Side 1/2
Power button / RGB button
A
G2.5" HDD/SSD trays
USB 3.0 / USB 2.0 / HD audio ports
B
HSlot covers
CFront panel
IAir filter for top panel
DTempered glass side panel
Air filter for front panel
J
ERight side panel
KAir filter for bottom panel
Specifications might vary depending on the country or region of sale.
Installing the Front I/O Connectors
MX440 Mesh RGB s front panel features bold lines and rugged structures. It is the chassisʼ
that brings the new concept of strength and sturdy to the gaming world. Moreover, the
mesh front panel provides superior airflow and keeps your advanced components safe from
overheating.
MX440 Mesh RGB comes with 3 ARGB fans. You are freely to control several amazing lighting
effects that we have preset for you with the dedicated RGB button.
With the full-length PSU cover hides cables and a massive tempered glass left panel presents
a clean and tidy build, you can easily build a pro-level system.
MX440 Mesh RGB s 215mm width allows much larger interior space with better coolingʼ
performance and cable management. However, its compact exterior dimension takes
up less desktop space. MX440 Mesh RGB can surely fit a full-sized ATX Motherboard,
320mm-length Graphic card, four 2.5 SSDs, and two 3.5 HDDs, which allow you to” ”
achieve the extreme operation and abundant storage space.
The top panel is equipped with two USB 3.0 ports and one USB 2.0 ports, let you easily
connect multiple peripheral devices and accessory charging. Not only optimize your processing
experiences, but also keep all USB devices without limitations.
MX440 Mesh RGB s interior space supports up to 170mm height CPU air cooler, a 360mmʼ
water cooling radiator, and high-end cooling components. It helps you to protect critical
components from overheating.
F3.5" HDD cage (compatible for 2.5" HDD/SSD)
L2 x 120mm fans for top panel (optional)
M3 x 120mm / 2 x 140mm fans for front panel
(3 x 120mm ARGB Fans pre-installed)
N120mm / 140mm fan for rear panel (optional)
• Mesh front panel combines with excellent appearance and
sufficient airflow
• Massive tempered glass left panel
• Support for up to six fans and a 360mm radiator
• Support for up to 320mm long graphics cards
• Support for two 3.5" HDDs and four 2.5" SSDs
ENGLISH
• Mesh-Frontpanel kombiniert mit exzellentem Erscheinungsbild
und ausreichendem Luftstrom
• Linker Abdeckung aus massivem gehärtetem Glas
• Unterstützt bis zu sechs Lüfter und einen 360-mm-Kühlkörper
• Unterstützt Grafikkarten mit einer Länge von bis zu 320 mm
• Unterstützt 2 3,5" Zoll-Festplatten und 4 2,5" Zoll-SSDs
DEUTSCH
• El panel frontal de malla, realiza una excelente combinación
entre apariencia y su sistema de flujo de aire
• Panel izquierdo de vidrio templado
• Soporta hasta 6 ventiladores y un radiador de 360mm
• Soporte para tarjetas gráficas de hasta 320mm de largo
• Soporte para 2 HDD de 3.5" y 4 SSD de 2.5"
ESPAÑOL
• Siatkowy panel przedni łączy się z doskonałym wyglądem i
wystarczającym przepływem powietrza
• Lewej pokrywie z litego szkła hartowanego
• Obsługa maksymalnie 6 wentylatorów i radiatora do 360 mm
• Możliwość montażu kart graficznych o długości do 320 mm
• Obsługa 2 dysków twardych 3,5" i 4 SSD 2,5"
POLISH
• Painel frontal Mesh combina excelente design com alto fluxo de ar
• Painel lateral esquerdo em vidro temperado
• Suporta até 6 ventoinhas e radiador de 360mm
• Suporta placas gráficas de até 320mm
• Suporta até 2 HDDs de 3.5" e 4 SSDs de 2.5"
PORTUGUÊS
РУССКИЙ
• Сетчатая передняя панель отлично с очетается с внешним
видом корпуса и мощным потоком воздуха
• массивной левой панелью из закаленного стекла
• Поддержка до шести вентиляторов и 360-мм радиатора
• Поддержка видеокарт длиной до 320 мм
• Поддержка двух 3.5-дюймовых жестких дисков и четыре
2.5-дюймовых SSD
• Le panneau avant en maille se combine avec une excellente
apparence et un flux d'air suffisant
• Un capot gauche en verre trempé massi
• Prend en charge jusqu'à 6 ventilateurs et un radiateur de 360 mm
