Side 1/2

MG130 IS AN ELEGANT AND COMPACT GAMING CASE WITH A METAL-LIKE BRUSHED FRONT

PANEL. IT SPORTS AN ATTRACTIVE AND COMPACT DESIGN AND SUPPORTS SIX COOLING

FANS AND THREE RADIATORS. WITH AN ELEGANT LOOK, A HIGHLY FUNCTIONAL DESIGN

AND A DURABLE CONSTRUCTION, THIS CASE DELIVERS GREAT VALUE YOU WANT.

G R E A T L O O K S

The elegant metal-like brushed front panel design gives it a modern, distinctive and classic

design for gamers and professionals!

G R E A T S U P P O R T F O R C O M P O N E N T S

You won't believe how powerful a gaming beast you can build inside MG130. Its advanced

support for graphics cards (up to two 330 mm-long graphics cards) will allow you to enjoy the

latest games with smooth framerates.

T O P - N O T C H C O O L I N G

MG130's compact layout allows you to install six fans and three water cooling radiators, with the

front one up to 280mm. This immense cooling potential will enable you to choose freely the

components you want in your build.

I N C R E D I B L E S T O R A G E

Up to two 3.5" HDDs and two 2.5" SSDs or four 2.5" SSDs will provide you with all the storage you

need to install games and store all kinds of media.

M I N I M A L I S T B E A U T Y

The case's 3.5" bay and PSU cover provides a clean view of your case and keep the airflow smoothly.

FEATURES

Assembly Drawing

Specifications might vary depending on the country or region of sale.

Power button / Reset button

Removable front panel

USB3.0 x 1 ,USB2.0 x 1 , Mic x 1, Audio x 1

Right side cover

Thumb screws

Left side cover

Slot covers

2.5" HDD/SSD trays

3.5”HDD trays

(compatible for 2.5”HDD/SSD)

Air filter on bottom cover

Air filter at front panel

2 x 140 / 3 x 120mm fans

for front panel (optional)

120mm fan for rear panel

(pre-installed)

Air filter on top cover

2 x 140 / 2 x 120mm fans

for top panel (optional)

• Elegant Brushed Front Panel

• Support for Micro ATX / Mini ITX Motherboards

• Up to Two 330 mm Graphics Cards

• Up to Six Fans (1 Standard Fan Preinstalled)

• Up to Three Water Cooling Radiators (Up to 280mm)

• Support for Two 3.5" HDDs and Two 2.5" SSDs or Four 2.5" SSDs.

ENGLISH

• Elegante Frontblende

• Unterstützt Micro-ATX/Mini-ITX-Motherboards

• Bis zu zwei 330-mm-Grafikkarten

• Bis zu sechs Lüfter (1 Standardlüfter vorinstalliert)

• Bis zu drei Wasserkühlungsradiatoren (bis zu 280 mm)

• Unterstützt zwei 3,5 Zoll-Festplatten und zwei 2,5 Zoll-SSDs oder vier

2,5 Zoll-SSDs

DEUTSCH

• Elegante Panel Frontal de Cepillado

• Soporte para Motherboards Micro ATX / Mini ITX

• Hasta dos Tarjetas Gráficas de 330 mm

• Hasta seis Ventiladores (1 ventilador estándar pre-instalado)

• Hasta tres Radiadores de Water Cooling (de hasta 280mm)

• Soporte para dos HDDs de 3.5” y dos SSDs de 2.5” o cuatro SDDs de 2.5”

ESPAÑOL

• Elegancki panel przedni szczotkowanej

• Obsługa płyt głównych Micro ATX / Mini ITX

• Maksymalnie dwie karty graficzne 330 mm

• Maksymalnie 6 wentylatorów (1 wentylator standardowy fabrycznie)

• Maksymalnie 3 radiatory chłodzenia wodnego (do 280 mm)

• Obsługa dwóch dysków twardych 3,5" i dwóch SSD 2,5" albo cztery SSD 2,5".

