Cudy AP3000 Outdoor Manual

Cudy Adgangspunkt AP3000 Outdoor

Læs gratis den danske manual til Cudy AP3000 Outdoor (2 sider) i kategorien Adgangspunkt. Denne vejledning er vurderet som hjælpsom af 26 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 13.5 anmeldelser. Har du et spørgsmål om Cudy AP3000 Outdoor, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

Software Conﬁguration

Method A – via a AP Controller or Cudy Mesh

Router: Connect the PoE adapter or PoE switch

to the LAN port of your Cudy Mesh Router. The

AP will be adopted into the Mesh network and

use the same Wi-Fi name and password.

Note: If the AP was conﬁgured before, press and hold the

Reset button for 5s to enable Mesh adoption.

Method B – Stand-alone AP: Connect the PoE

adapter or PoE switch to a router with Internet. Use

your computer/phone to search and connect Wi-Fi

“ ” with default password Cudy-Outdoor

“password”. Launch the browser on your device,

access http://cudyap.net, and create your

administration password. Follow the instructions.

Grip the base section of the antennas and tighten

them.

Note: Position the antennas at a 45-degree angle for optimal

downward Wi-Fi coverage.

Install the Wi-Fi Antennas

45° 45°

LAN/WAN

PoE IN

WPS Reset

Option a PoE Adapter: - Connect the access point

to the port of the PoE adapter via your PoE

Ethernet cable. Power up the PoE Adapter.

Power the AP

Option b PoE Switch: - Connect the access point

to a port of your PoE Switch via your PoE

Ethernet cable. Power up the PoE Switch.

LAN/WAN

PoE IN

WPS Reset

PoE Switch

LAN/WAN

PoE IN

WPS Reset

POE LAN

LAN/WAN

PoE IN

WPS Reset

Cudy Router

LAN/WAN

PoE IN

WPS Reset

Router

Quick Setup

Mode Timezone WAN Wireless Summary

Exit

Wireless Router

Opertion Mode

Wireless Access Point

Wireless Extender

WISP

Package Content

a. Access Point b. Wi-Fi Antennas

c. Ethernet Cable d. PoE Adapter

e. Power Cord f. Clamp g. Screw

Quick Installation Guide

Driver & Manual:

www.cudy.com/download

Website: www.cudy.com

Email: support@cudy.com

Support

For technical support, the user guide

and more information, please visit:

https://www.cudy.com/support

NEED TECH HELP?

810600311

Conﬁrm

http://cudyap.net/

Produkt Specifikationer

Mærke:	Cudy
Kategori:	Adgangspunkt
Model:	AP3000 Outdoor
Kode for international beskyttelse (IP):	IP65
Produktfarve:	Hvid
Ethernet LAN-porte (RJ-45):	1
Ethernet LAN-datahastigheder:	100,1000,2500 Mbit/s
Netværksstandarder:	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
Antenner, antal:	2
Knap til nulstilling:	Ja
WPS trykknap:	Ja
Maksimal dataoverførselshastighed:	- Mbit/s
Antenne type:	Ekstern
Strøm over Ethernet (PoE):	Ja
MIMO:	Ja
2.4 GHz:	Ja
5 GHz:	Ja
Antennefunktioner:	Aftagelig antenne
MIMO type:	Multi User MIMO
Spread-spectrum-metode:	OFDMA
Chipsæt:	MT7981, IPQ5018
Power over Ethernet (PoE) -type understøttet:	Active PoE, Passive PoE
6 GHz:	Ingen