• Prend en charge les cartes graphiques jusqu'à 320 mm de longueur
• Prise en charge de 2 disques durs 3,5" et 4 SSD 2,5"
FRANÇAIS
• 铁网面板结合美观设计与畅通气流
• 全透钢化玻璃左侧盖
• 360mm最高可支援6个风扇与 的水冷散热器
• 320mm支援长达 的显示卡
• 支援2个 3.5" HDD硬碟与4个 2.5" SSD硬碟
中 文
․フロントパネルはメッシュ設計で、優れた外観と十分な通気性を備えています
• PC強化ガラスウィンドウで の内部が見えるので内部のパーツを引き立てます
• 6個のファンと ｍｍの水冷ラジエーターを装着でき、優れた放熱効果を確保します360
• 320mm最大 グラフィックカードに対応できます
• 2 2.5" SSDつの つの3.5"のHDDと4を搭載可能です
日本語
• 우수한 외관과 충분한 공기 흐름이 결합 된 메쉬 전면 패널
• 강력한 강화 유리 좌측 덮개가 있는
• 최대 6 개의 팬 및 360mm 라디에이터 지원
• 최대 320mm의 긴 그래픽 카드를 지원
• 3.5" HDD 2 2.5" SSD 4개와 개
한국어
Case Form Factor
Dimension
Motherboard Type
I/O Panel
Case Drive Bays
Expansion Slots
Model Name
Cooling Fan Support
Water Cooling Radiator Support
Maximum Number of Fans
Max. Graphics Card Length
Max. CPU Cooler Height
Max. PSU Length
320mm / 12.6inch
Transparent Left Panel 4mm Tempered Glass
170mm / 6.7inch
150mm / 5.9inch
MX440 Mesh RGB
Model No. CGR-56C1B-MESH-RGB
Mid Tower
215 (W) x 505 (H) x 424 (D) mm / 8.5 (W) x 19.9 (H) x 16.7 (D) inch
7
Mini ITX / Micro ATX / ATX
USB 3.0 x 2 , USB 2.0 x 1 , Mic x 1, Audio x 1 , RGB Button
3.5" : 2
2.5" : 4 + 1 (converted from 3.5" drive bays) / (2 SSD trays included)
Front : 120mm x 3 / 140mm x 2 (120mm ARGB Fans x 3 pre-installed)
Rear : 140mm / 120mm
Top : 240mm / 120mm
Front
: 360mm / 280mm / 240mm / 140mm / 120mm
6 Max.
Top : 120mm x 2
Rear : 120mm x 1 / 140mm x 1
MX440 Mesh RGB s design has continued COUGAR s iconic sturdy and solid style. With included ʼ ʼ
three ARGB fans and a mesh front panel, it combines excellent air flow performance and great
lighting view. Besides, it has wide and powerful interior spaces, which allows you to have
hardware expandability, high cooling performance, and abundant storage space.
USB 3.0 HD AUDIO POWER SW
HD AUDIO
POWER SW
POWER LED
POWER LED +
POWER LED
-
USB3.0
USB 2.0
USB
H.D.D LED
H.D.D LED
-
+
WARRANTY PERIODS OF COUGAR GAMING DEVICES
Product : COUGAR MX440 Mesh RGB
Warranty : 1 Year
● This warranty gives you specific legal rights. You may also have other rights granted under local law. These rights may vary.
● Only for electrical components.
ACCESSORY KIT
год и месяц изготовления продукции указаны в серийном номере продукта.
(существует 2 способа определения даты изготовления, оба способа описаны ниже)
После S/N: первые две цифры означают год, вторые две – месяц изготовления.
Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702
После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,
и означают год,
последующие две цифры – месяц изготовления.
Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02
●
Например,
AG = 17 = 2017 год
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
A B C D E F G H I J
123456 8907
A
B
БЪЛГАРИЯ
• Подробни инструкции за употреба изтеглете от: https://cougargaming.com/bg България QR код
X 20Fan screws
X 82.5”HDD / SSD EVA washers
X 29Motherboard screws and 2.5" SSD screws
X 4Power supply screws
X 3Stand-off
3.5" HDD screws X 8
Cable ties X 5
Installing water cooling radiators & cooling fans
Installing the 2.5" SSDsRemoving side panels
1
2
1
2
3
4
2
12 31
Installing the 3.5" HDDs
4
3
Compucase Enterprise Co.,Ltd.
No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C
Tel:+886-6-356-0606
Service E-Mail:service@cougargaming.com
COUGAR USA Technical Service
Tel: (833) 256-3778
Mail: rma@compucaseusa.com
https://cougargaming.com/support/contact/upload/
For more information, please visit
Compucase Enterprise C o.,Ltd.
All rights reser ved. Made in China
1
3
2
120140240280360
120
120
120
240
140
120140
120140
(Top)
1(Front)
2
(Rear)
3
LEFT
RIGHT RIGHT
1
2
3
4
5
RIGHT
1
2
LEFT
1
2
1
RIGHT
2 3
RIGHT
LEFT
3
4
Connectors
Connectors
Connectors
5
1
2
Installing PCI-E cards
Support for graphics card up to 320mm-long
RIGHT
A. Please lift up the tempered glass panel
from the bottom left notch.
B. When lifting up the tempered glass panel,
please hold it carefully with your other hand.
A
B
2.5" HDD / SSD EVA washers
X 8
※ Please stick EVA washers on SSD holes before
installing 2.5" SSD.
