Side 1/2

FEATURES

Assembly Drawing

Power button

slot covers

Right side panel

Reset button

2.5

HDD/SSD drive bays

USB 3.0 / USB 2.0 / HD audio ports

3.5" HDD trays (compatible for 2.5" HDD/SSD)

Front panel

2 x 120mm fans for front panel (optional)

5.25

" ODD cover

Air filter for bottom panel

Installing the Front I/O Connectors

Excellent Looks with Superior Airflow

MX331 Mesh-X's front panel combines with excellent appearance and powerful airﬂow.

Make sure your critical hardware can be maximum cooled!

Massive Expandability

MX331 Mesh-X allows you to ﬁt a full-sized ATX motherboard, 350mm length graphic card,

one 5.25

devices, two 2.5

SSDs, and two 3.5

HDDs, which satisfy your expandability and

storage needs.

Strong Cooling

You can install up to six fans and a 240mm water cooling radiator to protect your investment

from the threat of overheating.

Minimalist Beauty

The case's PSU and 3.5

bay cover provide a clean view of your case and keep the airﬂow

strong.

Left side panel

120mm fan for rear panel (pre-installed)

Air filter for top panel

2 x 120mm fans for top panel (optional)

200 / 120 / 80mm fan for Side panel (optional)

• Mesh front panel combines with excellent appearance and sufficient airflow

• Support for up to six fans and a 240mm radiator

• Support for up to 350mm long graphics cards

• Support for one 5.25” device, two 3.5" HDDs, and two 2.5" SSDs,

or four 2.5" SSDs

ENGLISH

• Mesh-Frontpanel kombiniert mit exzellentem Erscheinungsbild und

ausreichendem Luftstrom

• Unterstützung für bis zu 6 Lüfter und einen 240-mm-Kühler

• Unterstützung für bis zu 350 mm lange Grafikkarten

• Unterstützung für ein 5,25-Zoll-Gerät, zwei 3,5-Zoll-Festplatten und

zwei 2,5-Zoll-SSDs oder vier 2,5-Zoll-SSDs

DEUTSCH

• El panel frontal de malla, realiza una excelente combinación entre

apariencia y su sistema de flujo de aire

• Admite hasta 6 ventiladores y un radiador de 240 mm

• Soporte para tarjetas gráficas de hasta 350 mm de largo

• Soporte para un dispositivo de 5.25”, dos HDD de 3.5" y dos SSD de 2.5 ",

o cuatro SSD de 2.5"

ESPAÑOL

• Siatkowy panel przedni łączy się z doskonałym wyglądem i

wystarczającym przepływem powietrza

• Obsługa do 6 wentylatorów i radiatora 240mm

• Obsługa dla kart graficznych o długości do 350mm

• Obsługa jednego napędu 5.25cala, dwa dyski twarde 3.5 cala

i dwa dyski ssd 2.5 cala lub 4 dyski ssd2.5 cala

POLISH

• Painel frontal Mesh combina excelente design com alto fluxo de ar

• Suporta até 6 ventoinhas e radiador de 240mm

• Suporte de placa gráficas de ate 350mm de comprimento

• Suporte para 1 dispositivo de 5.25, 2 HDD 3.5" e 2 SSDs de

2.5" ou 4 SSDs de 2.5"

PORTUGUÊS

РУССКИЙ

• Сетчатая передняя панель отлично сочетается с внешним видом

корпуса и мощным потоком воздуха

• Поддержка до 6 вентиляторов и 240-мм радиатора

• Поддержка видеокарт длиной до 350 мм

• Поддержка одного 5.25-дюймового устройства, двух 3.5-дюймовых

жестких дисков и двух 2.5-дюймовых SSD или четырех 2.5-дюймовых

SSD

• Le panneau avant en maille se combine avec une excellente apparence

et un flux d'air suffisant

• Prise en charge jusqu'à 6 ventilateurs et un radiateur de 240 mm

• Prise en charge de cartes graphiques jusqu'à 350 mm de long

• Prise en charge d'un appareil 5,25 ”, de deux disques durs 3,5" et de

deux disques SSD 2,5 ", ou de quatre disques SSD 2,5"

FRANÇAIS

• 铁网面板结合美观设计与畅通气流

• 最高支援6个风扇与240mm水冷散热器

• 支援长达350mm的显示卡

• 支援1个5.25" 装置、2个 3.5" HDD硬盘、2个 2.5" SSD硬盘

(或4个2.5" SSD硬盘)

