Gage Pressure Transducer
Installation and Operation
#NSA-A/GP 10Harness, NSA-A/GP 2Harness, NSA-GP(0-100G)- -P, NSA-GP(0-15G)- -P, NSA-GP(0-200G)- -P 20 20 20
NSA-GP(0-300G)- -P, NSA-GP(0-500S)- -P, NSA-GP(0-50G)- - - 11/14/2019 20 20 20 P
Specications subject to change without notice.
Catalog No. - - - Page of 11 808 759 01 1 4
The Gage Pressure Transducer (Air, Gases, & Liquid) Series is designed to provide
excellent accuracy and reliability in commercial, industrial, and process control
applications where performance is critical. The bulk micro-machined transducer features
a stainless steel diaphragm with welded construction that contains no O-rings, which
makes them compatible with any gas or liquid compatible with 304L stainless steel.
Some of the compatible gases and liquids include refrigerants, glycol, motor oil, diesel,
hydraulic uid, brake uid, water, waste water, Hydrogen, Nitrogen and air. The GP
Series transducers can also be ordered in an optional NEMA 4 rated, weatherproof metal enclosure or a NIST Calibration
Certicate. Accessory items such as pressure snubbers and pigtail syphons are available to protect the transducers from
line pressure surges (pulsations) or extreme operating temperatures. This series features Packard connectors and
separate harnesses allowing for installation flexibility.
Applications: Refrigeration, Fuel Cells, Pumps, Hydraulics, Compressors, Robotics, Pneumatics, Agriculture, Spraying
Systems, Process Control, Flow, Hydrogen Storage, Steam Lines, Boilers, Chillers
NSA-A/GP 10Harness NSA-A/GP 2Harness NSA-GP(0-100G)- -P NSA-GP(0-15G)- -P 20 20
NSA-GP(0-200G)- -P NSA-GP(0-300G)- -P NSA-GP(0-500S)- -P NSA-GP(0-50G)- -P 20 20 20 20
Specications
Supply Voltage:
250 Ohm Load 500 Ohm Load: +13 to 30 VDC | : 18 to 30 VDC
Reverse Polarity Protection:
+/- 16 V over 5 minutes
Maximum Load Resistance:
800 Ohms @ 24 VDC | : (Supply VDC 8 VDC) / 0.020A Formula –
Supply Current:
25 mA minimum
Output Signal:
4 to 20 mA (2-Wire, Loop Powered)
Response Tim e:
< 1 ms
Pressure Ranges:
NSA-GP(0-100G)- -P20 : 0-100 psig (689 kPa) | NSA-GP(0-15G)- -P20 : 0-15 psig (103 kPa)
NSA-GP(0-200G)- -P20 : 0-200 psig (1379 kPa) | NSA-GP(0-300G)-20-P: 0-300 psig (2069 kPa)
NSA-GP(0-500S)- -P20 : 0-500 psis (3447 kPa) | NSA-GP(0-50G)- -P20 : 0-50 psig (345 kPa)
Accuracy
1
@ 22ºC (71.6ºF):
15 to 60 psig 75 to 300 psig 500 psis: < +/- 1.0% FS | : < +/- 0.5% FS |
3
: < +/- 0.5% FS
Thermal Error
2
(-40º to 105ºC):
15 to 60 psig 75 to 300 psig 500 psis: < +/- 1.0 FS | : < +/- 0.5% FS |
3
: < +/- 0.5% FS
Stability (250 Hours @ 225ºF (125ºC)):
+/- 0.03% FS @ 0 PSIG; +/- 0.12% FS @ 1000 PSIG
Proof Pressure:
15 to 300 psig 500 psis: 3x FS | : 3x FS
Burst Pressure:
15 to 300 psig 500 psis: 3x FS | : 3x FS
Thermal Shock:
300 Cycles (105ºC to -40ºC, 0.5 hr soaks @ Temp. (2s Transfer))
Vibration (100 to 2000Hz, 20g
Sinusoidal, 3 Axes):
144 Hours
Operating Temperature Range:
-40 to 221ºF (-40 to 105ºC)
Storage Temperature Range:
-40 to 176ºF (-40 to 80ºC)
Operating Humidity Range:
0 to 95% RH, non-condensing
Media Types:
Any gas or liquid compatible with 304L Stainless Steel
Transducer Housing Material:
Stainless Steel
Process Fitting Material | Thread Size:
304L Stainless Steel | 1/4”-18 NPT
Recommend Torque Specication:
150 lbs-in (16.95 Nm)
Wiring Connections:
Packard Connector (Cables ordered separately)
Approvals:
EMC Compliance: 10 V/m (EN61000-4-3), CE, RoHS2, WEEE, ISO 9001
Product Dimensions (Length x
Diameter):
2.60” (66.6 mm) x 0.87” (22.23 mm)
Product Weights:
NSA-A/GP Series Transducer: 0.30 lbs. (0.13 kg)
NSA-A/GP 2Harness NSA-A/GP 10Harness: 0.09 lbs. (0.04 kg) | : 0.32 lbs. (0.14 kg)
Gage Pressure Transducer
Installation and Operation
#NSA-A/GP 10Harness, NSA-A/GP 2Harness, NSA-GP(0-100G)- -P, NSA-GP(0-15G)- -P, NSA-GP(0-200G)- -P 20 20 20
NSA-GP(0-300G)- -P, NSA-GP(0-500S)- -P, NSA-GP(0-50G)- - - 11/14/2019 20 20 20 P
Specications subject to change without notice.
Catalog No. - - - Page of 11 808 759 01 2 4
1
Accuracy includes Hysteresis, Repeatability, and Non-linearity (BFSL)
2
Additional error over temperature range
3
Sealed Gage pressure transducers are not vented to atmosphere, but are calibrated to have 4 mA at 14.5 PSIG to resemble a standard
gauge pressure transducer output
Front View
Right View
Figure 1
Installation
Figure 2
Location
Install the sensor in a location where it will not be exposed to extreme temperatures, vibration or shock. Install the
pressure sensor above or on the side of pipes, in a location where liquid will not drip on the unit. Condensation can
potentially build up and run down the harness, position the unit and harness so water does not pool on the back of the
sensor. Do not install the sensor at the end of a long run of pipe.
