Side 1/2

Enjoy the internet!

Quick Installation Guide

NEED TECH HELP?

810600195

www.cudy.com/qr_vg_ap

www.cudy.com

support@cudy.com

www.cudy.com/download

Power Supply1

PoE Switch

Method 2: Via PoE Switch

Connect an Ethernet cable from the PoE switch to the Ethernet port.

Method 1: Via Power Adapter

Plug one end of the provided power adapter into the DC POWER

port of the AP and the other end to a standard electrical wall outlet.

Power Adapter

Method 3: Via PoE Adapter

Connect an Ethernet cable drom the Ethernet port of the AP device

to the PoE port of the provided PoE adapter.

LED and Button

PoE Adapter

LAN

PoE LAN

Software Conﬁguration

Method 1: Standalone Mode

To configure and manage APs separately.

Choose from the following methods to configure your APs.

Clients

Router AP

Internet

LANWAN

Note 1：

1. Before you start, be sure to power up and connect your devices according to the

topology figure.

2. A DHCP server (typically a router with DHCP function enabled) is required to assign IP

addresses to the APs and clients in your local network.

Note 2：

If the router you use is a Cudy mesh WiFi router(firmware version:1.15.28 or later), then

the access point will auto work as an add-on mesh unit and share the same WiFi network

name and password with the Cudy router you connect.

1. Connect wirelessly by using the default SSID printed on the

bottom label of the product.

2. Launch a web browser and enter in the http://cudyap.net/

address bar. Use as log in Password .admin

http://cudyap.net/

English

admin

3. Click " ", the window below will pop up, please Quick Setup

follow the step-by-step instructions to set up the internet

connection.

Quick Setup

Mode Timezone Connections Wireless Summary

Exit

Wireless Router

Opertion Mode

Wireless Access Point

Wireless Extender

WISP

Off

Red

Blue

Flashing blue

Yellow

Flashing yellow

Red, blue, and yellow alternate

Red and blue alternate

LED

Reset Button

Produkt Specifikationer

Mærke:	Cudy
Kategori:	Adgangspunkt
Model:	AP3000
Bredde:	232 mm
Dybde:	232 mm
Højde:	57.1 mm
Produktfarve:	Hvid
Opbevaringstemperatur (T-T):	-40 - 70 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 90 %
Ethernet LAN-porte (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Ethernet LAN-datahastigheder:	100,1000,2500 Mbit/s
Sikkerhedsalgoritmer:	WPA-PSK, WPA2-PSK, WPA3-SAE
Hurtig start guide:	Ja
Frekvensområde:	160 MHz
Placering:	Ceiling, Wall
Netværksstandarder:	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
Antenner, antal:	5
Servicekvalitet support (QoS):	Ja
Udgangsspænding:	12 V
AC-adapter inkluderet:	Ja
Processorfrekvens:	1300 MHz
Kompatible operativsystemer:	Microso Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux
Maksimal dataoverførselshastighed:	2976 Mbit/s
Antenne type:	Intern
Strøm over Ethernet (PoE):	Ja
Monteringssæt:	Ja
MIMO:	Ja
Indbygget processer:	Ja
2.4 GHz:	Ja
5 GHz:	Ja
Begrænsning af hastighed:	Ja
Wi-Fi-multimedie (WMM)/(WME):	Ja
Maksimal dataoverførselshastighed (5 GHz):	2402 Mbit/s
Maksimal dataoverførselshastighed (2,4 GHz):	574 Mbit/s
Service Set Identifier (SSID) funktioner:	Multiple SSIDs
Stråleformning:	Ja
MIMO type:	Multi User MIMO
Antenneretningstype:	Omniretningsbestemt
Driftsmodus:	Wireless Access Point, Wireless Router, Wireless Extender, WISP
Båndstyring:	Ja
Spread-spectrum-metode:	OFDMA
Hurtig roaming:	Ja
Chipsæt:	MT7981BA+MT7976CN+RTL8221B
Airtime Fairness (ATF):	Ja
Power over Ethernet (PoE) -type understøttet:	Active PoE
6 GHz:	Ingen