POLISH

• Elegáns, szálcsiszolt panel

• Támogatás Micro ATX / Mini ITX alaplapokhoz

• Max. két 330 mm-es grafikus kártya

• Max. hat ventilátor (1 szabványos ventilátor gyárilag telepítve van)

• Max. három vízhűtő radiátor (fent 360 mm-ig)

• Támogatás két 3,5"-os HDD-hez és két 2,5"-os SSD-hez vagy négy 2,5"-os

SSD-hez

HUNGARIAN

• Painel frontal elegante em escovado

• Suporte para Placas Mães Micro ATX / Mini ITX

• Até duas Placas de Vídeo de 330 mm

• Até seis Ventoinhas (1 ventoinha padrão pré-instalada)

• Até três Radiadores de Water Cooling (Em cima até 280mm)

• Suporte para dois HDDs de 3.5” e dois SSDs de 2.5” ou quatro SDDs de 2.5”

PORTUGUÊS

РУССКИЙ

• Элегантная передняя панель

• Поддержка материнских плат формата Micro ATX / Mini ITX

• До двух 330-мм графических карт

• До шести вентиляторов (предустановлен 1 стандартный вентилятор)

• До трех водоохлаждающих радиаторов (до 280 мм)

• Поддержка двух 3.5-дюймовых жестких дисков и двух 2.5-дюймовых SSD

накопителей или четыре 2.5-дюймовых SSD накопителей.

• Élégant panneau avant en brossé

• Prise en charge de cartes mères Micro ATX / Mini ITX

• Jusqu'à deux cartes graphiques 330 mm

• Jusqu'à six ventilateurs (1 ventilateur standard préinstallé)

• Jusqu'à trois radiateurs de refroidissement par eau (Haut jusqu'à 280 mm)

• Prise en charge de deux disques durs 3,5" et deux SSD 2,5" ou quatre SSD 2,5".

FRANÇAIS

• Elegante pannello anteriore

• Supporto per schede madri Micro ATX / Mini ITX

• Fino a due schede grafiche da 330 mm

• Fino a sei ventole (1 ventola standard preinstallata)

• Fino a tre radiatori di raffreddamento ad acqua (280 mm)

• Supporto per due HDD da 3,5" e due SSD da 2,5" o quattro SSD da 2,5".

ITALIANO

• 高质感发丝纹面板

• Micro ATX / Mini ITX 支持主板

• 2 330 mm 最高可安装组显卡

• 6 ( 1 )最高支持个风扇背板预装个风扇

• 3 ( 280mm )最高可安装个水冷散热器支持最大长度水冷排

• 2 3.5" HDD ( 2 2.5"SSD ) 4 2.5" SSD支持个硬盘可转换为个硬盘与个硬盘

中文

• エレガントなヘアラインフロントパネル。

• Micro-ATX Mini-ITXとマザーボードに対応しています。

• 2 330 mm最大つのグラフィックカードに対応できます。

• 6 1最大個のファンを装着できます。（個のファンをリアカバーにセットしている）

• 3 280mmつの水冷ラジエーターを装着可能です。（の水冷ラジエーターを装着可能）

• 2 3.5 HDD( 2 2.5" SSDs) 4 2.5" SSDつのインチの或いはつのとつのを装着できます。

日本語

• 우아한 프론트 판넬

• Micro ATX / Mini ITX 마더보드 지원

• 최대 2개의 330 mm 그래픽 카드 장착 가능

• 최대 6개의 팬 설치 가능 (1개의 기본 팬 내장)

• 최대 3개의 수냉식 라디에이터(280mm)

• 3.5" HDD 2개와 2.5" SSD 2개 또는 2.5" SSD 4개 지원

한국어

год и месяц изготовления продукции указаны в серийном номере продукта.

(существует 2 способа определения даты изготовления, оба способа описаны ниже)

После S/N: первые две цифры означают год, вторые две – месяц изготовления.

Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702

После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,

и означают год,

последующие две цифры – месяц изготовления.

Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02

●

Например,

AG = 17 = 2017 год

ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ

A B C D E F G H I J

123456 8907

ACCESSORY KIT

MG130

GLOBAL WARRANT Y POLICY

WARRANTY PERIODS OF COUGAR GAMING DEVICES

Product : COUGAR MG130

Warranty : 1 Year

●

This warranty gives you specific legal rights. You may also have other rights granted under local law. These rights may vary.

●

Only for electrical components.

