Side 1/2
FEATURES
Assembly Drawing
●
Подробни инструкции за употреба
изтеглете от:https://cougargaming.com/bg
БЪЛГАРИЯ
България QR код
ENGLISH
●
sufficient airflow
●
Integrated RGB system with 5V ARGB motherboard
synchronization
●
Massive tempered glass left side panel
●
Support for up to E-ATX motherboard
●
Support for up to a 360mm water cooling radiator and eight fans
●
Support for up to 410mm graphics cards
●
Support for vertical GPU
POLISH
●
Przedni panel siatkowy łączący w sobie doskonały wygląd
i wystarczający przepływ powietrza
●
Zintegrowany system RGB zsynchronizowany z płytą główną
przez złącze ARGB 5V
●
Lewy panel ze szkła hartowanego
●
Obsługa płyt głównych do E-ATX
●
Obsługa chodnicy wodnej o szerokości do 360 mm i ośmiu wentylatorów
●
Obsługa kart graficznych o długości do 410 mm
●
Obsługa procesora graficznego montowanego pionowo
ITALIA
●
Il pannello anteriore in rete si combina con un aspetto
eccellente e un flusso d'aria sufficiente
●
Sistema RGB integrato con sincronizzazione della scheda
madre ARGB 5 V
●
Pannello sinistro in vetro temperato massiccio
●
Supporto fino a una scheda madre E-ATX
●
Supporto per un radiatore per raffreddamento ad acqua fino
a 360 mm e otto ventole
●
Supporto per schede grafiche fino a 410 mm
●
Supporto per GPU verticale
PORTUGUÊS
●
Painel frontal em malha combina com excelente aspecto
e fluxo de ar suficiente
●
Sistema RGB integrado com sincronização de placa mãe
de 5V ARGB
●
Painel esquerdo em vidro maciço temperado
●
Apoio até à placa-mãe E-ATX
●
Suporte para um radiador de arrefecimento a água até 360mm
e oito ventiladores
●
Suporte para placas gráficas até 410mm
●
Suporte para GPU vertical
РУССКИЙ
●
Сетчатый дизайн передней панели обеспечивает
достаточный поток воздуха
●
Интегрированная система RGB подсветки с 5V ARGB
синхронизацией материнской платы
●
Массивная боковая панель из закаленного стекла
●
Поддержка всех материнских плат до формата E-ATX
●
Поддержка водяного охлаждения радиатора размером до
360 мм и восьми вентиляторов
●
Поддержка всех видеокарт размером до 410 мм
●
Поддержка вертик ального графического процессора
DEUTSCH
●
Gitterfrontblende kombiniert ausgezeichnetes Aussehen
und ausreichenden Luftstrom
●
Integriertes RGB-System mit
5-V-ARGB-Motherboard-Synchronisierung
●
Linke Blende aus massivem Hartglas
●
Unterstützt Motherboards bis E-ATX
●
Unterstützt einen Wasserkühlkörper bis 360 mm und acht
Lüfterherboard
●
Unterstützt Grafikkarten bis 410 mm
●
Unterstützt vertikale GPU
ESPAÑOL
●
El panel frontal de malla se combina con una excelente
apariencia y suficiente flujo de aire
●
Sistema RGB integrado com sincronização de placa mãe
de 5V ARGB
●
Panel izquierdo de cristal templado masivo
●
Soporte para la placa madre de hasta E-ATX
●
Soporte para un radiador de refrigeración de agua de hasta
360 mm y ocho ventiladores
●
Soporte para tarjetas gráficas de hasta 410 mm
●
Soporte para la GPU vertical
FRANÇAIS
●
Le panneau frontal en maille combine une excellente
apparence avec un flux d'air suffisant
●
Système RGB intégré avec synchronisation de la carte
mère ARGB 5V
●
Panneau gauche en verre trempé massif
●
Prise en charge des cartes mères jusqu'à E-ATX
●
Prise en charge d'un radiateur de refroidissement à eau de
360 mm et de huit ventilateurs
●
Prise en charge des cartes graphiques jusqu'à 410 mm
●
Compatible avec les GPU verticaux
●
铁网面板结合美观设计与畅通气流
●
RGB整合系统支援5V ARGB主机板灯效同步控制功能
●
全景透视钢化玻璃左侧盖
●
最高支援E-ATX主机板
●
最高支援360mm水冷排与8个风扇
●
最高可安装410mm显卡
●
支援显卡垂直安装
中 文
●
우수한 외관과 충분한 공기 흐름이 결합된 메쉬 전면 패널
●
5V ARGB 마더 보드 동기화 기능이있는 통합 RGB 시스템
●
좌측 패널의 크고 단단한 대형 강화유리
●
최대 E-ATX 마더보드 지원
●
최대 360mm 수랭식 라디에이터 및 팬 8개 지원
●
최대 410mm 그래픽 카드 지원
●
수직 GPU 지원
한국어
●
メッシュパネルで、放熱を最適化した設計によって優れた冷却性能を実現
●
ARGBシステムは5VのマザーボードのRGB効果に同期します
●
強化ガラスウィンドウでPCの内部が見えるので内部のパーツを引き立てます
●
E-ATXマザーボードに対応
●
8個のファンと360ｍｍの水冷ラジエーターを装着でき、優
れた放熱効果を確保します
●
最大410mmグラフィックカードに対応できます
●
グラフィックカードを垂直に取付可能
日本語
MX660 Mesh RGB-L
CGR-5BMSB-MESH-RGB-L
Mid-Tower
213 (W) x 495 (H) x 474 (D) mm
8.4 (W) x 19.5 (H) x 19 (D) in.
Mini ITX / Micro ATX / ATX / CEB / E-ATX
120mm x 1
2
120mm x 1 (for HDD Cooling)
8 Max.
*360mm / 280mm / 240mm / 140mm / 120 mm
*360mm / 280mm / 240mm / 140mm / 120 mm
120mm
200 (mm) / 7.9 in.
5+2 (converted from 3.5" drive bays) / (2 SSD trays included)
7+2
*120mm ARGB Fans x 3 (pre-installed) / 140mm x 2
120mm x 3 / 140mm x 2
USB3.0 x 2, Type C 3.1 x 1, Mic x 1 / Audio x 1, RGB Button
Model Name
Model No.
Case Form Factor
Motherboard Type
Dimensions (WxHxD)
I/O Panel
3.5" Drive Bay
2.5" Drive Bay
Expansion Slots
Cooling Fan
Support
Water Cooling
Support
Maximum Number of Fans
Max. Graphics Card Length
Max. CPU Cooler Height
Max. PSU Length
* Please choose either of front or top to install a 360mm radiator.
* Top 360mm radiator supports within 30mm thickness.
