Side 1/4

Further indications are given in the pages to follow and in the user instructions.

Water supply indicator

Check the appliance fills with water.

Lower spray arm block indicator.

Release the spray arm.

"Water stop" device indicator

"Water stop" device not working.

Switch off the dishwasher and shut off the

water tap.

Rinse aid level indicator

Add rinse aid.

Salt level indicator

Add regeneration salt; only add

regeneration salt immediately before

starting a wash programme.

Programme progress indicator Delayed start buttons

The wash cycle can be programmed to start after 1-24 hours. Then

press the Start button. The dishwasher will start at the set time.

Time and failure display

Indicates in hours the time remaining until the start of the wash cycle.

Switches off when the programme has started. Toward the end of the

programme, during the drying cycle, the display will indicate the time

remaining in minutes.

“F1-F9” Identification of faults for service technician.

Start button

Indicator lamp lit while the dishwasher is operating. Flashes when a fault

occurs.

Switches off at the end of the programme.

On / Off Button

Pre-rinse /

Pre-wash

Washing

Drying

Programme end

Options

Eco-Dry

The indicator lamp switches on during dry

cycles without fans.

Half Load button

This function can be used with any

programme. The indicator lamp switches on:

The wash cycle is activated for the upper

lower rack only.

Programme Symbol

and Temperature

Programme selection and

recommended load type

Place the detergent in the:

small compartment large compartment Consumption 1)

Normal load / (Half load)

Water

(Litres) Energy

(kWh) Time

(Min.)

Pre-wash Crockery to be washed later. - - 5.0 (4.2) 0.02 (0.02) 9 (9)

Glasses 40° C Light soiling, especially glasses and cups. - X 12.0 (10.0) 0.82 (0.78) 60 (59)

Rapid 40° C Lightly soiled crockery with no dried-on food. - X 13.0 (13.0) 0.85 (0.75) 30 (30)

Bio-Eco 50° C Normally soiled crockery, with dried-on food. - X 12.0 (10.0) 1.25 (1.19) 73 (71)

Bio-Normal 50° C 2) Normally or heavily soiled crockery with dried-on food. X X 16.0 (14.5) 1.24 (1.10) 91 (88)

Normal 65° C 3) Normally or heavily soiled crockery with dried-on food. X X 16.0 (13.4) 1.55 (1.37) 86 (80)

Intensive 70° C Heavily soiled pans and saucepans. X X 21.0 (18.0) 1.68 (1.57) 93 (90)

Quick Reference Guide

5019 100 90268

(We reserve the right to make technical modifications)

1) Values may vary in relation to usage, e.g.: different loads, water temperatures -above or below 15° C-, water hardness and

power supply voltage, etc.

2) Programme recommended when using detergents of type B (enzyme-based detergents). Reference programme for energy label.

3) Programme recommended when using detergents of type A (non enzyme-based detergents).

GSF 5476

1. After loading the dishwasher, close the

door properly and open the water

supply tap.

2. Press the On/Off button to switch the

dishwasher on. One of the programme

indicator lamps will switch on.

3. Select the desired programme by

pressing the corresponding button.

The

corresponding indicator lamp lights

up. If required, select options (if supplied).

4. Press the Start button to start the

selected wash programme. The Start

indicator lamp will light up. Once set,

the programmed data cannot be

altered by pressing the programme

selector buttons.

Note: once the Start button has been

pressed, the dishwasher memorises

the last programme selected. This

information remains in the memory

even during interruption of the power

supply.

To change the selected

programme, press the Start button

for about 5 seconds,

until the Start

indicator lamp switches off.

Select a new programme using the

programme selector knob and

press the Start button.

Note:

If the dishwasher is switched off

during a wash programme, when

switched on again it will resume the wash

cycle from where it was interrupted.

Only open the dishwasher door if

strictly necessary during a wash

cycle and exercise maximum

caution. Danger of scalding from

steam.

5. To indicate the end of the programme,

the Start indicator lamp switches off

and the End indicator lamp (if fitted)

lights up (for about 30 min.).

6. Once the Start indicator lamp has

switched off press the On/Off button to

switch the dishwasher off. All the

indicator lamps switch off.

7. Open the door (warning: beware of hot

steam). Unload the lower rack before

the upper one. Close the water tap.

Upper rack

Half Load:

If the upper rack

only is to be filled, remove the

cultery basket from the lower rack and place it

in the upper one.

Rack height adjustment:

(The dishwasher is delivered with the upper

rack in the top position).

The rack height can also be changed

when loaded.

• To lower: pull out the two side

handles and gently lower the rack.

• To raise: pull up the two side handles

until the rack clicks into place.

• The rack must be level on both

sides.

Crockery holders:

• Down:

cups and long-stemmed glasses.

•Up: plates.

“ ”Vario Organizer multi-purpose

support:

• To be used, for example, for long-

handled utensils (arrange knives

with the blade facing downwards),

cups and glasses.

• May be used in three different

positions (see also “Dishwasher

loading instructions” on Page 4).

1. Upon the left-hand side of the rack.

2. Upside-down, towards the centre of

the rack.

3. Upside-down, towards the left side.

Glass holder:

Lower rack

Half Load:

Loading the lower rack only gives

greater washing power, especially for

plates and saucepans.

Plate holders:

• May be lowered to increase

available space (A).

• May be removed to increase

available space (B). To remove:

pull the handle up.

Cutlery basket:

The cutlery basket can be removed to

increase (C) available space.

How to use the dishwasher

Please read the user instructions carefully.

Upper and lower rack
