Side 1/2
FEATURES
Assembly Drawing
Power button / RGB control button
A
G
2.5" HDD/SSD drive bay
USB 3.0 / USB 2.0 / HD audio ports
B
Air filter for top panel
Front panel
I
Air filter for bottom panel
Tempered glass side panel
3 x 120mm RGB fans for front panel (pre-installed)
J
E
Right side panel
K
2 x 120mm fans for top panel (optional)
Specifications might vary depending on the country or region of sale.
*Please choose either of front or top to install a 240mm radiator.
Installing the Front I/O Connectors
Excellent Looks with Superior Airflow
MX410 Mesh-G RGB
Let it breathe through the front panel!
Enjoy the Dazzling RGB Show
The integrated lighting button with built-in LED controller allows MX410 Mesh-G RGB to display


Elegant Design with Massive Tempered Glass Left Panel
With the full-length PSU cover hides cables and a massive tempered glass left panel

Wider but More Compact and Powerful
MX410 Mesh-G RGB s 210mm width allows much larger interior space with better cooling


  

Abundant for Multiple USB Devices


Strong Cooling Performance
MX410 Mesh-G RGB


F
3.5
"
HDD cage
L
120mm RGB fan for rear panel (pre-installed)
• Mesh front panel combines with excellent appearance and sufficient airflow
• Elegant design with massive tempered glass left panel
• Integrated RGB system with 5V RGB motherboard synchronization
• Support for up to six fans and a 240mm radiator
• Support for up to 300mm long graphics cards
• Support for two 3.5" HDDs and three 2.5" SSDs
ENGLISH
• Mesh-Frontpanel kombiniert mit exzellentem Erscheinungsbild und
ausreichendem Luftstrom
• Elegantes Design mit linker Abdeckung aus massivem gehärtetem Glas
• Integriertes RGB-System mit 5-V-RGB-Motherboard-Synchronisierung
• Unterstützt bis zu sechs Lüfter und einen 240-mm-Kühlkörper
• Unterstützt Grafikkarten mit einer Länge von bis zu 300 mm
• Unterstützt zwei 3,5 Zoll-Festplatten und drei 2,5 Zoll-SSDs
DEUTSCH
• El panel frontal de malla, realiza una excelente combinación entre apariencia
y su sistema de flujo de aire
• Diseño elegante con panel izquierdo de vidrio templado
• Sistema RGB integrado con sincronización de placa base con 5V RGB
• Soporta hasta seis ventiladores y un radiador de 240mm
• Soporte para tarjetas gráficas de hasta 300mm de largo
• Soporte para dos HDD de 3.5" y tres SSD de 2.5"a
ESPAÑOL
• Siatkowy panel przedni łączy się z doskonałym wyglądem i
wystarczającym przepływem powietrza
• Elegancki wygląd dzięki lewej pokrywie z litego szkła hartowanego
• Zintegrowany system RGB zsynchronizowany z płytą główną przez
złącze RGB 5V
• Obsługa maksymalnie 6 wentylatorów i radiatora do 240 mm
• Możliwość montażu kart graficznych o długości do 300 mm
• Obsługa dwóch dysków twardych 3,5" i trzy SSD 2,5"
POLISH
• Painel frontal Mesh combina excelente design com alto fluxo de ar