* Please choose either of a TOP 360mm radiator or FRONT 120mm x 3 fans to install.
Specifications might vary depending on the country or region of sale.
410 (mm) / 16.1 in.
165 (mm) / 6.5 in.
Onboard Lighting System
RGB Sync with M/B
Yes
Yes
Rear
PSU cover
Front
Top
Rear
Front
Top
C
A
B
P
F
N
I
J
O
H
G
M
K
L
D
E
E
2 x 140mm /
120mm ARGB Fans x 3(pre-installed)
MX660 MESH
Installing the Front I/O Connectors
USB 3.0Type-C 3.1 HD Audio
HD AUDIO
POWER SW
USB3.0
Power SW Power LED
POWER LED
POWER LED
+
-
Accessory kit
X 5
X 12
Power supply screws
2.5"
HDD
/ SSD EVA washers
X 17
Motherboard
/ SSD screws
Fan screws
(on PSU cover for
HDD cooling)
X 4
X 5
Cable ties
X 5
Stand-off
for motherboard
X 2
Stand-off
for VGA riser cable
Power button
/ RGB button
A
Removable front panel
C
USB3.0 x 2, Type C 3.1 x 1
Mic , Audio
B
F
Right side panel
Thumb screws
E
D
Tempered glass
left panel
Slot covers
G
1 x 120mm fan on PSU cover
for HDD Cooling
O
2.5" HDD/SSD trays
H
Air filter at the front
P
3.5" HDD trays (compatible
for 2.5" HDD/SSD)
I
Air filter at the bottom
J
Air filter on the top
L
120mm fan for rear panel
M
2 x 140mm / 3 x 120mm fans
K
N
Made in China
For more information, please visit
www.cougargaming.com
Compucase Enterprise Co.,Ltd.
All rights reserved.
Compucase Enterprise Co.,Ltd.
No. 225, Lane 54, An Ho Road Sec. 2
Tainan, Taiwan, R.O.C
Tel:+886-6-356-0606
Service E-Mail:
service@cougargaming.com
COUGAR USA Technical Service
Tel: (833) 256-3778
Mail: rma@compucaseusa.com
https://cougargaming.com/support/
contact/upload/
GLOBAL WARRANT Y POLICY
WARRANTY PERIODS OF COUGAR GAMING DEVICES
Product : COUGAR PC Case
Warranty : 1 Year
This warranty gives you specific legal rights.
You may also have other rights
granted under local law.
These rights may vary.
*only for electrical components
год и месяц изготовления продукции указаны в серийном номере продукта.
(существует 2 способа определения даты изготовления, оба способа описаны ниже)
После S/N: первые две цифры означают год, вторые две – месяц изготовления.
Например, S/N: H 000001 означает, что товар был произведен в феврале 1702 2017 года.
После S/N:
если указаны буквы, то две буквы представляют цифры из таблицы ниже,
и означают год, последующие две цифры – месяц изготовления.
Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02
●
Например, AG=17=2017 год
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
A B E F G HC D I J
1 2 3 4 5 6 7 08 9
A
B
MX660 Mesh RGB-L is an upgraded mid-tower case, which continues COUGAR’s iconic
style.The massive mesh front panel with folding angles provides better air flow
performance.With three ARGB fans and a crystal clear tempered glass left panel, you are
freely to create a clear view of your computer’s internal components.
ADVANCED MID-TOWER CASE WITH POWERFUL AIRFLOW
RGB SW
button
2
1
1
Right
1
3
2
1
Left
Removing the side panels 2.5" HDD/SSD Installing 3.5" HDDInstalling
LeftRight Right Right
1 2
3
4 5
6
7
Right
Left
1
2
3
4
7
5 6
●
Please stick EVA washers on SSD holes
before installing 2.5" SSD.
2.5" HDD/SSD
EVA washers
1
4
4
2
Connectors
1
2
120
140
240
280
120
120
140
120
120
Top 360mm radiator supports
within 30mm thickness.
Please choose either of front or top to install a 360mm radiator.
Installing water cooling radiators & cooling fans
TOP
REAR
PSU COVER
1
2
3
4
nectors
PUSH &
HOLD the Bar
PUSH &
HOLD the Bar
3
PUSH &
HOLD the Bar
1
2
Lift up with 45°
Angle to Remove it
*360
*120
140
120140240280
360
FRONT
* Please choose either of a
TOP 360mm radiator or
FRONT 120mm x 3 fans
to install.
1
2
Stand-off
for VGA riser cable
The vertical graphic
card and the PCI-E
riser cable are not
i n c l u d e d i n t h e
p a c k a g e , p l e a s e
purchase separately.
Please choose either
of a Vertical Graphic
Card or 2.5" SSD
trays on the PSU cover
to install.
Max. Graphics Card
Length :
410mm
3
Installing Vertical Graphic Card
1
2
3
4
5
6
5V Addressable
RGB adapter
Power
connector
1
1 2 3 4 5 6
Power cable
Power supply
Controlling lighting modes
FIRST MODE: SEVERAL LIGHTING EFFECTS
You can use the front panel’s RGB button to switch between several beautiful lighting effects we have preset for you.
SECOND MODE: MOTHERBOARD SYNCHRONIZATION
Please use the included adapter to connect to a compatible motherboard’s 3-pin
5V Addressable RGB header. Then, press and hold the RGB button for 3 seconds.
1
2
Power
cable
Power supply
Motherboard
5V Addressable
RGB adapter
5V Addressable RGB connector
If you press and hold the RGB button for
3 seconds again. It will be returned to the
First mode: Preset Lighting Effects
FIRST MODE
Several Lighting
Effects
Press the RGB button
for one second
1 sec
SECOND MODE
Motherboard
synchronization
Press and hold the RGB
button for 3 seconds
3 secs
2

