Place terminal in a secure
position so that it won’t
accidentally contact the
negative battery post
Power / Ground
cable size
It is critical to use the proper
power and ground cable. Select
the size listed here for your
amplier model. Always use high
quality copper cable.
Cable size recommendations for
multi amp systems are available
on our website.
Properly route power,
speaker and RCA cables
through the vehicle.
Choose a mounting location
that will provide adequate air
ventilation. Mount the amplier to
a secure surface. Do not mount
the amplier upside down.
Bare metal
Connect the RCA cables to
the INPUT connectors. The
OUTPUT can be used to
provide input for a second
amplier.
Connect the power cable to the
positive battery terminal. The
power cable must be fused
within 18 inches of the battery
terminal.
Re-connect the negative
battery terminal making sure it
is securely tightened.
The chassis ground connection
is critical to the performance
of the amplier. Choose a
location that is close to the
amplier. Completely scrape
away the paint and use a nut
and bolt if possible.
DO NOT USE AN EXISTING
FACTORY BOLT!
Disconnect
negative battery
terminal
Run Cables
Mount Amplier
Signal Input
Low Level RCA
Positive Battery
Connection
Re-connect
Negative Battery
Terminal
Chassis Ground
Be prepared to disarm your vehicle’s alarm and
to enter your radio / source unit code.
Installation
Before you start
CAUTION
Many new and factory radios require a reset code when
disconnected from battery power. This is an anti-theft
feature. Before unplugging power, you must determine if
your radio/source unit requires a reset code. Check the
operation manual for your vehicle or contact the dealer.
1
2
3
6
10
11
4
Turn the LEVEL control completely
counter-clockwise to minimum.
Level Control
7
4ga
Model Fuse Size Cable Size
PZ 2-1530.1D
PZ 2-203 0.1D
PZ2-3030.1D
PZ 2- 4 03 0.1D
PZ2-1030.2D
PZ2-1530.2D
PZ2-2030.2D
PZ2-1530.4D
PZ2-2030.4D
PZ2-2030.5D
External 60A
External 80A
External 125A
External 150A
External 40A
External 50A
External 100A
External 40A
External 60A
External 100A
Using spade terminals, connect the
+12V to the power cable from the
battery, the REM to the source unit
turn-on wire and the GND to the
chassis ground..
Using spade terminals,connect
the speaker cables to the speaker
output connectors. Follow the
diagram below that best ts your
speaker conguration.
Power
Connections
Speaker
Connections
Stereo
Monoblock
single woofer Monoblock multiple woofers
Bridged
5
9
SPEAKER
CH2CH1
CH2CH1
CH2CH1
BRIDGED
BRIDGED
BRIDGED
OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
CH2CH1
BRIDGED
SPEAKER OUTPUT
CH4CH3
BRIDGED
SPEAKER OUTPUT
SPEAKER
CH4CH3
BRIDGED
OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
SPEAKER
CH2CH1
CH2CH1
CH2CH1
BRIDGED
BRIDGED
BRIDGED
OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
CH2CH1
BRIDGED
SPEAKER OUTPUT
CH4CH3
BRIDGED
SPEAKER OUTPUT
SPEAKER
CH4CH3
BRIDGED
OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
SPEAKER
CH2CH1
CH2CH1
CH2CH1
BRIDGED
BRIDGED
BRIDGED
OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
CH2CH1
BRIDGED
SPEAKER OUTPUT
CH4CH3
BRIDGED
SPEAKER OUTPUT
SPEAKER
CH4CH3
BRIDGED
OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
SPEAKER
CH2CH1
CH2CH1
CH2CH1
BRIDGED
BRIDGED
BRIDGED
OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
CH2CH1
BRIDGED
SPEAKER OUTPUT
CH4CH3
BRIDGED
SPEAKER OUTPUT
SPEAKER
CH4CH3
BRIDGED
OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
SPEAKER OUTPUT
CH1 CH2
POWER
The HI INPUT is for use with source
units that do not offer RCA outputs.
Use the supplied harness to connect
to the source unit’s speaker output.
Signal Input
High Level
8
HI-INPUT
CH1
+
- -
+
CH2
The information contained within this document is intended to offer some basic guidelines
for a few of the most common installations. More complex audio systems should be
installed by a competent professional. Additional installation information available at
www.maxxsonics.com
9V 0.2V
INPUT
LEVEL
6V 0.2V
LEVEL
PHASE
0 180
BASS EQ
0 10dB
BASS EQ
0 9dB
BASS EQ
0 12dB
15 35Hz
SUBSONIC
10 40Hz
SUBSONIC
30 250Hz
LPF
35 250Hz
LPF
40 300Hz
LPF
FULL
LP
HP
XOVER
MONO STEREO
MODE
FULL
LPF
HPF
XOVER
MONO STEREO
MODE
4CH 2CH
MODE
60 1.3KHz
HPF
60 1.2KHz
HPF
10 2.5KHz
HPF
10 1.5KHz
HPF
