BEFORE YOU BEGIN
Read these instructions completely and
carefully.
• IMPORTANT — Save these
instructions for local inspector’s use.
• IMPORTANT — Observe all
governing codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with Consumer.
• Note to Consumer – Keep these
instructions for future reference.
• Skill level – Installation of this appliance
requires a qualified installer or electrician.
• Proper installation is the responsibility
of the installer.
• Product failure due to improper installation
is not covered under Warranty.
• Product is for indoor use only.
Installation Instructions
30” French Door Built-in Wall Ovens
FOR YOUR SAFETY:
WARNING
Before beginning the installation, switch power off at the service panel and lock
the service disconnecting means to prevent power from being switched on accidentally. When the
service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a
tag, to the service panel.
Be sure the oven is securely installed in a cabinet that is firmly attached to the house structure. Weight
on the oven door could cause the oven to tip and result in injury. Never allow anyone to climb, sit,
stand or hang on the oven door.
Make sure the wall coverings, counters and cabinets around the oven can withstand the heat (up to
200°F [93.3°C]) generated by the oven.
MATERIALS YOU MAY NEED
Junction Box
Wire Nuts
Strain Relief Clamp for 1/2” Conduit
TOOLS YOU MAY NEED
1/8” Drill Bit and Electric or Hand Drill
3/16” hex key 1/8” hex key
Phillips Screwdriver Wire Strippers
Safety Glasses Gloves
1 REMOVE PACKAGING MATERIALS
Failure to remove packaging materials could result in damage to the appliance. Remove all
packing parts from oven, racks and heating elements. Remove protective film and labels on
the outer door and control panel. Also, remove plastic on trims and panel, all tape around the
oven and any shipping screws securing the oven to the base pad. Open oven door and remove
literature pack and oven racks. Remove the bottom trim from the top of the oven. It will be
installed at the end of the installation process. The trim is wrapped separately and taped to the top
of the unit.
2 PREPARE THE OPENING
NOTE: If the cabinet does not have a solid
bottom, two braces or runners must be
installed to support the weight of the oven.
For French Door ovens, the runners and
braces must support 220 lbs (98.8 kg).
NOTE: If marks, blemishes or the cutout
opening are visible above the installed oven,
it may be necessary to add wood shims under
the runners and front trim until the marks or
opening are covered.
NOTE: If the cabinet does not have a front
frame and the sides are less than ¾” (1.9 cm)
thick, shim both sides equally to establish the
cutout width.
ATTENTION INSTALLER: All electric wall ovens must be hard-wired (direct-wired)
into an approved junction box. A plug and receptacle is NOT permitted on these products.
DESIGN INFORMATION
FRENCH DOOR SINGLE OVEN INSTALLATIONS
The French Door single oven may be installed in a cabinet alone or above a warming drawer and/
or below a Microwave/Advantium. However, the French Door single oven is not allowed under a
countertop or cooktop, and it is not allowed to be installed flush to the front surface of the cabinet.
IMPORTANT: Always refer to individual installation instructions packed with each product for
specific requirements.
Questions? Call us at 1.800.432.2737 or visit GEAppliances.com.
In Canada, call 1.800.561.3344 or visit GEAppliances.ca.
Suitable
Bracing
to Support
Runners
2" x 4" (5 cm x 10 cm)
or Equivalent Runners Level
with Bottom of Cutout
and Flush with Sides of Cutout
C
L
B
A
Cutout Location from
Floor
321»
2” (82.6 cm)
161»
4” (41.3 cm) Min.
Cutout –
observe all
dimensions and
requirements.
Cutout –
observe all
dimensions and
requirements.
30” (76.2 cm) Min. if both ovens are French Door
14” (35.6 cm) Min. if only one oven is French Door
Center Line Center Line
30” Models
581»
2” (148.6 cm) if both ovens are French Door
421»
2” (108 cm) if only one oven is French Door
These ovens are
not approved
for stackable
installations.
H
D
E
JJ
Junction
Box
Location
(junction
box may
be located
in adjacent
cabinet)
22” (55.9
cm) Min.
to Bottom
of Junction
Box
Cutout Depth
231»2”
(59.7 cm) Min.
