Side 1/2
INSTGMRSAV
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 10/14/13
INSTGMRSAV
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 10/14/13
INSTGMRSAV
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 10/14/13
INSTGMRSAV
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 10/14/13
The GMRSAV is designed to provide an audio/video input to the
OEM overhead video screen from the aftermarket radio, and provide
the audio/video input from the rear seat control panel to the
aftermarket radio.
GMRSAV
INTRODUCTION
BUICK
Enclave 2008-up
CADILLAC
Escalade/ESV/EXT 2007-2011
SRX 2007-2009
CHEVROLET
Avalanche 2007-2011
Avalanche without NAV 2012-up
Silverado 2007-2011
Silverado without NAV 2012-2013
Suburban 2007-2011
Suburban without NAV 2012-up
Tahoe 2007-2011
Tahoe without NAV 2012-up
Traverse 2009-up
GMC
Acadia 2007-up
Sierra 2007-2013
Yukon 2007-2011
Yukon without NAV 2012-up
HUMMER
H2 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
SUZUKI
XL-7 2007-2009
APPLICATIONS
INTERFACE COMPONENTS
• 16-pin GMLAN RSE harness
TOOLS REQUIRED
• Cutting tool • Tape • Crimping tool
• Connectors (i.e. butt-connectors, bell caps, etc.)
INSTALLATION INSTRUCTIONS
Important: Before beginning any of the following, disconnect the negative
battery terminal to prevent an accidental short circuit.
From the 16-pin harness
Connect the “From rear A/V input” RCAs to the aftermarket radios
audio/video input. Plug Yellow in to video-in, Red to right audio-in,
and White to left audio-in.
Connect the “To overhead screen” RCAs to the aftermarket radios
audio/video output. Plug Yellow in to video-out, Red to right audio-out,
and White to left audio-out.
Connect the Black with the ring terminal to ground.
The GMRSAV is designed to provide an audio/video input to the
OEM overhead video screen from the aftermarket radio, and provide
the audio/video input from the rear seat control panel to the
aftermarket radio.
GMRSAV
INTRODUCTION
BUICK
Enclave 2008-up
CADILLAC
Escalade/ESV/EXT 2007-2011
SRX 2007-2009
CHEVROLET
Avalanche 2007-2011
Avalanche without NAV 2012-up
Silverado 2007-2011
Silverado without NAV 2012-2013
Suburban 2007-2011
Suburban without NAV 2012-up
Tahoe 2007-2011
Tahoe without NAV 2012-up
Traverse 2009-up
GMC
Acadia 2007-up
Sierra 2007-2013
Yukon 2007-2011
Yukon without NAV 2012-up
HUMMER
H2 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
SUZUKI
XL-7 2007-2009
APPLICATIONS
INTERFACE COMPONENTS
16-pin GMLAN RSE harness
TOOLS REQUIRED
Cutting tool Tape Crimping tool
Connectors (i.e. butt-connectors, bell caps, etc.)
INSTALLATION INSTRUCTIONS
Important: Before beginning any of the following, disconnect the negative
battery terminal to prevent an accidental short circuit.
From the 16-pin harness
Connect the “From rear A/V input” RCAs to the aftermarket radios
audio/video input. Plug Yellow in to video-in, Red to right audio-in,
and White to left audio-in.
Connect the “To overhead screen” RCAs to the aftermarket radios
audio/video output. Plug Yellow in to video-out, Red to right audio-out,
and White to left audio-out.
Connect the Black with the ring terminal to ground.
INSTGMRSAV
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 10/14/13
INSTGMRSAV
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 10/14/13
INSTGMRSAV
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 10/14/13
INSTGMRSAV
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 10/14/13
El GMRSAV está diseñado para proporcionar una entrada de audio /
vídeo a la pantalla de vídeo de arriba OEM de la radio del mercado de
accesorios, y proporcionar el audio / entrada de vídeo desde el panel de
control del asiento trasero a la radio no original.
