Installation instructions for part HDCC-02

REV. 5/27/2016 INSTHDCC-02

axxessinterfaces.com

•

metraonline.com

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power (12-volt 10-amp)

• Provides NAV outputs (parking brake, reverse, speed sense)

• Pre-wired ASWC-1 harness (ASWC-1 sold separately)

• Retains factory backup camera

• Retains LaneWatch camera

• Retains ability to change factory clock and date

• Retains factory AUX-IN jack

• Can be used in non-amplified, or amplified models

• High level speaker input

• Retains balance and fade

• Micro “B” USB updatable

FEATURES

• Cutting tool • Crimping tool • Tape • Connectors

(example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED

HDCC-02

Honda LaneWatch camera retention

2014-up

• HDCC-02 interface • HDCC-02 harness

INTERFACE COMPONENTS

APPLICATIONS

HONDA

Civic 2014-2015

CR-V 2015-up

HDCC-02

Connections to be made

From the HDCC-02 harness to the aftermarket radio

(a) Main harness:

• Connect the Black wire to the ground wire.

• Connect the Yellow wire to the battery wire.

• Connect the Red wire to the accessory wire.

• If the vehicle is equipped with a factory amp, connect the Blue/White wire to

the amp turn-on wire.

Note: This wire must be connected to hear sound from the factory amplifier.

• Connect the White wire to the left front positive speaker output.

• Connect the White/Black wire to the left front negative speaker output.

• Connect the Gray wire to the right front positive speaker output.

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the Green wire to the left rear positive speaker output.

• Connect the Green/Black wire to the left rear negative speaker output.

• Connect the Purple wire to the right rear positive speaker output.

• Connect the Purple/Black wire to the right rear negative speaker output.

(b) 16-pin harness:

• Connect the Orange/White wire to the illumination wire (if the aftermarket

radio has no illumination wire, tape off and disregard this wire).

The following (3) wires are for aftermarket multimedia/navigation radios that

require these wires:

• Connect the Light Green wire to the parking brake wire (if applicable).

• Connect the Blue/Pink wire to the speed sense wire (if applicable).

• Connect the Green/Purple wire to the reverse wire (if applicable).

• Connect the Yellow RCA jack to the backup camera input (if applicable).

Note: This RCA jack is used to retain the backup camera as well as the

LaneWatch camera.

• Connect the White and Red RCA jacks to the audio AUX-IN jacks (if applicable).

• If the vehicle is equipped with a factory amp, connect the White RCA jack to the

subwoofer output jack.

(d) 12-pin pre-wired ASWC-1 harness:

• This harness is to be used in along with the optional ASWC-1 (not included)

to retain steering wheel audio controls. If the ASWC-1 is not being used,

disregard this harness. If it will be used, please refer to the ASWC-1

instructions for radio connections and programming.

Note: Disregard the harness that comes with the ASWC-1.

Installing the HDCC-02

With the key in the off position:

• Connect the 22-pin connector of the HDCC-02 harness, into the

HDDC-02 interface.

• Connect the (2) 24-pin, 12-pin, 8-pin and 20-pin connectors of the HDCC-02

harness into the vehicle.

Connections to be made
