 30 seconds, then “off” and “on” again to
test the radio.
AXSWC (if installing)
After the interface is initialized, plug in the AXSWC into the 12 pin harness of the
AXVI-9003 and refer to the AXSWC instructions.