中文

• フロントパネルはメッシュ設計で、優れた外観と十分な通気性を備えています

• 6 240個のファンとｍｍの水冷ラジエーターを装着でき、優れた放熱効果を確

保します

• 最大グラフィックカードに対応できます350mm

• 1 2 2つのデバイスと5.25” つの3.5"のHDD、つの2.5" SSDもしくは 4つの

2.5" SSDを搭載可能です

日本語

• .우수한 외관과 충분한 공기 흐름이 결합 된 메쉬 전면 패널

• 6 240mm .최대 개의 팬과 라디에이터를 지원합니다

• 350mm .최대 길이의 그래픽 카드를 지원합니다

• 5.25" 1 3.5" HDD 2 2.5" SSD 2 2.5" SSD장치 개와 개 및 개 또는

4 개를 지원합니다

한국어

GLOBAL WARRANT Y POLICY

WARRANTY PERIODS OF COUGAR GAMING DEVICES

Product : COUGAR MX331 Mesh-X

Warranty : 1 Year

●

This warranty gives you specific legal rights. You may also have other rights granted under local law. These rights may vary.

●

Only for electrical components.

Specifications might vary depending on the country or region of sale.

Case Form Factor

Dimension

Motherboard Type

I/O Panel

Case Drive Bays

Expansion Slots

Model Name

Cooling Fan Support

Water Cooling Radiator Support

Maximum Number of Fans

Max. Graphics Card Length

Max. CPU Cooler Height

Max. PSU Length

350 (mm) / 13.8 (in)

155mm / 6.1inch

200mm / 7.9inch

MX331 Mesh-X

Model No.

CGR-5NC2B-MESH-X

Mid Tower

204 (W) x 481 (H) x 443 (D) mm / 8 (W) x 19 (H) x 17 (D) inch

Mini ITX / Micro ATX / ATX

USB 3.0 x 1 , USB 2.0 x 1 , Mic x 1, Audio x 1 , Reset Button

5.25" : 1

3.5" : 2

2.5" : 2+2 (converted from 3.5" drive bays)

Front : 120mm x 2

Rear : 120mm

Top : 120mm

Front

: 240mm / 120mm

6 Max.

Top : 120mm x 2

Rear : 120mm x 1 (pre-installed)

Side : 200 / 120 / 80mm x 1

MX331 Mesh-X sports an attractive and compact design with a massive mesh front panel

for better airﬂow performance. With an elegant look, a highly functional design and a

durable construction, this case delivers great value.

ACCESSORY KIT

M X 3 3 1

M E S H

год и месяц изготовления продукции указаны в серийном номере продукта.

(существует 2 способа определения даты изготовления, оба способа описаны ниже)

После S/N: первые две цифры означают год, вторые две – месяц изготовления.

Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702

После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,

и означают год,

последующие две цифры – месяц изготовления.

Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02

●

Например,

AG = 17 = 2017 год

ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ

A B C D E F G H I J

123456 8907

БЪЛГАРИЯ

• Подробни инструкции за употреба изтеглете от: https://cougargaming.com/bg

България QR код

Motherboard screws, 5.25" ODD screws,

and 2.5" SSD screws

Stand-off

3.5" HDD screws

Cable ties

Power supply screws X 7

X 5

X 14

X 2

X 4

X 3

X 6

X 1

Front fan screws

3.5" HDD tray and cage screws

Slot cover

USB 3.0 HD AUDIO POWER SW

HD AUDIO

POWER SW

RESET SW

H.D.D LEDPOWER LED

POWER LED +

POWER LED

USB3.0

USB 2.0

USB

H.D.D LED

120

(Top)

(Rear)

(Side)

120 80200

120

(Front)

Installing water cooling radiators & cooling fans Installing PCI-E cards

Support for graphics card up to 350mm-long

Removing side panels Installing the 5.25" device

Installing the 2.5" SSDs

Installing the 3.5" HDDs

(Top)

(Rear)

120

120240

(Front)

RIGHT

LEFT

RIGHT

LEFT

RIGHT

Compucase Enterprise Co.,Ltd.

No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C

Tel:+886-6-356-0606

Service E-Mail:service@cougargaming.com

COUGAR USA Technical Service

Tel: (833) 256-3778

Mail: rma@compucaseusa.com

https://cougargaming.com/support/contact/upload/

For more information, please visit

Compucase Enterprise Co.,Ltd.

www .coug argam ing.c om

Made in China
