Side 1/1

Vented slot covers

Tempered glass side cover

Thumb screws

Right side cover

Front panel

Power button / Reset button

USB 3.0 / USB 2.0 / HD audio ports

Assembly Drawing

3.5" HDD trays (compatible with 2.5" HDD/SSD)

2.5" HDD/SSD drive bays

Air filter on bottom cover

120mm fan for rear panel (pre-installed)

120mm fans x 3 for front panel (optional)

Magnetic fan filter on top cover

120/140mm fans x 2 for top cover (optional)

Specifications might vary depending on the country or region of sale.

Accessory Kit

X 17

X 16X 12

X 4

X 8

Specifications might vary depending on the country or region of sale.

For Fans For SSD

For Fans

For PSU

Expansion Card

For Motherboard

HDD

X 4

Cable ties

Expansion Slots

Max. Graphic Card Length

350mm / 13.8 inch

Max. CPU Cooler Height m / 6.3 inch 160m

Standard ATX PS2PSU

Middle Tower

Mini ITX / Micro ATX / ATX

206 (W) x 461 (H) x 420 (D)mm / 8.11 (W) x18.14 (H) x 16.53 (D)inch

Fron 120mm x t : 3 / 140mm p1-x2

To 120 mm x 2p : /140

Rear : 120mm x 1

(Pre-installed )

Front : 360mm / 240mm / 120mm

Top : 120/240mm

(Max Component Height on Motherboard 40mm)

Rear : 120mm

3.5" : 2

2.5" : 2+2 (Converted from 3.5" Drive Bays)

USB3.0 x 2 / USB2.0 x 1, Mic x 1,

Audio x 1

Dimensions

Water Cooling Radiator Support

Case Drive Bays

I/O Panel

Cooling Fan Support

Motherboard Type

Case Type

YesCable Management

For more information, please visit

Compucase Enterprise Co.,Ltd.

ww w.c oug arg ami n g.c om

Made in China

Compucase Enterprise Co.,Ltd.

No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C

Tel:+886-6-356-0606

Service E-Mail:service@cougargaming.com

COUGAR USA Technical Service

Tel: (833) 256-3778

Mail: rma@compucaseusa.com

https://cougargaming.com/support/contact/upload/

●

Например,

AG = 17 = 2017 год

A B C D E F G H I J

1 2 3 4 5 6 7 8 9 0

год и месяц изготовления продукции указаны в серийном номере продукта.

(существует 2 способа определения даты изготовления, оба способа описаны ниже)

После S/N: первые две цифры означают год, вторые две – месяц изготовления.

Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702

После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,

и означают год, последующие две цифры – месяц изготовления.

Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02

ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ

TURRET

PRO-COOLING COMPACT PC CASE WITH

TEMPERED GLASS SIDE WINDOW

Turret Mesh is an affordable case with superb cooling. It sports an attractive and compact

design with a tempered glass window. It can house up to three radiators and has a mesh

front cover that guarantees excellent airflow. It also allows you to install up to three

350mm-long graphics cards. What else can you ask for?

• Massive Tempered Glass Side Window

• Supports Three Radiators (Frontal: 360mm, Top: 240mm, Rear: 120mm)

• Mesh Front Cover: Plenty of Air for Your System

• Power Gaming: Supports Three 350mm-Long Graphics Cards

• Supports Two 3.5" HDDs (or Two Additional 2.5" SSDs) and Two 2.5" SSDs

ENGLISH

• Gran Ventana de Vidrio Templado

• Soporta Tres Radiadores (Frontal: 360mm, Superior: 240mm, Posterior: 120mm)

• Cubierta Frontal de Malla Metálica: Gran Flujo de Aire

• Hasta Tres Tarjetas Gráficas de 350mm

• Soporta Dos HDD de 3.5" ( convertibles a dos SSD de 2.5" adicionales) y Dos SSD de 2.5"

ESPAÑOL

• Janela lateral em vidro temperado massivo

• Suporta três radiadores (frontal: 360 mm, topo: 240 mm, traseira: 120 mm)

• Tampa frontal de malha: ar de sobra para o seu sistema

• Gaming poderoso: suporta três placas gráficas de 350 mm de comprimento

• Suporta dois HDDs de 3.5" (ou dois SSDs adicionais de 2.5") e dois SSDs de 2.5"

PORTUGUÊS

• Массивное боковое окно из закаленного стекла

• Поддерживает три радиатора (фронтальный: 360 мм, верх: 240 мм, сзади: 120

• Передняя панель из сетки: больше охлаждения для Вашей системы

• Мощная игра: поддерживает три графических карты длиной 350 мм

• Поддерживает два 3.5 "жестких диска (или два дополнительных 2.5" SSD) и два

РУССКИЙ

• Finestra laterale in vetro temperato massiccio

•

Supporta tre radiatori (parte anteriore: 360 mm, parte superiore: 240 mm, parte posteriore

• Copertura frontale in rete: Pieno di aria per il sistema

• Potente gaming: Supporta tre schede grafiche di 350 mm di lunghezza

• Supporta due HDD da 3,5" (o due SSD da 2,5" aggiuntive) e due SSD da 2,5"

ITALIANO

Installing the Front I/O Connectors

How to install the 3.5”HDD

Pull

to install a water cooler (f

LEFT

RIGHT

How to install a

Rear

PSU BRACKET

LEFT

How (rear)

LEFT

RIGHT

LEFT SIDE

How to install a water cooler (to

LEFT

USB 3.0 HD AUDIO USB 2.0

HD AUDIO USB

POWER SW POWER LEDRESET SW

POWER SW

RESET SW

POWER LED +

POWER LED