Produkt Specifikationer

Mærke: Cougar
Kategori: Computertaske
Model: MX660 Mesh RGB-L

Har du brug for hjælp?

Hvis du har brug for hjælp til Cougar MX660 Mesh RGB-L stil et spørgsmål nedenfor, og andre brugere vil svare dig


Computertaske Cougar Manualer

Cougar

Cougar MX660 Mesh RGB-L Manual

26 August 2025
Cougar

Cougar Turret Mesh Manual

26 August 2025
Cougar

Cougar Blazer Essence Manual

26 August 2025
Cougar

Cougar Panzer Manual

26 August 2025
Cougar

Cougar Airface Pure RGB Manual

26 August 2025
Cougar

Cougar Gemini T Pro Manual

26 August 2025
Cougar

Cougar MX331 Mesh-X Manual

26 August 2025
Cougar

Cougar MX350 Manual

26 August 2025
Cougar

Cougar MX660 Mesh RGB Manual

26 August 2025
Cougar

Cougar FV150 Manual

14 August 2025

Computertaske Manualer

Nyeste Computertaske Manualer

Spirit Of Gamer

Spirit Of Gamer Rogue 5 Manual

26 August 2025
Spirit Of Gamer

Spirit Of Gamer GHOST 5 Manual

26 August 2025
Asus

Asus TUF Gaming GT302 ARGB Manual

26 August 2025
Gigabyte

Gigabyte Cupio 6140 Manual

26 August 2025
Gigabyte

Gigabyte MIB T5142 Manual

26 August 2025
Gigabyte

Gigabyte GZ-KXA Manual

26 August 2025
Gigabyte

Gigabyte Setto 1000 Manual

26 August 2025
Gigabyte

Gigabyte C102 GLASS ICE Manual

26 August 2025
Gigabyte

Gigabyte C200 GLASS Manual

26 August 2025
Gigabyte

Gigabyte Sumo α Manual

26 August 2025
