20-Amp Metered Vertical PDU, 24-Outlet (5-20R)

This 20-amp, vertically mounted power distribution unit is 60 inches long,

features a current meter, and has 24 outlets.

PDUMV24-S20-120V

Overview

The metered PDU LCD display shows the current power draw

in amps. The metered PDU only has one function button,

MUTE, located next to the display. The metered PDU’s alarm

sounds when the current draw reaches 90% of capacity (18

amps). The alarm can be turned off by pressing the MUTE

button. When the current draw excedes 90% the maximum

current rating, the alarm cannot be muted, and the PDU alarms

until the current draw is reduced.

Environmental: Operating Temperature: 32 to 104° F

(0 to 40° C);

Storage Temperature: 32 to 149° F (0 to 65° C);

Operating and Storage Humidity: 0 to 90%,

noncondensing relative

cUL Listed: Yes

RoHS: Yes

Specifications

Circuit Breaker: 20 A

Cord Connector: L5-20P

Cord Length: 15 ft. (4.5 m)

Cord Type: SJT 12/3C

Current Alarm: Yes

Current Rating: 20 amps (16A derated)

Input Voltage: 120 VAC

Metered: Yes, 3-digit LED

Mounting: Vertical

Number of Outlets: 24

Outlet Location: Front

Outlet Max. Current: 20A

Outlet Type: 5-20R

Indicator: Power LED

FREE, live, 24/7 Tech Support is just 20 seconds away.

724-746-5500 | blackbox.com

Safety Instructions

1. The PDU is designed for indoor use only in a controlled environment away from excess moisture, temperature extremes,

conductive contaminants, dust, or direct sunlight.

2. Do not connect the PDU to an ungrounded outlet or extension cords or adapters that eliminate the connection to ground.

3. The power requirement for each piece of equipment connected to the PDU must not exceed the individual outlet’s load rating.

4. The total power requirements for equipment connected to the PDU must not exceed the maximum load rating.

5. Do not drill into or attempt to open any part of the PDU. There are no user-serviceable parts inside.

6. Do not attempt to modify the PDU, including input plugs and power cables.

7. To reduce the risk of fire, connect only to a branch circuit with overcurrent protection in accordance with the National Electric

Code, ANSI/NFPA 70(3KVA).

What’s included

• 24-outlet vertical PDU

• (2) mounting brackets

• (4) mounting screws

• Specification sheet

and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Double Diamond

™

is a trademark of BB Technologies, Inc. Any third-party trademarks appearing in this publication are acknowledged to be the property of their respective owners.

PDUMV24-S20-120V, rev. 1

Produkt Specifikationer

Mærke:	Black Box
Kategori:	stikdase
Model:	PDUMV24-S20-120V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Produktfarve:	Sort
Driftstemperatur (T-T):	0 - 50 °C
Montering:	Lodret
Strømstik:	NEMA L5-20P
Nominel indgangsspænding:	120 V
AC udgange, antal:	24 AC stikkontakt(er)
AC stikkontakt typer:	NEMA 5–20R
Rackkapacitet:	1U
Strøm (maks.):	20 A
PDU-typer:	Målte
