INSTALLATION INSTRUCTIONS FOR PART GMOS-LAN-09

METRA. The World’s best kits.™ metraonline.com1-800-221-0932

REV. 9/11/2014 INSTGMOS-LAN-09

CAUTION: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE: Refer to the instructions included with the

aftermarket radio.

• Providesaccessory(12-volt10-amp)

• RetainsR.A.P.(RetainedAccessoryPower)

• Usedinnon-amplifiedsystems

• Retainschimes

• ProvidesNAVoutputs(ParkingBrake,

Reverse,Mute,andspeedsense)

• RetainsOnStar/OEBluetooth

• AdjustablevolumeforchimesandOnStar

• RetainsOEAUXinput

• Highlevelspeakerinput

• USBupdatable

• Retainsbalanceandfade

• PrewiredASWC-1harness(ASWC-1sold

separately)

KIT FEATURES

•Cuttingtool•Crimpingtool•Tape•Connectors

(example:butt-connectors,bellcaps,etc.)

TOOLS REQUIRED

LAN-29 Data Interface

2014-up

GMOS-LAN-09

APPLICATIONS

•GMOS-LAN-09interface•GMOS-LAN-09

harness•16-pinharnesswithstrippedleads

INTERFACE COMPONENTS

CHEVROLET

Silverado1500 2014-up

Silverado2500/3500 2015-up

Suburban 2015-up

Tahoe 2015-up

GMC

Sierra1500 2014-up

Sierra2500/3500 2015-up

Yukon 2015-up

GMOS-LAN-09

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connectthe(2)Redwirestotheaccessorywire.

 Note: If installing the ASWC-1, there will be an accessory wire in the

12-pin harness to connect as well.

• ConnecttheOrange/White wiretotheilluminationwire.Iftheaftermarket

radiohasnoilluminationwire,tapeofftheOrange/Whitewire.

• ConnecttheWhite wiretotheleftfrontpositivespeakeroutput.

• ConnecttheWhite/Blackwiretotheleftfrontnegativespeakeroutput.

• Connectthe Gray wiretotherightfrontpositivespeakeroutput.

• ConnecttheGray/Blackwiretotherightfrontnegativespeakeroutput.

• ConnecttheBlue/White wiretotheampturn-onwire.

Note: This wire must be connected to turn the interface on.

• ConnecttheBrown wiretothemutewire.Iftheaftermarketradiodoesnot

haveaMutewire,tapeupthe Brown wire.Ifthe Brownwireisnotconnected,

theradiowillturnoffwhenOnStarisactivated.

Thefollowingwiresarefortheaftermarketradiosthathavenavigationbuiltin:

• ConnecttheLight Greenwiretotheparkingbrakewire(ifapplicable).

• ConnecttheBlue/Pinkwiretothespeedsensewire(ifapplicable).

• Connectthe Green/Purplewiretothereversewire(ifapplicable).

From the GMOS-LAN-09 harness:

(a) 16-pin harness to the aftermarket radio:

• ConnecttheYellowwiretothe12-voltbatterywire.

• ConnecttheBlack wiretothegroundwire.

• ConnecttheGreenwiretotheleftrearpositivespeakeroutput.

• ConnecttheGreen/Blackwiretotheleftrearnegativespeakeroutput.

• ConnectthePurplewiretotherightrearpositivespeakeroutput.

• ConnectthePurple/Blackwiretotherightrearnegativespeakeroutput.

(b) 22-pin harness to the aftermarket radio:

• TheBlack/YellowwireisfortheOnStarvolumeadjustment.Thiswillbe

discussedintheOnStarLevelAdjustmentsectionofthisinstruction.

• TheDINconnectorisforusewiththeoptionalAX-LCD(soldseparately).This

willgiveyoutheoptionofchangingthesettingsinyourpersonalizationmenu.

• ConnecttheWhiteRCAtotheaftermarketradio’sleftAudioAUXin.

• ConnecttheRedRCAtotheaftermarketradio’srightAudioAUXin.

Note: To retain the factory 3.5mm jack, the radio must have an Audio AUX in.

Connections to be made