• Design elegante com painel lateral esquerdo em vidro temperado
• Sistema RGB integrado com sincronização de placa mãe de 5V RGB
• Suporta até 6 ventoinhas e radiador de 240mm
• Suporta placas gráficas de até 300mm
• Suporta até 2 HDDs de 3.5" e 3 SSDs de 2.5"
PORTUGUÊS
РУССКИЙ
• Сетчатая передняя панель отлично сочетается с внешним
видом корпуса и мощным потоком воздуха
• Элегантный дизайн с массивной левой панелью из закаленного стекла
• Интегрированная система RGB подсветки с 5V синхронизацией
материнской платы
• Поддержка до шести вентиляторов и 240-мм радиатора
• Поддержка видеокарт длиной до 300 мм
• Поддержка двух 3.5-дюймовых жестких дисков и трех 2.5-дюймовых SSD
• Le panneau avant en maille se combine avec une excellente apparence et
un flux d'air suffisant
• Conception élégante avec un capot gauche en verre trempé massif
• Système RGB intégré avec synchronisation de la carte mère RGB 5V
• Prend en charge jusqu'à 6 ventilateurs et un radiateur de 240 mm
• Prend en charge les cartes graphiques jusqu'à 300 mm de longueur
• Prise en charge de deux disques durs 3,5" et trois SSD 2,5"
FRANÇAIS
• 铁网面板结合美观设计与畅通气流
• 高雅设计与全透钢化玻璃左侧盖
• RGB 5V整合系统支援 主机板灯效同步控制功能
• 240mm最高可支援 个风扇与6的水冷散热器
• 300mm支援长达 的显示卡
• 2 3.5" HDD 3 2.5" SSD支持 个 硬盘与 个 硬盘
中 文
• 󴳞󴳶󴳼󴳑󴳚󴳖󴳴󴱺󴳪󴳌󴳀󴳮󴱲󴰾󴲗󴱪󴱳󴱵󴲝󴱓󴱱󴱏󴲉󴱤
• PC󴲵󴳲󴳂󴲯󴲬󴳼󴳒󴲯󴱲 󴱹󴱗󴱓󴲖󴱹󴱲󴱹󴳚󴴅󴳍󴲝󴱘󴱱󴲉󴱤
• RGB 5V RGB󴳀󴳂󴳏󴳩󴱺 󴱹󴳧󴲿󴴅󴳥󴴅󴳒󴱹 󴱶󴱢󴲉󴱤
• 240mm 󴱯󴱹󴳞󴲪󴳼󴱳6󴱹󴳲󴳁󴲱󴴅󴳈󴴅󴲝󴱲󴱤
• 300mm 󴲹󴳲󴳞󴲬󴳌󴲸󴲴󴴅󴳒󴱶󴱲󴱘󴲉󴱤
• 2 3.5 HDD 3 2.5" SSD󴱯󴱹 󴲭󴳼󴳊󴱹 󴱳 󴱯󴱹 󴲝󴱲󴱘󴲉󴱤
日本語
• 우수한 외관과 충분한 공기 흐름이 결합 된 메쉬 전면 패널
• 강력한 강화 유리 좌측 덮개가 있는 우아한 디자인
• 5V RGB RGB 마더 보드 동기화 기능이있는 통합 시스템
• 240mm 최대 개의 6 팬 및 라디에이터 지원
• 300mm 최대 의 긴 그래픽 카드를 지원
• 3.5" HDD 2 2.5" SSD 3개와 개
한국어
GLOBAL WARRANTY POLICY
WARRANTY PERIODS OF COUGAR GAMING DEVICES
Product : COUGAR MX410 Mesh-G RGB
Warranty : 1 Year
●
This warranty gives you specific legal rights. You may also have other rights granted under local law. These rights may vary.
●
Only for electrical components.
Case Form Factor
Dimension
Motherboard Type
I/O Panel
Case Drive Bays
Expansion Slots
Model Name
Cooling Fan Support
Water Cooling Radiator Support
Maximum Number of Fans
Max. Graphics Card Length
Max. CPU Cooler Height
Max. PSU Length
300 (mm) / 11.8 (in) (Only fans at the front panel)
270 (mm) / 10.6 (in) (Radiator with fans at the front panel)
165mm / 6.5inch
160mm / 6.3inch
MX410 Mesh-G RGB
Model No.
CGR-5VM6B-MESH-G-RGB
Mid Tower
210 (W) x 455 (H) x 380 (D) mm / 8.3 (W) x 17.9 (H) x 15 (D) inch
7
Mini ITX / Micro ATX / ATX
USB 3.0 x 2 , USB 2.0 x 2 , Mic x 1, Audio x 1 , RGB Control Button
3.5" : 2 max.
2.5" : 3 max.
Front : 120mm x 3 (RGB fans x 3 pre-installed)
Rear : 120mm
Top : 240mm
*
/ 120mm ( Max. Component Height on Motherboard is 40mm )
Front
: 240mm
*
/ 120mm
6 Max.
Top : 120mm x 2
Rear : 120mm x 1 (RGB fan x 1 pre-installed)
MX410 Mesh-G RGB sports an attractive and compact design with a massive mesh front panel