Opening
Between
Inside Walls
Must be at
Least 281»2”
(72.4 cm)
Wide
Side-by-Side Installations
Install two ovens in separate cutouts.
2 A
CUTOUT FOR SINGLE OVENS IN WALL CABINET
NOTE: If the cabinet does not have a front frame and the sides are less than ¾” (1.9 cm) thick,
shim both sides equally to establish the cutout width.
K
E E
L
Dimension Dimension Description 30” Single Oven
ACabinet width 30” (76.2 cm)
BCutout width 281»2” (72.4 cm) min.
285»8” (72.7 cm) max.
CCutout height 271»4” (69.2 cm) min.
275»16” (69.4 cm) max.
DClearance from cutout - side edges* 11»16
” (1.75 cm)
EDoor swing depth - Allow additional clearances for
installation and oven usage
161»4” (41.3 cm) min.
FClearance from cutout - top* 1” (2.5 cm) min
(11»
4” (3.2 cm)
GClearance from cutout - bottom* 11»4
” (3.2 cm)
HJunction box location 91
»2” (24.1 cm) max.
right side only
JDoor swing width - Allow additional clearances for
installation and oven usage
14” (35.6 cm) min.
KCountertop or cabinet door protrusion (measure if exist) Measure “K”
LGap between edge of countertop or cabinet door
to cabinet opening
If K = 0, L = 0, Otherwise
L = K + 1” (2.54 cm) min.
F
GC
* Refers to minimum clearance required for wall oven installation and does not reflect actual product dimensions.
2 B
CUTOUT FOR DOUBLE OVENS IN WALL CABINET
NOTE: If the cabinet does not have a front frame and the sides are less than ¾” (1.9 cm) thick,
shim both sides equally to establish the cutout width.
Dim. Description
30” Double Oven with
Pedestal
30” Double Oven without
Pedestal
ACabinet width 30” (76.2 cm) 30” (76.2 cm)
BCutout width 281»2” (72.4 cm) min.
285»
8” (72.7 cm) max.
281»2” (72.4 cm) min.
285»
8” (72.7 cm) max.
CCutout height 5113
»16
” (131.6 cm) min.
5115
»
16 ” (131.9 cm) max.
50 ¼” (127.64cm)
DClearance from cutout - side edges* 11
»16” (1.75 cm) 11
»16” (1.75 cm)
ELower door clearance to adjacent corners,
drawers, walls, etc., When door is open
23” (53.3 cm) min. 23” (53.3 cm) min.
FClearance from cutout - top* 1” (2.5 cm) min.(1
1»4” (3.2 cm) 1” (2.5 cm) min.(11»4” (3.2 cm)
GClearance from cutout - bottom* 1
1»4” (3.2 cm) 1
1»4” (3.2 cm)
HJunction box location 91»2” (24.1 cm) max.right side only 9
1»2” (24.1 cm) max.right side only
KCutout location from floor 12” (30.5 cm) min. 12” (30.5 cm) min.
LFrench (upper) door swing depth - Allow additional
clearances for installation and oven usage
161»4” (41.3 cm) min. 161»4” (41.3 cm) min.
MCountertop or cabinet door protrusion
(measure if exist)
Measure “M” Measure “M”
NGap between edge of countertop
or cabinet door to cabinet opening
If M = 0, N = 0, Otherwise
N = M + 1” (2.54 cm) min.
If M = 0, N = 0, Otherwise
N = M + 1” (2.54 cm) min.
PJunction Box location 5-1/4” (13.34 cm) max. 5-1/4” (13.34 cm) max.
RJunction Box location 2-1/2” (6.35 cm) max. 2-1/2” (6.35 cm) max.
SDoor swing width - Allow additional clearances for
installation and oven usage
14” (35.6 cm) min. 14” (35.6 cm) min.
Continue to Section 3.
H
P
R
B
C
K
F
G
D
A
E
Junction Box
Location (junction
box may be
located in
adjacent cabinet)
Cutout Depth
23-1/2”
(59.7 cm) Min.
* Refers to minimum clearance required for wall oven installation and does not reflect actual product dimensions.
M
L L
N
S S
NOTE: Allow
1/4” (0.64 cm)
clearances from
side edges of
oven door.