X 5Power supply screws

X 25Motherboard/SSD screws

X 4Stand-off

X 5Cable ties

HD AUDIO

RESET SW

USB3.0

USB

POWER SW

H.D.D LED +

H.D.D LEDUSB 3.0 HD AUDIOUSB 2.0

Installing the Front I/O Connectors

RESET SWPOWER SW

ELEG ANT AND COMPACT MINI T OWER CA SE

WITH A METAL-LIKE BRUSHED FRONT PANEL

Max. Graphics Card Length

Max. CPU Cooler Height

Max. PSU Length

PSU

Case Form Factor

Dimension

Motherboard Type

I/O Panel

Case Drive Bays

Expansion Slots

Model No.

Model Name

Cooling Fan Support

Water Cooling Radiator Support

Maximum Number of Fans

Cable Management

Rear : 120mm

330mm / 12.99inch

175mm / 6.89inch

160mm / 6.3inch

Standard ATX PS2

MG 130

CGR-5TM1B

Mini Tower

210 (W) x 415 (H) x 400 (D) mm / 8.27 (W) x 16.34 (H) x 15.75 (D) inch

Mini ITX / Micro ATX

USB3.0 x 1 , USB2.0 x 1 , Mic x 1 , Audio x 1 , Reset Button

3.5" : 2

Yes

2.5" : 2+2 (converted from 3.5" drive bays) / (2 SSD trays included)

Top : 120mm x 2 / 140mm x 2

Front : 120mm x 3 / 140mm x 2

Top : 240mm / 140mm / 120mm

Front : 280mm / 240mm / 140mm / 120mm

6 Max.

Rear : 120mm x 1 (pre-installed)

Removing the side panel Removing the front panel Installing an internal 2.5" HDD/SSD Installing an internal 3.5" HDD

Install with trays

(There are two SSD trays in this case. Please select two locations you prefer to install.)

Installing water cooling radiators & cooling fans

120140240

280

120

140

120

140

240

120

140

(Top)

(Front)

(Rear)

Up to three 330mm graphics cards

Removing the dust filters Installing PCI-E cards

For more information, please visit

Compucase Enterprise Co.,Ltd.

ww w .co u gar g a min g .co m

Made in China

Compucase Enterprise Co.,Ltd.

No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C

Tel:+886-6-356-0606

Service E-Mail:service@cougargaming.com

COUGAR USA Technical Service

Tel: (833) 256-3778

Mail: rma@compucaseusa.com

https://cougargaming.com/support/contact/upload/

Air filter on top cover

Air filter at front panel

Air filter on bottom cover

Note:

Please remove the USB bezel before you

install the toppest fan at the front panel.

Connectors

Produkt Specifikationer

Mærke:	Cougar
Kategori:	Computertaske
Model:	MG130
Type:	PC
Bredde:	210 mm
Dybde:	400 mm
Højde:	415 mm
Vægt:	4570 g
Produktfarve:	Sort
Pakkevægt:	5670 g
Pakkedybde:	440 mm
Pakkebredde:	258 mm
Pakkehøjde:	481 mm
Formfaktor:	Mini Tower
Antal USB 2.0-porte:	1
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	1
Knap til nulstilling:	Ja
Lydindgang:	Ja
Lydudgang:	Ja
Strømforsyning inkluderet:	Ingen
Tænd/sluk-knap:	Ja
Forbedret kabelstyring:	Ja
Antal understøttede HHD'er:	2
Understøttet motherboard, formfaktorer:	Micro ATX, Mini-ITX
Siderude:	Ingen
Antal udvidelsesporte:	4
Maksimal højde på CPU-køler:	175 mm
Maksimal længde på grafikkort:	330 mm
Maksimal PSU længde:	160 mm
Understøttede HDD-størrelser:	2.5, 3.5 "
Antal understøttede frontventilatorer (maks.):	3
Understøttede diametre for frontventilatorer:	120,140 mm
Bagerste ventilatorer installeret:	1x 120 mm
Antal understøttede bagerste ventilatorer (maks.):	1
Understøttede diametre for bagerste ventilatorer:	120 mm
Antal understøttede øverste ventilatorer (maks.):	2
Understøttede diametre for øverste ventilatorer:	120,140 mm
HDD/SDD kombineret bur:	Ja
Kapacitet for flydende nedkøling:	Ja