ACCESSORY KIT
X 8Fan screws
X 17
Motherboard screws and 2.5" SSD screws
X 12Power supply screws
X 3Stand-off
3.5" HDD screws X 8
Cable ties X 6
B
E
F
G
I
J
K
L
M X 4 1 0
M E S H
-
G RGB
USB 3.0 HD AUDIO POWER SW POWER
HD AUDIO
POWER SW
H.D.D LEDPOWER LED
POWER LED +
POWER LED
-
USB3.0
USB 2.0
USB
H.D.D LED
-
+
год и месяц изготовления продукции указаны в серийном номере продукта.
(существует 2 способа определения даты изготовления, оба способа описаны ниже)
После S/N: первые две цифры означают год, вторые две – месяц изготовления.
Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702
После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,
и означают год,
последующие две цифры – месяц изготовления.
Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02
●
Например,
AG = 17 = 2017 год
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
A B C D E F G H I J
12345 78906
A
B
БЪЛГАРИЯ
• Подробни инструкции за употреба изтеглете от: https://cougargaming.com/bg
България QR код
120
*240
*240
120
(Top)
1
(Rear)
3
120 120
120120
(Front)
2
Installing water cooling radiators & cooling fans
* Please choose either of front or top to install a 240mm radiator.
* Max. component height on motherboard is 40mm.
1
1
2
3
2
3
Installing the internal 2.5
"
SSDs
RIGHT
1
2
RIGHT
LEFT
RIGHT
Removing side panels
Installing PCI-E cards
2
1
2
1
2
1
LEFT
1
2
Installing the internal 3.5
"
HDDs
RIGHT
Controlling lighting modes
Support for graphics card up to 300mm-long
RIGHT
RIGHT
2
1
RIGHT
3
4
Compucase Enterprise Co.,Ltd.
No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C
Tel:+886-6-356-0606
Service E-Mail:service@cougargaming.com
COUGAR USA Technical Service
Tel: (833) 256-3778
Mail: rma@compucaseusa.com
https://cougargaming.com/support/contact/upload/
* 300 (mm) / 11.8 (in) (Only fans at the front panel)
* 270 (mm) / 10.6 (in) (Radiator with fans at the front panel)
3
First Mode: 16 Preset Lighting Effects
You can use the front panel’s RGB SW button to switch between the sixteen beautiful
lighting effects we have preset for you.
Second Mode: Motherboard Synchronization
Please use the included adaptor to connect to a compatible motherboard’s
3-pin 5V Addressable RGB header. Then, press and hold the RGB SW button
for 3-5 seconds.
If you press the RGB SW button for 1 second again.
It will be returned to the First mode: 16 Preset Lighting Effects
First Mode: 16 Preset Lighting Effects
Second Mode: Motherboard Synchronization
Press the RGB button for one second
Press and hold the RGB button for 3-5 seconds
For more information, please visit
Compucase Enterprise Co.,Ltd.
All rights reserved.
www. coug arga ming .com
Made in China
LED Strip 1
5V Addressable Header Adapter
Power Connector
FAN1
FAN2
FAN3
LED Strip 2
FAN6
FAN5
FAN4
RGB SW button
*
Please don't remove the SATA connector from the PSU
RIGHT