GMRSAV
INTRODUCCIÓN
BUICK
Enclave 2008 y mas
CADILLAC
Escalade/ESV/EXT 2007-2011
SRX 2007-2009
CHEVROLET
Avalanche 2007-2011
Avalanche sin NAV 2012 y mas
Silverado 2007-2011
Silverado sin NAV 2012-2013
Suburban 2007-2011
Suburban sin NAV 2012 y mas
Tahoe 2007-2011
Tahoe sin NAV 2012 y mas
Traverse 2009 y mas
GMC
Acadia 2007-up
Sierra 2007-2013
Yukon 2007-2011
Yukon sin NAV 2012 y mas
HUMMER
H2 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
SUZUKI
XL-7 2007-2009
APLICACIONES
COMPONENTES DE LA INTERFASE
• 16-pin GMLAN RSE arnés
HERRAMIENTAS REQUERIDAS
• Cortador • Pelacables • Cinta
• Conectores (p. ej., conectores a tope, tapas acampanadas, etc.)
INSTRUCCIONES DE INSTALACIÓN
Importante: Antes de empezar el siguiente procedimiento, desconecte la
terminal negativa de la batería para evitar un corto circuito accidental.
Desde el arnés de 16 pins
Conecte los conectores RCA “From rear A/V input” (desde la parte
trasera entrada de A/V) a la entrada de audio/video del radio de
mercado secundario. Conecte el conector amarillo a la entrada de
video, el rojo a la entrada de audio derecha y el blanco a la entrada
de audio izquierda.
Conecte los conectores RCA “To overhead screen” (a la pantalla de
arriba) a la salida de audio/video del radio de mercado secundario.
Conecte el conector amarillo a la salida de video, el rojo a la salida de
audio derecha y el blanco a la salida de audio izquierda.
Conecte el cable negro suelto a tierra.
El GMRSAV está diseñado para proporcionar una entrada de audio /
vídeo a la pantalla de vídeo de arriba OEM de la radio del mercado de
accesorios, y proporcionar el audio / entrada de vídeo desde el panel de
control del asiento trasero a la radio no original.
GMRSAV
INTRODUCCIÓN
BUICK
Enclave 2008 y mas
CADILLAC
Escalade/ESV/EXT 2007-2011
SRX 2007-2009
CHEVROLET
Avalanche 2007-2011
Avalanche sin NAV 2012 y mas
Silverado 2007-2011
Silverado sin NAV 2012-2013
Suburban 2007-2011
Suburban sin NAV 2012 y mas
Tahoe 2007-2011
Tahoe sin NAV 2012 y mas
Traverse 2009 y mas
GMC
Acadia 2007-up
Sierra 2007-2013
Yukon 2007-2011
Yukon sin NAV 2012 y mas
HUMMER
H2 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
SUZUKI
XL-7 2007-2009
APLICACIONES
COMPONENTES DE LA INTERFASE
16-pin GMLAN RSE arnés
HERRAMIENTAS REQUERIDAS
Cortador Pelacables Cinta
Conectores (p. ej., conectores a tope, tapas acampanadas, etc.)
INSTRUCCIONES DE INSTALACIÓN
Importante: Antes de empezar el siguiente procedimiento, desconecte la
terminal negativa de la batería para evitar un corto circuito accidental.
Desde el arnés de 16 pins
Conecte los conectores RCA “From rear A/V input” (desde la parte
trasera entrada de A/V) a la entrada de audio/video del radio de
mercado secundario. Conecte el conector amarillo a la entrada de
video, el rojo a la entrada de audio derecha y el blanco a la entrada
de audio izquierda.
Conecte los conectores RCA “To overhead screen” (a la pantalla de
arriba) a la salida de audio/video del radio de mercado secundario.
Conecte el conector amarillo a la salida de video, el rojo a la salida de
audio derecha y el blanco a la salida de audio izquierda.
Conecte el cable negro suelto a tierra.
